Allow Next Key Only used in Result Mode. Usually in Result mode only the result (sum) of the individual
modules is shown. By entering a non-zero value here this will define the number of seconds
that the Next key needs to be held down to enable individual item values to be viewed.
Once available the Next key will cycle between all the individual values and the result. This
will remain available until the handheld is powered off.
Each time the Next key is pressed the display will show a brief message indicating what will
be displayed; Input 1, Input 2, Result etc. From firmware version 1.2 onwards the handheld
allow customised prompt messages. See
F1 Data Tag The F1 key can be used to trigger other modules such as a WIRELESS-T24-SO module to
provide
printer services etc. This key will generate a Data Provider message which other modules
can use.
Set this value to non zero to enable this function and to define the Data Tag that will
identify the message sent.
The content of the message is defined by the F1 Data parameter.
F1 Data Define what data is carried in the Data Provider message when the F1 key is pressed.
Select Always Gross to transmit the gross value regardless of whether the Tare key has
been pressed.
Select As Displayed to transmit either the gross or net value depending on the currently
displayed data.
Remote Data Tags and IDs
Data Tag Enter the Data Tag of the message to use for the specified input item.
ID Enter the ID of the module used to supply the specified input item.
If you are not using Item mode then you are not required to enter the ID although it will be
filled in automatically if you pair to a module to retrieve its settings.
P Click this then perform pairing on a remote transmitter to automatically provide the ID and
Data Tag. Usually pairing is activated by removing and replacing the power supply on the
remote transmitter. You must perform pairing within 5 seconds of clicking the button.
X Click this to reset the Data Tag and ID to zero (disabling the input item).
Set Prompts For modules with a firmware revision of 1.2 and newer this button will be visible. This
displays a page where the message labels shown before switching between channels can be
set by the user.
MA-WIRELESS-T24-HA_EN.docx
If motion detection is configured then this key will have no effect while
the reading is not steady.
This is only necessary for Item Mode where individual items are to be
woken using the Wake key as opposed to letting the handheld wake all
modules.
