- Page 1 BP-1530 Booster Pump Owners Manual w w w . g r o w o n i x . c o m www.growonix.com toll free 888.406.8521, office 818.510.0264, sales@growonix.com...
- Page 2 BP-1530 SYSTEMS FEATURES pressure allows for better emembrane rejection, longer membrane life, and increased membrane Continuous duty cycle flow rate. GrowoniX BP-6010 Series Booster Adjustable output pressure Pumps allow for the full potential performance of the RO membrane to be acheived—with...
- Page 3 Traditional RO systems have waste ratios of approximately 4:1, which means there are 4 gallons of waste water produced for every 1 gallon of purified water. GrowoniX line of water filters achieve waste ratios of 2:1 with the EX100 through GX400 and an astounding 1:1 ratio with the GX600 and GX1000.
- Page 4 INFORMATION ON QUICK CONNECT FITTINGS GROWONIX WATER FILTERS USE QUICK CONNECT FITTINGS THAT ALLOW FOR EASY MAINTENANCE. MAKE A CLEAN TUBE CUT Cut the tube squarely and if using plastic tubing, ensure that the cut has not made the tube out of round.
- Page 5 IF ADDITIONAL HELP IS NEEDED, PLEASE CONSULT THE FACTORY. ABOUT The GX150/300 Booster Pump is designed for use with all GrowoniX water filters 600 GPD and under. • The pump is designed to boost low water pressure conditions to optimal pressure.
-
Page 6: Flow Rates
FLOW RATES 100GPD — 400GPD FILTER FLOW RATES EX/GX400-HF, 77ºF EX/GX400-HF, 60ºF EX/GX400-HF, 50ºF EX/GX200-HF, 77ºF EX/GX200-HF, 60ºF EX/GX200-HF, 50ºF EX100-HF, 77ºF EX100-HF, 60ºF EX100-HF, 50ºF WATER PRESSURE (PSI) WITH OR WITHOUT PUMP 600GPD — 1000GPD FILTER FLOW RATES 2800 2600 EX/GX1000-HF, 77ºF 2400... -
Page 7: Replacement Parts
EX400-tall, Slim Scrub 71.00 Must for well water and chloramine removal 5,700 Gallons RO Water 34,000 Gallons Total CF-4520-KDF Premium Carbon EX600/1000-Tall, XL Scrub 127.00 Must for well water and chloramine removal 17,000 Gallons RO www.growonix.com toll free 888.406.8521, office 818.510.0264, sales@growonix.com... - Page 8 BP-1530 BOOSTER PUMP COMPONENT DIAGRAM 1. MOTOR 2. PUMP INLET 3. PUMP OUTLET 4. PRESSURE SWITCH 5. ADJUSTABLE INTERNAL BYPASS 6. POWER TRANSFORMER READ ENTIRE MANUAL THOROUGHLY BEFORE INSTALLING THIS PRESSURE-BOOSTING PUMP...
- Page 9 BP1530 ASSEMBLY DIAGRAM www.growonix.com toll free 888.406.8521, office 818.510.0264, sales@growonix.com...
-
Page 10: Setup Instructions
SETUP INSTRUCTIONS input input output Make note of direction of flow prior to Connect feed water tubing to pump installation. input. output Insert output tubing into pump output. Insert output tubing into RO filter input. -
Page 11: Pressure Switch
PRESSURE SWITCH Install the pressure switch on the product water line (RO out tubing) after the auto-shutoff valve. The switch can be installed in any direction. FIG. 1 PRESSURE SWITCH (PSW) www.growonix.com toll free 888.406.8521, office 818.510.0264, sales@growonix.com... - Page 12 ADJUSTABLE INTERNAL BYPASS The BP-1530 Booster Pump is equipped with an adjustable internal bypass valve, which controls the maximum operating pressure. The valve is located in the center of the triangular cap on the top of the pump head, between the input and output ports. To adjust, insert the included 1/16” Allen Wrench into Increase the chrome adjustment screw.
- Page 13 Allows for removal of the standard drain/flush assembly. 4.5”x9.75” | 16000 gallons Mounts atop the GX series chassis for easy viewing and adjusting. Easy wall mounting as well. www.growonix.com toll free 888.406.8521, office 818.510.0264, sales@growonix.com...
- Page 14 GROWONIX REVERSE OSMOSIS SYSTEM WARRANTY For a period of one year from the date of original purchase, we will replace or repair any part of the GrowoniX reverse osmosis water system that we find to be defective in operation du e to faulty materials or workmanship with the EXception of the replaceable filters and membranes.
