2-6 Getting Started Guide
Netopia 3341-ENT ADSL Router Status Lights
The figure below represents the Netopia 3341-ENT status light (LED) panel.
Netopia 3341-ENT status indicator lights
Ethernet Link: Solid
Ethernet Traffic: Blinks
over the Ethernet
DSL Traffic: Blinks
DSL Sync: Blinking
solid
USB Active: Solid
Power: Solid
green
green
when Ethernet link is established
green
when traffic is sent or received
green
when traffic is sent/received over the WAN
green
with no line attached or training,
green
when trained with the DSL line
green
when the USB is connected
when the power is on
