X-16s™ Users Manual

Appendix A: Specifications

Power Requirements
Input Voltage: 9-28 VDC (power is supplied via the expansion bus cable, 24V recommended)
Current:
Power Supply Current
9 VDC
12 VDC
24 VDC
Analog Inputs
Number of Inputs:
Input Range:
Conversion Method:
Resolution:
Maximum Inaccuracy:
Input Offset Voltage:
Input Bias Current:
Conversion Rate:
Reference Output
Voltage:
Current:
Accuracy:
Temperature Coefficient:
Connector
Type:
Connection wire:
Stripping Length:
Connection capacity:
Conductor minimum:
Conductor maximum:
Conductor Type:
Tightening torque:
(Replacement part number, Phoenix Contact 1803691)
Expansion Connector:
Connector:
Communications:
LED Indicators
Green:
Environmental
Indoor use or NEMA-4 protected location
Xytronix Research & Design, Inc.
See table below for typical values at 25°C
40 mA
30 mA
18 mA
8 single-ended, 4-differential, or a combination
0 - 5V [(-0.1V (min), 5.1V (max)] all channels
24-bit, ∑∆ ADC
10µV
±0.075% full scale
10µV
350nA
7 Hz
5.00V
50mA max
0.04%
3ppm/°C Max
14-position, removable, 3.81 mm pitch
Use wire rated for 75ºC (min) for connections to the terminal blocks
7mm
1.5mm 2 stranded, 1.5mm
30AWG (UL/CUL)
14 AWG (UL/CUL)
Copper
0.22 Nm (min), 0.25 Nm (max)
Ribbon cable, 2x5-position, polarized 0.100" pitch
RS-485
Power On
2 solid
