Data Enable - Wavetronix Click 111 Using Manual

Off On
Off On
On Off
On Off
All others
If any of the switches are on (flipped up), Hardware mode is selected, meaning the channel allocation will
be configured using the DIP switches, and Click Supervisor and the front panel menu will be able to display
the current setting, but not change it. If all switches are off (down), Software mode is selected and only Click
Supervisor and the front panel menu will be able to both display and change the current setting.

Data Enable

Also on this switch is the data enable parameter. This is configured on the third DIP switch, labeled S3, using
switches 6–8 (S3:6–8).
Note. This parameter can also be changed using the front panel menu or Click Supervisor.
This group of DIP switches determines whether the data buses are enabled to receive contact closure data. Each
bus can be independently enabled or disabled.
This parameter may be useful if you know a bus will not be receiving any data—for instance, if you're only using
one sensor with your Click 111. If a bus is disabled from receiving data, then its associated channels will not go into
a fault state, even if that bus is not receiving any data.
Note. If you've disabled a bus from receiving data, you can still use it to configure the card using Click Supervisor.
6
Off
On
–
–
–
–
Dashes in the table indicate that the state of those switches don't affect that particular setting.
If switch 6 is on (flipped up), Hardware mode is selected, meaning that the data enable parameter will be
configured using the DIP switches, and Click Supervisor and the front panel menu will be able to display the
current setting, but not change it. If switch 6 is off (down), Software mode is selected and only Click Supervisor
and the front panel menu will be able to both display and change the current setting.
Warning. If you don't have switch 6 on (flipped up) to set it to Hardware mode, anything you set on switches 7 and
8 will be ignored by the Click 111.
WX-501-0552 • 01.22
On
On
Off
Off
S3: Data Enable
7
–
–
Off
On
–
–
Off 6
On 4
Off 2
On 0
8
8
–
–
–
–
Off
On
10
12
14
16
8
State
Software mode
Hardware mode
Bus 1 disabled
Bus 1 enabled
Bus 2 disabled
Bus 2 enabled
