Netopia 3341-ENT back panel
.
Port
DSL port An RJ-48 jack labeled DSL for your ADSL connection.
Ethernet port An RJ-45 10/100Base-T Ethernet jack. You can use this to configure the Netopia
3341-ENT. For a new installation, use an Ethernet connection. You can either connect
your computer directly to the Ethernet port using the supplied Category 5 Ethernet
cable, or connect both your computer and the Netopia 3341-ENT to an existing LAN
environment. The Ethernet port is auto-sensing, eliminating the need for a crossover
cable.
USB port A Universal Serial Bus port for a direct connection to the Telnet screens. You can use
this as an alternative to an Ethernet connection.
Power port A DC power adapter cable connection.
DSL port USB port
Ethernet
port
Description
Making the Physical Connections 2-5
Power switch
Power port
