- Page 1 FSF207 INSTRUCTION MANUAL We’ll Make It Stress-Free If you have any questions along the way, just give us a call. 1-800-359-5520. We’re ready to help! Scan for easy install video san.us/1125...
- Page 2 Does your TV weigh more than 25 lbs. (11.3 kg) including accessories? No — Perfect! 25 lbs. Yes — This mount is NOT compatible. Visit vuepoint.sanus.com or call 1-800-359-5520 (UK: 0800-056-2853) to fi nd a (11.3 kg) compatible mount. Drywall...
- Page 3 Dimensions TV INTERFACE 7.87in 200mm NOTE: TV shifts 4.27 in. (108.6 mm) to the right or left when in the home position. 3.94in 100mm Consider this when selecting the location of your wall mount. .35in 7.87in 8.8mm 200mm WALL PLATE TOP VIEW - EXTENDED SIDE VIEW - EXTENDED 7.59in...
-
Page 4: Step 1 Attach Bracket To Tv
STEP 1 Attach Bracket to TV STEP 1 Parts and Hardware WARNING: This product contains small items that could be a choking hazard if swallowed. Before starting assembly, verify all parts are included and undamaged. If any parts are missing or damaged, do not return the damaged item to your dealer;... - Page 5 STEP 2 Parts and Hardware STEP 3 Hardware Wall Plate Template Wall Plate Assembly Locking Screw WELCOME AND THANKS FOR CHOOSING SANUS VUEPOINT GET STARTED THIS IS YOUR DRILLING YOU’RE REALLY GOING WITH STEP 1 TEMPLATE FOR STEP 2 TO ENJOY STEP 3...
- Page 6 Hardware for STEP 2B Concrete Installation Hardware for STEP 2C Steel Stud Installation [CMK2 Kit is NOT INCLUDED] [Steel Stud Anchor Kit is NOT INCLUDED] Contact Customer Service at 1-800-359-5520 to have these Contact Customer Service at 1-800-359-5520 to have these additional pieces shipped directly to you.
- Page 7 Blank Page...
- Page 8 STEP 1 Attach TV Bracket to TV 1-1 Measure Your TV Hole Pattern 1-2 Assemble Your TV Bracket Measure the width and height of your TV hole pattern in cm. Determine which TV bracket configuration to use, A, B, or C based on your TV hole pattern measurements.
- Page 9 20.0 x 10.0 20.0 x 20.0 20.0 20.0 10.0 20.0 Assemble TV bracket extenders onto TV bracket Assemble TV bracket extenders onto TV bracket illustrated. illustrated. Secure using eight screws in the corner holes shown. Secure using eight screws in the corner holes shown.
- Page 10 1-3 Select TV Screw 1-4 Select TV Screw Length Standard configurations Diameter are shown. For special If your TV has a flat back AND you want your TV closer to applications, or if you Hand thread screws into the the wall, use the shorter screws. are uncertain about your threaded inserts on the back hardware selection,...
- Page 11 1-5 Attach TV Bracket Position your TV bracket configuration (A, B, or C) over your TV hole pattern - making sure the bracket is centered over the TV hole pattern and level. CAUTION: Avoid potential personal injuries and property damage! DO NOT use power tools for this step. Tighten the screws only enough to secure the TV bracket to the TV.
- Page 12 STEP 2A Attach Wall Plate to Wall Wood Stud Option CAUTION: Avoid potential personal injuries and property damage! ● Drywall covering the wall must not exceed 5/8 in. (16 mm) ● Minimum wood stud size: common 2 x 4 in. (51 x 102 mm) nominal 1½ x 3½ in. (38 x 89 mm) Locate your stud.
- Page 13 Install wall plate assembly using two lag bolts and two washers . Tighten the lag bolts only until they are pulled firmly against the wall plate. NOTE : If needed, you can make small level adjustments to the wall plate by loosening the bottom lag bolt and shifting the wall plate until level.
- Page 14 STEP 2B Attach Wall Plate to Wall Solid Concrete or Concrete Block Option CAUTION: Avoid potential personal injuries and property damage! Concrete Installation Kit CMK2 is not ● Mount the wall plate assembly directly onto the concrete surface included (see page 6) Contact Customer ●...
- Page 15 and insert two anchors C1 Remove the wall plate template (Fischer UX 10 x 60 - included in the Concrete Installation Kit*see page 6). CAUTION: Be sure the anchors C1 are seated flush with the concrete surface. using two lag bolts C3 and two washers C2 (use only the lag bolts and washers from the Concrete Install wall plate Installation Kit*).
- Page 16 STEP 2C Attach Wall Plate to Wall Steel Stud Installation Steel Stud Anchor Kit SSMK1 is not included (see page 6) Contact Customer Service at 1-888-333-9952 to have the additional hardware shipped directly to you. Min. Locate stud. 1/2 in. (13 mm) Level the wall plate template and mark the hole locations.
- Page 17 Drill pilot holes as illustrated. Fold metal channel of anchor S1 until it is flat with the plastic straps and slide the metal channel into the drilled hole. 25 mm (1 in.) 13 mm (1/2 in.)
- Page 18 Hold the plastic straps of anchor S1 by the end and pull towards you until the metal channel is flush behind the drywall. Slide the plastic cap down the straps and into the hole with the lip of the cap flush against the wall.
- Page 19 Bend the straps up and down until they snap off level with the lip of the cap. CAUTION: Be sure the cap is seated against the drywall surface and the ends of the anchor do not extend beyond the cap - cut if neccessary.
- Page 20 STEP 3 Hang TV onto Wall Plate HEAVY! You may need assistance with this step. Hang the TV onto the arm of wall plate assembly by first hooking the top support, then resting the TV into place. Lock the TV to the wall plate assembly with locking screw and washer CAUTION!
