- Page 1 Last version of this manual IP1725EN • 2023-01-23 Ditec ARC Technical Manual Swing gates (translation of the original instructions) www.ditecautomations.com...
-
Page 2: Table Of Contents
Index Declaration of incorporation of partly completed machinery ..................4 UK Declaration of Conformity ..........................5 Technical data ..............................6 Operating instructions ........................... 7 Machinery Directive ........................... 7 Standard installation ..........................8 Dimensions and components ..........................9 Installation .............................. 10 Preliminary checks .......................... - Page 3 General safety precautions ATTENTION! Important safety instructions.Please follow these instructions carefully. Failure to observe the information given in this manual may lead to severe personal injury or damage to the equipment.Keep these instructions for future reference. This manual and those for any accessories can be downloaded from www.ditecautomations.com This installation manual is intended for qualified personnel only •...
-
Page 4: Declaration Of Incorporation Of Partly Completed Machinery
SE-261 44 Landskrona Sweden, declare, under our sole responsibility, that the type of equipment with the name: Ditec ARC BH Irreversible automation for swing gates up to 2.5 m Ditec ARC 1BH Irreversible automation for swing gates up to 5 m... -
Page 5: Declaration Of Conformity
SE-261 44 Landskrona Sweden Declare under our sole responsibility that the types of equipment with names: Ditec ARC BH Non-reversible automation for swing gates up to 2.5 m Ditec ARC 1BH Non-reversible automation for swing gates up to 5 m complies with the following directives and their amendments: •... -
Page 6: Technical Data
1. Technical data ARCBH ARC1BH Type Irreversible wings up to 2.5 m Irreversible wings up to 5 m Stroke control Rotary limit switch (optional) (limit switch) Power supply 24 V 24 V Absorption 12 A Power absorbed 75 W nom. 290 W nom. -
Page 7: Operating Instructions
1.1 Operating instructions Use: INTENSIVE (For vehicle or pedestrian accesses to large condominiums, industrial or com- mercial complexes and parking lots with very frequent use). - Performance characteristics are to be understood as referring to the recommended weight (approx. 2/3 of maximum permissible weight) and at an ambient temperature of 25°C. When used with the maximum permissible weight a reduction in the above mentioned performance can be expected. -
Page 8: Standard Installation
Semi-recessed key-operated selector switch without cylinder AXK5NI AXR7 RFID reader unit 5 x 0.5 mm² Ditec ARCBH Actuator for door wing of up to 2.5 m 2 x 1.5 mm² Ditec ARC1BH Actuator for door wing of up to 5 m Connect the power supply to an approved omnipolar switch with an opening distance of the contacts of at least 3 mm (not supplied). -
Page 9: Dimensions And Components
3. Dimensions and components Ø9 Ø9 Ø9 Ref. Description Fastening plate Gate mounting bracket... -
Page 10: Installation
4. Installation Unless otherwise specified, all measurements are expressed in millimetres (mm). 4.1 Preliminary checks Check that the structure is sufficiently rugged and that the hinge pivots are properly lubricated. Provide an opening and closing stop. 90° ~120° min 360 min 360 4.2 Gearmotor installation - Remove the gearmotor from the fastening plate [2]. - Page 11 - Fasten the articulated arms as shown in the figure. WARNING: move the wing to the fully closed position and align the arms to the holes [A]. - The arm articulations must be lubricated and the screws tightened so that they do not impede the movement of the arms.
-
