Cayman 2E-W User's Guide
November 2000
set ip ethernet [ A | B ] rip-receive-keyid keyid
Specifies the key that will be used to authenticate all incoming RIP
packets if
is selected for
v2-MD5
receives a RIP packet, it uses the expected key to create an MD-5
digest of the RIP message. It then compares this calculated digest to
the MD-5 digest sent with the RIP packet. If the calculated digest
does not match the received digest, the RIP message is discarded. If
the two digests match, the packet is processed as a normal RIP-2
packet.
IP authentication keys can be 1-16 characters long, and can include
spaces and special characters. You must enclose the authentication
key string in double quotes ("").
Default IP Gateway Settings
set ip gateway option { on | off }
Specifies whether the Cayman 2E-W should send packets to a default
gateway if it does not know how to reach the destination host.
set ip gateway interface { ip-address | ppp }
Specifies how the Cayman 2E-W should route information to the
default gateway. If you select
address of a host on a local or remote network. If you specify
the Cayman 2E-W uses the default gateway being used by the remote
PPP peer.
set ip gateway default ip_address
Specifies the IP address of the default IP gateway.
WAN-to-WAN Routing Settings
Use the following command to configure settings for routing
between WAN connections.
set ip interwan-routing { on | off }
Enables or disables routing between WAN connections.
. When your Cayman 2E-W
rip-send
, you must enter the IP
ip-address
Using the Command Line Interface
,
ppp
4-25
