  • Page 1 Audio Products XAP TH2 Telephone Interface Installation & Operation Manual...
  • Page 2 XAP TH2 Telephone Interface Installation & Operation Manual...
  • Page 3 © 2002 ClearOne Communications, Inc. All rights reserved. No part of this document may be reproduced in any form or by any means without written permission from ClearOne Communications. Printed in the United States of America. ClearOne Communications reserves specific privileges.

  • Page 4: Table Of Contents

    To add a XAP TH2 to a site file ....... .
  • Page 5 To sync site file to the XAP TH2 ....... . .16...

  • Page 6: Chapter 1: Introduction

    It continually filters low and high frequency noise to provide pure sound. The XAP TH2 is designed to function as a stand-alone telephone hybrid or as an accessory to the XAP 800 (echo cancelling, audio processing, microphone mixing matrix), enabling you to add remote callers to your audio conferences.

  • Page 7: Professional Services Group

    E-mail: global@clearone.com Product registration Please register your XAP TH2 online by visiting ClearOne Technical Support at www.clearone.com. When your product is properly registered, ClearOne Communications is better able to serve you should you require technical assistance. Registration information is also used to notify you of upgrades and new product information.

  • Page 8: Unpacking

    ON state. Pressing and holding the On button for more than a D. On. The On button connects the XAP TH2 to the telephone line and half-second while automatically adapts the hybrid to the line.

  • Page 9: Rear Panel

    XAP TH2. See page 8 for more details. G. Expansion Bus In, Out. This RJ-45 connector is used to connect the XAP TH2 to the XAP 800 for control. G-Ware is capable of accessing and controlling an expansion bus local area network (LAN) of up to eight XAP 800/PSR1212 units and 16 XAP TH2 units, where the total number of microphone inputs does not exceed 64.

  • Page 10: Before You Install

    XAP TH2 units, where the total number of microphone inputs does not exceed 64. The maximum distance between interconnected XAP 800/400 or PSR1212 units is 80 feet (24 meters). Insertion of a XAP TH2 must not increase the cable length between two PSR1212s, XAP 800s and/or XAP 400s beyond 80 feet. ClearOne recommends that category five twisted-pair (10BaseT LAN) cable be used.
  • Page 11 Technical Services Group ~ 1-800-283-5936 (USA) ~ 1-801-974-3760...

  • Page 12: Chapter 2: Installation

    CHAPTER 2: Installation Hardware Setup The XAP TH2 is designed for easy installation and setup. All connections are made through rear-panel connectors. This section provides instructions on installing the units in the rack and making initial connections, assigning device ID numbers, and creating an expansion bus (E-bus) network.

  • Page 13: Assigning Device Id Numbers

    Assigning device ID numbers Before creating an expansion bus network, you need to set up unique expansion bus Device ID numbers for each XAP TH2 on the network. There are 16 expansion bus If more than one XAP TH2 network device locations that can be selected (0-F). As shipped from the factory, all is assigned the same device XAP TH2 units default as binary address 0.

  • Page 14: Creating An Expansion Bus Network

    1 ( DOWN) 1 (DOWN) Creating an expansion bus network Place the XAP TH2 unit in the rack. The back-panel Expansion Bus In and Expansion Bus Out connectors are designed for setting up your expansion bus network. Connections between units are made in daisy-chain fashion using category five twisted-pair cable.

  • Page 15: Connecting Power

    XAP 800/400 and PSR1212 units is 80 feet (24 meters). Connecting power The power input [A] will operate at any level between 100–240VAC, 50–60Hz, 15W (typical). Plug in the XAP TH2 to complete the hardware installation. Technical Services Group ~ 1-800-283-5936 (USA) ~ 1-801-974-3760...

  • Page 16: Chapter 3: Configuration

    Unit(s) You can add XAP TH2(s) to your site file by connecting to your networked site and Document. If you sync to the letting G-Ware automatically create icons for the detected units. Or you can work...
  • Page 17 PC, or AMX touch panel. Click OK to save settings and close the Unit Properties window. You will need to repeat this process for all XAP TH2 units on your network. Figure 3.4. Unit Properties Security tab...

  • Page 18: Telco Configuration

    Telco Configuration XAP TH2 Flow Screen The XAP TH2 Flow Screen shows a detailed block diagram of the audio path in relation to the TH2. There are four buttons on the Flow Screen: Dial, Telco Config, Telco Meters, and GPIO builder. The Flow Screen is displayed for the selected unit in the site panel on the left of the G-Ware screen.
  • Page 19 ALC can be turned on or off. The default setting is on. Edit Speed Dial The XAP TH2 supports 10 speed dial numbers. Each number can be 40 digits long and can have a 20 character label associated with it. These numbers and labels are stored in non- volatile memory and the number can be called by a single command.

  • Page 20: Creating Custom Control

    To use GPIO Builder GPIO, or general purpose input/output, allows you to establish pin assignments for the XAP TH2's Control/Status port. These pins provide control via contact closure and status via open collector functions in the unit. Open the GPIO Builder by clicking the GPIO Builder button on the Flow Screen.

  • Page 21: Synchronizing Site Files

    Establish a direct serial connection from you PC to the XAP 800 units with the configurations you which is linked to the XAP TH2(s) via the E-bus have saved in the site file. Click the Connect button on the G-Ware toolbar or select Connect from the Connect menu.

  • Page 22: Chapter 4: Operation

    CHAPTER 4: Operation The XAP TH2 has four basic functions: make a call, answer a call, disconnect a call, and mute. This chapter explains how to perform these functions with the TH2 unit and a telephone handset (optional) and with the Dial interface in G-Ware. You can also use touch panels and custom control devices.

  • Page 23: Using The Dial Interface

    When the conversation is complete, press the Off button [E] to disconnect auto-answer, the XAP TH2 the call. You can also disconnect using an external controller. If the handset will connect to the call is off hook, audio will be routed to the telephone.
  • Page 24 Re-Null. Sends a short noise seizure, allowing options such burst down the telephone line as 3-way calling, call waiting, and forces the XAP TH2 to and call hold. This feature is adapt to the telephone line for dependent on the services...

  • Page 25: Controllers

    XAP products can be accessed and controlled from that single point. The controller can also be connected directly to the XAP TH2 RS-232 port. Using an external controller, the XAP TH2 can be turned on or off; transmit and receive audio can be muted; DTMF tones can be generated (see Serial Commands, page 28);...

  • Page 26: Chapter 5: Optimization

    CHAPTER 5: Optimization Adjusting Levels In order to optimize the audio levels, you will need to place a call on the XAP TH2. This will enable you to evaluate the levels for caller audio, audio being sent to the telephone, dial tone, DTMF tone, audible hook indication, and audible ring indication.

  • Page 27: Adjusting Transmit Audio

    To increase or decrease audio being sent to the telephone line, adjust the output gain on the XAP 800 output channel that is connected to the XAP TH2 Transmit Input. This will affect only the audio being sent to the telephone on that channel. See the XAP 800 manual or G-Ware help file for detailed instructions.

  • Page 28: Telco Meters

    Telco Meters Using meters Open the XAP TH2 Telco Meters window by clicking the Telco Meters button on the XAP TH2 Flow Screen. The Telco Meters window is a diagnostic tool which allows you to observe the performance of various aspects of XAP TH2 operation. Refer to the Transmit and Receive meters when making level adjustments.
  • Page 29 DAA. The range of the meter is -30 to +20dB. Receive Input This meter shows the audio level input to the XAP TH2 as it is received from the Telco DAA. The range of the meter is -30 to +20dB.

  • Page 30: Appendices

    APPENDICES Appendix A: Specifications Dimensions (LxDxH) RS-232 Receive Output 17.25" x 10.25" x 1.75" DB-9 female Push-on terminal block, balanced 43.8 x 26 x 4.5 cm 9,600/19,200/38,400 Impedance: <50Ω (default)/57,600 baud rate; 8 bits, Nominal Level: 0dBu Weight 1 stop, no parity Maximum Level: 19dBu 7 lb/3.18 kg dry Hardware flow control...

  • Page 31: Appendix B: Pinouts

    Appendices ~ Appendix B: Pinouts Appendix B: Pinouts Remote connector pinout Definable Type Default Description Control (Input) Telco On Status (Output) Telco On Indicator Control (Input) Telco Off Status (Output) Telco Off Indicator Control (Input) Status (Output) Control (Input) Status (Output) Control (Input) Transmit Mute Status (Output)
  • Page 32 Appendices ~ Appendix B: Pinouts RS-232 COM port pinout Description Description Not used Ground Set connector pinout Description Description To pin 6 of SET RJ-11C To pin 5 of SET To pin 2 of LINE Ring To pin 1 of LINE RJ-11C Line connector pinout Description Description...

  • Page 33: Appendix C: Serial Commands

    A command to enable auto-answer on the XAP TH2 device “0” would have the command line: #60 AA 1 1. In this command line, 6=XAP TH2, 0=unit 0, AA=command, 1=Telco channel 1, 1=on state. If a command calls for a “null” value, leave a blank in the command line. For example, #60 AA would return the current auto-answer state on device 60.
  • Page 34 (mic inputs). The following table shows the alpha representations for the different groups and the channels that are available for each product. Type and device IDs Type ID Unit type Device ID range PSR1212 0–7 XAP 800 0–7 XAP TH2 0–F XAP 400 0–7 Technical Services Group ~ 1-800-283-5936 (USA) ~ 1-801-974-3760...
  • Page 35 Appendices ~ Appendix C: Serial Commands Meter type definitions Serial command error codes Error number Text message Explanation/Solution Memory error The box is out of internal memory. Power cycle the box. No command found A command was not found in the string. Unknown command A command was executed on a different device type that this box response...
  • Page 36 Selects/reports the title screen inactivity time MINIT Sets/reports modem initialization string of serial port Reports unit ID (read only) MUTE Sets/reports mute status Reports unit version (read only) NULL Renulls the XAP TH2 to the telephone line Technical Services Group ~ 1-800-283-5936 (USA) ~ 1-801-974-3760...
  • Page 37 See Groups and Channels on page 29 Value 0 = Off, 1 = On, 2 = Toggle Example: #61 AA 1 1 On XAP TH2 unit 1 (#61), auto-answer (AA) for telco channel (1) is set on (1). ACONN - Audible Connect / Disconnect Indication This command selects/reports the status of the audible connect/disconnect indication.
  • Page 38 0 = Off, 1 = On, 2 = Toggle (Null to query in text) Example #62 ALC 1 1 On XAP TH2 unit 2 (#62), the automatic level control (ALC) for the hybrid (1) is on (1). BAUD - Baud Rate This command selects/reports the baud rate of the serial port.
  • Page 39 Description Value See Type and Device IDs, page 29 (Null to query in text) Example: #63 DID 0 On XAP TH2 unit 3 (#63), the device ID (DID) is set to 0. Technical Services Group ~ 1-800-283-5936 (USA) ~ 1-801-974-3760...
  • Page 40 Value -12.00 – 12.00 (Null to query in text) Example: #62 DTMFLVL 1 6 On XAP TH2 unit 2 (#62), the DTMF tone level (DTMFLVL) is set to 6dB. DTONELVL - Dial Tone Level This command selects/reports the audible dial tone’s level.
  • Page 41 Name Description Channel See Groups and Channels, page 29 Example: #65 HOOK 1 On XAP TH2 unit 5 (#65), send a HOOK flash to the hybrid (1). HOOKD - Hook Flash Duration This command selects/reports the hook flash duration. Command form: DEVICE HOOKD <Channel> [Value]...
  • Page 42 Value -99.99 – 99.99 (Sent with Null in text, Value returned) Example: #61 LVL 1 T I This will return the level of the telco input on XAP TH2 unit 1. LVLREPORT - Level Report This command selects/reports the status of level reporting for the specified channel.
  • Page 43 Value 0 = Off, 1 = On, 2 = Toggle (Null to query in text) Example: #67 MDMODE 1 On XAP TH2 unit 7 (#67), the modem mode (MDMODE) is on (1). MINIT - Modem Initialization String This command sets/reports the modem initialization string of the serial port when in modem mode.
  • Page 44 Value 1–80 Characters CLEAR = Clear current value Null = Current value Example: #63 PRGSTRING 2 MUTE On XAP TH2 unit 3 (#63), string location 2 is programmed (PRGSTRING) with MUTE. Supported special characters \a = alert \b = backspace...
  • Page 45 See Groups and Channels, page 29 Group 17 (R) Example: #60 REDIAL 1 On XAP TH2 unit 0 (#60), the hybrid (1) will redial the last number dialed. RING - Ring Indication This command indicates a ringing line. This command is reportable only. It cannot be queried or set.
  • Page 46 0 = Off, 1 = On, 2 = Toggle (Null to query in text) Example: #64 RXBOOST 1 6 On XAP TH2 unit 4 (#64), the receive boost (RXBOOST) of the hybrid (1) is set to 6dB. Technical Services Group ~ 1-800-283-5936 (USA) ~ 1-801-974-3760...
  • Page 47 Value 0 = Off, 1 = On, 2 = Toggle, (Null to query in text) Example: #65 RXRD 1 0 On XAP TH2 unit 5 (#65), the receive reduction (RXRD) for the hybrid (1) is off (0). SERECHO - Serial Echo This command selects/reports the serial echo of the RS-232 port.
  • Page 48 Value 1 – 10 (Null to query in text) Example: #61 SPEEDDIAL 1 5 On XAP TH2 unit 1 (#61), SPEEDDIAL the hybrid (1) with the number stored in location 5. STOREDIAL – Store a number as a Speed Dial This command saves a number in a speed dial or reports the current value.
  • Page 49 0 = Off, 1 = On, 2 = Toggle (Null to query in text) Example: #63TE 1 1 On XAP TH2 unit 3 (#63), set the telco enable (TE) of the hybrid (1) on (1), off hook. TERL - Telco Echo Return Loss This command reports the Telco echo return loss.
  • Page 50 0–F or * to select all units Command Value Null to return value Example: #64 VER 1.0.0 The version of the firmware (VER) programmed into XAP TH2 unit 4 (#64), is 1.0.0. Technical Services Group ~ 1-800-283-5936 (USA) ~ 1-801-974-3760...

  • Page 51: Appendix D: Warranty

    Appendices ~ Appendix D: Warranty Appendix D: Warranty ClearOne Communications (Manufacturer) warrants that this product is free of defects in both materials and workmanship. Should any part of this product be defective, the Manufacturer agrees, at its option, to: A. Repair or replace any defective part free of charge (except transportation...
  • Page 52 This warranty extends only to the original end user and is not assignable or transferable. This Warranty is governed by the laws of the State of Utah, without regard to the conflicts of interests provisions thereof. ClearOne Communications 1825 Research Way Salt Lake City, Utah 84119...

  • Page 53: Appendix E: Compliance

    Appendix E: Compliance Warning: The country code settings must be set for the desired country of operation in order to ensure proper operation of the XAP TH2 and to ensure that the XAP TH2 complies with the country’s Telco requirements.
  • Page 54 If you experience problems with this equipment, contact ClearOne Communications, 1825 Research Way, Salt Lake City, Utah 84119, or by phone at (801) 975-7200 for repair and warranty information.
  • Page 55 ClearOne Communications Manufacturer’s Address: 1825 West Research Way Salt Lake City, Utah 84119 U.S.A. Model No.: XAP TH2 Standard(s) to which Conformity is declared: 89/336/EEC “Electromagnetic Compatibility (EMC) Directive”: EN 55022: 1998 (Emissions) Specification for limits and methods of measurement of radio interference characteristics of information technology equipment.
  • Page 56 Appendices ~ Appendix E: Compliance EN 61000-3-2:1995/A1/A2:1998 Part 3: Limits – Section 2: Limits for harmonic current emissions. EN 61000-3-3:1995 Section 3: Limitation of voltage fluctuations and flicker in low voltage supply systems for equipment with rated current up to and including 16 A.

  • Page 57: Appendix F: Block Diagram

    Appendices ~ Appendix F: Block Diagram Appendix F: Block Diagram Technical Services Group ~ 1-800-283-5936 (USA) ~ 1-801-974-3760...

  • Page 58: Glossary

    Glossary ~ A–E Glossary Acoustic Echo Cancellation (AEC) A process in which acoustical echo is removed from a signal. AEC can be used to remove unwanted signals from mic audio if the unwanted acoustic signal is available separately as an electronic signal. Ambient Noise The existing room-level noise, such as that caused by ventilation systems, paper shuffling, and background chatter.
  • Page 59 GPIO (general purpose input/output) The Remote port on the rear of the XAP TH2 unit. G-Ware Software The XAP TH2’s setup and configuration software. Macro A series of user-created instructions, stored within the unit, which can be executed from an RS-232 command or contact closure.

  • Page 60: Index

    Index ~ A–R Index answering calls 17 GPIO Builder 13, 15 audible connect 33 G-Ware 11–16 audible connect/disconnect level 32 audible hook indication 14, 21, 22 audible ring 14, 17, 21, 22, 40, 41 hook flash 14, 19, 36 auto adapt 14 hook flash duration 36 auto-answer 14, 18, 32 auto-disconnect 14, 33...
  • Page 61 45 string execution 43 View Last # 19 tail time 25 XAP 800 7, 16, 21 telco adaptation 14, 44 XAP TH2 Telco Config 13 adding 11 telco enable 44 configuring 12, 13, 21 telco line 5, 25 connecting 7–8...
