Model # 151-101-COSEC
USE AND CARE GUIDE
TOBAGO CORNER SECTION
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8.00 a.m. - 6.00 p.m., EST, Monday - Friday
1-855-HD-HAMPTON
HAMPTONBAY.COM
THANK YOU
this corner section. We strive
to continually create quality products designed to enhance your home. Visit us online to see our full line of products available
for your home improvement needs. Thank you for choosing Hampton Bay!
Advertisement
Table of Contents
Related Manuals for HAMPTON BAY TOBAGO 151-101-COSEC
Summary of Contents for HAMPTON BAY TOBAGO 151-101-COSEC
- Page 1 HAMPTONBAY.COM THANK YOU this corner section. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs. Thank you for choosing Hampton Bay!
-
Page 2: Table Of Contents
Table of Contents Pre-Assembly............Table of Contents............Planning Assembly............Safety Information............Hardware Included............. Warranty ................... 2 Year Frame, Weave and Fabric Limited Warranty Package Contents ............. What Is Covered............Assembly ..............What Is Not Covered............Care Instructions............2 Safety Information DANGER: Please keep children out of the assembly area during assembly. -
Page 3: Pre-Assembly
Pre-Assembly PLANNING ASSEMBLY It will take two people about 20 minutes to complete the assembly process. HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Part Description Quantity Bolt (M6x18) Bolt (M6x35) Washer (D6) Nut cap Wrench Plastic clamp NOTE: If you also bought other Tobago chair sections, you can secure one or two of them to this corner section with Parts (HH), from the bottom of the L-shaped woven panel. -
Page 4: Package Contents
Pre-Assembly (continued) PACKAGE CONTENTS 比例 0.300 Part Description Quantity Back panel Back panel Seat panel L-shaped panel Seat cushion Back cushion Back cushion... -
Page 5: Assembly
Assembly Attaching the back panel (B) to the back panel (A) □ Stand the back panel (A) on a flat, smooth surface. □ Attach the back panel (B) to the back panel (A) with washers (CC) and bolts (AA and BB) using the wrench (EE). IMPORTANT: Do not fully until the end of Step 3. - Page 6 Assembly Attaching the L-shaped panel □ Attach the L-shaped panel (D) to the back panel (A), the seat panel (C) and the back panel (B) with washers (CC) and bolts (BB) using the wrench (EE). □ Fully tighten all the bolts (AA and BB) when all of them are in place. CC BB EE BB EE...
- Page 7 Assembly Covering the bolts □ Cover all the bolts (AA and BB) with bolt caps (DD). Placing the cushions □ Place the seat cushion (E) and the back cushions (F and G) on the sofa. □ Adjust foot glides to stabilize the sofa. HAMPTONBAY.COM Please contact 1-855-HD-HAMPTON for further assistance.
