Installation and Connections
Terminal Description
+5Vref +5.0V reference output, 50mA maximum
+5Vref +5.0V reference output, internally connected to above
Ain1 Analog Input 1 (0-5V) or Differential Ain1+
Ain2 Analog Input 2 (0-5V) or Differential Ain1-
Agnd Analog Ground
Ain3 Analog Input 3 (0-5V) or Differential Ain3+
Ain4 Analog Input 4 (0-5V) or Differential Ain3-
Agnd Analog Ground
Ain5 Analog Input 5 (0-5V) or Differential Ain5+
Ain6 Analog Input 6 (0-5V) or Differential Ain5-
Agnd Analog Ground
Ain7 Analog Input 7 (0-5V) or Differential Ain7+
Ain8 Analog Input 8 (0-5V) or Differential Ain7-
Agnd Analog Ground
Page 8
12-Pin Connector Pinout
