Pts Specifications - SPY PIG TRACKING SYSTEMS Operating Instructions Manual

Mounting can be permanent or temporary and can be accomplished by using
pipe straps or clamps. Units can be installed along the line as often as needed.
The systems are provided in explosion-proof Class I, Division 1, Groups B, C, &
D certified enclosures. The enclosures come complete with an "O" ring seal,
which makes the housing NEMA 4X/7. Three quarter inch hubs are provided on
each enclosure for conduit connection into your SCADA or recording system.
When supplied by the factory as an assembly, proper explosion proof fittings are
used and manufacturer specified procedures are followed to connect the units in
order to maintain their rating. Make sure that you follow proper wiring and conduit
procedures as specified by the appropriate authority for wiring in hazardous areas
if you wish to connect your monitoring systems to the PTS system.

pts specifications

MODEL
Enclosure
Power Input
Power Output
Transmit Speed
Display Type
Unit Weight (lb)
Unit Dimensions (L x W x H)
Factory Warranty
Domestic & International
Standards
** Other types of power supply inputs can be used, but must be specified on order entry
to allow for modifications to be made to the modules.
PTR
Enclosure Class 1, Division 1,
Groups B, C & D Blind modules
Either 129 Volts AC or ±3VDC (Sensor
Module) and 18 Volts DC for Indicator**
Normal Open non-latching Dry
Contacts rated at 1A at 250 Volts AC
PTS Passage Indicator NOT a
Presence Indicator
Visual
9.4
26" x 26" x 4.75"
12 Month
CE Compliant
19
