pig tracker Sensor (pts)
When the need for noting the passage of a pig becomes a little less
temporary, (e.g.; manpower or distance prevents leap frogging) then SPY
offers a line of stationary Pig Tracking Sensors (PTS). We offer the standard
PTS for use with electromagnetic transmitters and our model PTS-M for
use with magnet equipped pigs.
The PTS system requires NO HOLE to be drilled in the pipe. This non-
invasive system allows for lower installation costs and significantly reduces
the overall cost of the monitoring point. It also offers safer monitoring. This
feature also makes the PTS more desirable than invasive systems from a
pollution prevention standpoint.
The PTS systems must be mounted directly onto the pipe in order to pick
up the signal of the transmitter or magnet. Care should be taken to allow
sufficient distance between the sensor and the launcher/ receiver so that
the pig can travel completely past the sensor.
NOTE: The PTS is a passage indicator, not a presence indicator.
Indicator Module*
Reset Button
18
Sensor Module*
Passage
Indicator
Window
*Explosion-proof Class I, Division 1, Groups B, C, & D certified enclosures.
®
Power Module*
