Item # 661 244
Model #151-115-7D-V2-NF
USE AND CARE GUIDE
TOBAGO 7 PIECE WOVEN DINING SET - BARE
(1-pair Fully Woven Rocking Dining Chairs)
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8.00 a.m. - 6.00 p.m., EST, Monday - Friday
1-855-HD-HAMPTON
HAMPTONBAY.COM
THANK YOU
this 7 piece set. We strive
to continually create quality products designed to enhance your home. Visit us online to see our full line of products available
for your home improvement needs. Thank you for choosing Hampton Bay!
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for HAMPTON BAY 151-115-7D-V2-NF
Summary of Contents for HAMPTON BAY 151-115-7D-V2-NF
- Page 1 THANK YOU this 7 piece set. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs. Thank you for choosing Hampton Bay!
- Page 2 Table of Contents Pre-Assembly............Table of Contents............Planning Assembly............Safety Information............Hardware Included............. Warranty ................... 2 Year Frame and Weave Limited Warranty.... Package Contents ............. What Is Covered............Assembly ..............What Is Not Covered............Care Instructions............2 Safety Information DANGER: Please keep children out of the assembly area during assembly.
- Page 3 Pre-Assembly PLANNING ASSEMBLY It will take two people about 20 minutes to complete the assembly process. HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Part Description Quantity Bolt (M8x42) Lock washer Washer Washer plate Bolt cap Nut cap Spanner HAMPTONBAY.COM Please contact 1-855-HD-HAMPTON for further assistance.
- Page 4 Pre-Assembly (continued) PACKAGE CONTENTS Part Description Quantity Chair base Seat and back Seat pad...
- Page 5 Assembly Attaching the seat and back to the chair base □ Place the chair base (A) upside down on a flat, smooth surface. □ Attach the seat and back (B) to the chair base (A) from below the U-bar (A-1) with the bolts (AA) and one washer plate (EE) (see Fig. 1), and above the U-bar (A-1) with one washer plate (EE), washers (DD), lock washers (CC) and nuts (BB) (see Fig.
- Page 6 Assembly Attaching the seat and back to the chair base (continued) □ At the U-bar (B1) attach the chair base (A) to the seat and back (B) from under the U-bar (B-1) with bolts (AA), washer plate (EE) (see Fig. 3), and with washer plate (EE), washers (DD), lock washers (CC) and nuts (BB) (see Fig.
- Page 7 Assembly Attaching the bolt caps □ Cover all the bolts (AA) and pre-installed bolts with bolt caps (FF). □ Cover all the nuts (BB) and pre-installed nuts with nut caps (GG). Placing the seat pad on the chair □ Place the seat pad (C) on the chair. □...
- Page 8 Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service 8.00 a.m. – 6.00 p.m., EST, Monday-Friday 1-855-HD-HAMPTON HAMPTONBAY.COM Retain this manual for future use.
