BP-6010
Bp-6010-CH
ESOK
Owners Manual
w w w . g r o w o n i x . c o m
Built in the U.S.A.
1
www.growonix.com
toll free 888.406.8521, office 818.510.0264, sales@growonix.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BP-6010 and is the answer not in the manual?

Questions and answers

Related Manuals for Growonix BP-6010

Summary of Contents for Growonix BP-6010

  • Page 1 BP-6010 Bp-6010-CH ESOK Owners Manual w w w . g r o w o n i x . c o m Built in the U.S.A. www.growonix.com toll free 888.406.8521, office 818.510.0264, sales@growonix.com...

  • Page 2: Our Mission

    Traditional RO systems have waste ratios of approximately 4:1, which means there are 4 gallons of waste water produced for every 1 gallon of purified water. GrowoniX line of water filters achieve waste ratios of 2:1 with all 200-400 GPD systems, and an astounding 1:1 ratio with the 600-1000 GPD systems.
  • Page 3 Membranes love pressure! In general, more pressure allows for better membrane rejection, longer life, and increased flow rate. GrowoniX BP-6010 Series Booster Pumps allow for the full potential performance of an RO system to be acheived—with only 35 PSI of incoming water pressure.

  • Page 4: Basic Information

    READ ENTIRE MANUAL THOROUGHLY BEFORE INSTALLING THIS HIGH PRESSURE-BOOSTING PUMP. ABOUT The BP-6010 series of Booster Pumps are designed for use with all GrowoniX EX1000 & GX1000 • water filters. The pump is designed to boost low water pressure conditions to optimal pressure.

  • Page 5: Plumbing And Electrical

    The output is 3/8” OD tubing. the ESOK is 3/4” or 1”. • CAUTIONS Do not use garden hose fittings or attachements when using a BP-6010 series pump, especially • when using an ESOK (electric shutoff kit). It is only recomended to plumb he RO system with appropriate SCH40/80 PVC, copper, or CTS pipe suitable to pass local plumbing inspections in your area.
  • Page 6 Mounting O CXA-S1 15-80 (1.0-5.5) 15-30 (1.0-2.1) 129 (8.9) BP-6010 INFORMATION Setpoint Ad CXA-S2 30-100 (2.1-6.9) 20-35 (1.4-2.4) 179 (12.3) Weight: 0.7 CXA-S3 35-150 (2.4-10.3) 30-40 (2.1-2.8) 204 (14.1) CXA-R1 15-80 (1.0-5.5) 15-30 (1.0-2.1) Deadband: 129 (8.9) CXA-R2 30-100 (2.1-6.9) 20-35 (1.4-2.4)

  • Page 7: Component Diagram

    COMPONENT DIAGRAM 1. Motor 2. 1/2” Pump Input (connection to pre filter housing output) 3. 3/8” Pump Output (connection to membrane input) 4. Output Pressure Gauge 5. Low Pressure Switch 6. Pump Pressure Bypass Adjustment 7. Pump Power On/Off Switch 8.
  • Page 8 SETUP INSTRUCTIONS FOR BP-6010 IMPORTANT TIPS: TURN OFF INCOMING WATER SUPPLY AND DRAIN SYSTEM PRESSURE BEFORE INSTALLING A BP-6010 PUMP Slide the 1/2” locking clip off of the Insert the supplied 1/2” tubing into the carbon filter output fitting, and remove carbon filter output.
  • Page 9 Cut the 3/8” tubing to the appropriate length (ensure no kinks or flow restrictions), and install the 1/2” x 3/8” stem reducer onto the 3/8” tubing. Insert the stem reducer into the 1/2” membrane input fitting. Complete assembly as shown, with red locking clips in the correct places.
  • Page 10 SETUP INSTRUCTIONS FOR BP-6010-CH TURN OFF INCOMING WATER SUPPLY AND DRAIN SYSTEM PRESSURE BEFORE INSTALLING A BP-6010 PUMP Attach BP-6010-CH chassis to Install the caster onto the chassis GX600/1000 housing using the bottom. existing caster hardware. Slide the 1/2” locking clip off of the carbon filter output fitting, and Insert the supplied 1/2”...
  • Page 11 Attach BP-6010-CH chassis to GX600/1000 housing. Replace caster nut and washer and tighten. Cut the 3/8” tubing to the appropriate length (ensure no kinks or flow restrictions), and install the 1/2” x 3/8” stem reducer onto the 3/8” tubing. Insert the stem reducer into the 1/2”...
  • Page 12 PUMP OUTPUT PRESSURE ADJUSTMENT BP-6010 PUMP BP-6010-CH PUMP The bypass valve, located on the input side of the pump can be used to regulate pump output pressure. It is adjustable with a flat head screwdriver. WHILE REFERENCING THE PUMP PRESSURE GAUGE: 1.
  • Page 13 ELECTRIC SHUT OFF KIT COMPONENT DIAGRAM direction of flow 1. SOLENOID VALVE 2. FLOAT BALL SWITCH 3. FLOAT BALL PIGGYBACK CORD 4. SOLENOID VALVE MANUAL OVERRIDE SWITCH 5. SOLENOID VALVE (DIRECTION OF FLOW) SOLENOID MANUAL OVERRIDE SWITCH NORMAL MANUAL OPERATION OVERRIDE Built in the U.S.A.
  • Page 14 (ESOK) ELECTRIC SHUT OFF KIT CONNECTION DISCONECT PUMP AND ALL COMPONENTS FROM ELECTRICAL SUPPLY, AND TURN OFF FEED WATER SUPPLY BEFORE CONNECTING THE ESOK. INSTALLING THE SOLENOID VALVE 1. Remove the garden hose fitting from the water filter input and attach the supplied SCH80 PVC as shown above.
  • Page 15 (ESOK) WIRING DIAGRAM ESOK ELECTRICAL CONNECTION 1. Attach the float ball piggyback cord to the male plug end from the pump control box.(2) The float switch will now govern whether current will flow to the pump control box or not. 2.

  • Page 16: General Conditions

    GROWONIX SYSTEM WARRANTY For a period of one year from the date of original purchase, we will replace or repair any part of the GrowoniX product that we find to be defective in operation due to faulty materials or workmanship with the exception of the replaceable filters and membranes.
