MA-WIRELESS-T24-HS_EN
WIRELESS-T24-HS
User Manual
Page 1 on 21
Rev: 09/05/2011
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for SENSY WIRELESS-T24-HS
Summary of Contents for SENSY WIRELESS-T24-HS
-
Page 1: Table Of Contents
User Manual 1. INTRODUCTION / OVERVIEW ................................2 1.1. Quick Start ....................................2 1.1.1. Connecting Power ................................2 1.1.2. Pairing ....................................2 1.1.3. WIRELESS-T24-HS Operation ............................3 2. CONFIGURATION ....................................4 2.1. Installation ....................................4 2.1.1. T24 Toolkit ..................................4 2.1.2. T24-BSu Base Station .................................4 2.2. T24 Toolkit ....................................5 2.2.1. -
Page 2: Introduction / Overview
− Ensure that acquisition module is not powered. − We need to turn on the WIRELESS-T24-HS in pairing mode. To do this we start with it turned off, then press and hold the power key then press and hold the Tare key. Now both keys are held down until PAIRING is seen on the display. -
Page 3: Wireless-T24-Hs Operation
Gross and Net are retained through power off. 1.1.1.4. Modes When you want to use the WIRELESS-T24-HS with a different acquisition module you use pairing. (Ensure that the acquisition module is unpowered for at least 10 seconds.) Press and hold the Power key then while still holding down the power key press and hold the Tare key. -
Page 4: Configuration
2. CONFIGURATION This section explains how to install software and connect the required devices together. Please note that you will need the T24 Toolkit software and a T24-BS base station to allow your computer to communicate with T24 telemetry devices. 2.1. -
Page 5: T24 Toolkit
2.2. T24 Toolkit The T24 Toolkit provides a means of simple configuration of the WIRELESS-T24-HS handheld and associated acquisition module along with useful tools to aid integration. Calibration of the acquisition module is also provided. Run the T24 Toolkit software application. -
Page 6: Home
2.2.2. Home We now have successful communications with the base station so we can now pair with our device or we can select the Spectrum Analyser mode or Data Provider Monitor mode. To connect to our device we will pair. This is achieved by power cycling the device. Pairing removes the need to know the radio settings of the device you are connecting to and also ensures that it is in a suitable state for configuration. -
Page 7: Analyser
2.2.3. Analyser The analyser page is provided as a tool and will not normally be needed unless you plan to change channels and want to find the best channel to select, or to diagnose poor communications issues. This page shows the radio signal levels detected across all the channels available to the T24 series of devices. -
Page 8: Data Provider Monitor
2.2.4. Data Provider Monitor T24 acquisition devices normally operate in low power mode and periodically transmit Data Provider packets This page shows all detected Data Provider packets which may be useful for checking that a device is operational. NOTE: When the toolkit connects to a device to enable configuration it will usually inhibit the transmission of Data Provider packets. -
Page 9: Information
2.2.5. Information Once successfully paired to a device this page is displayed. This page shows you information about the connected device. Items you can change: − Name : You can enter a short description which may help you recognise this device in the future. MA-WIRELESS-T24-HS_EN Rev: 09/05/2011 Page 9 on 21... -
Page 10: Zero Settings
Items you can change: − Power On Auto Zero : Here you can determine whether the WIRELESS-T24-HS performs automatic zero when it is powered on. Enter zero to disable this function. If you enter a non-zero value then when the handheld is first turned on it checks the value read from the acquisition module. -
Page 11: Display Format
2.2.7. Display Format Here you can adjust the display. Items you can change: − Format & Resolution : Here you can define how the values are displayed on the LCD. There are 7 digits available and you can define where the decimal point is shown by entering text where a zero indicates a numeric digit position. -
Page 12: Display Format Advanced Settings
2.2.8. Display Format Advanced Settings Here you can adjust the display update rate and also scale the displayed data. This may be used, for example, to convert the data from a T24-SA calibrated in Kgs so that the handheld display shows Lbs. Items you can change: −... -
Page 13: Channel And Encryption
2.2.9. Channel and Encryption Here you can change the channel and encryption key for the acquisition module. If you want to change the channel of an acquisition module and WIRELESS-T24-HS pair there is no need to change both devices. Simply pair to the handheld and change its channel and key. -
Page 14: Save And Restore
2.2.10. Save and Restore Here you can save the device settings to a file on your PC so that they can be later loaded back into the same or different device. Items you can change: − Save : Click this button to open a file dialog window to allow you to select a filename and location to save the configuration file to. -
Page 15: Advanced Settings
2.2.11. Advanced Settings You should not normally need to change these settings. Items you can change: − Waker Duration : When the handheld is turned on it may attempt to wake the paired acquisition module. This setting allows you to adjust the time it will wait to wake the remote device in milliseconds. The default is 12000. -
Page 16: Installation
3. INSTALLATION 3.1. Overview Radio performance at microwave wavelengths is very dependent upon the operating environment; any structure within the operating region of the radios will give rise to three effects: Obscuration: Obscuration will result in reduced range and occurs when an obstruction masks the line-of-sight between radios. -
Page 17: Antenna Orientation
3.2. Antenna Orientation For the maximum range the acquisition module and the WIRELESS-T24-HS should be orientated as shown. The sensitivity to the radio transmission will be reduced if the acquisition module is oriented in a vertical or portrait position. 3.3. Battery Use a pair of alkaline AA batteries. -
Page 18: Wireless-T24-Hs
4.2. WIRELESS-T24-HS Electrical Typical Units Power Supply voltage V dc Power Supply Typical Units Active Low power mode Estimated Battery life using 2Ahr batteries: Standby mode (Powered off) Years Continuous operation Hours Environmental Typical Units IP rating IP65 Operating temperature range... -
Page 19: Fcc
(2) this device must accept any interference received, including interference that may cause undesired operation. CAUTION: If the device is changed or modified without permission from SENSY Electronics Ltd, the user may void his or her authority to operate the equipment. -
Page 20: Oem / Reseller Marking And Documentation Requirements
Section 15.247 (emissions). Acquisition modules have been certified by the FCC for use with other products without any further certification (as per FCC section 2.1091). Changes or modifications not expressly approved by SENSY could void the user’s authority to operate the equipment. -
Page 21: Worldwide Regional Approvals
To Be Determined 7.1. Important Note SENSY does not list the entire set of standards that must be met for each country. SENSY customers assume full responsibility for learning and meeting the required guidelines for each country in their distribution market.
