Item # 661 240
Model #151-115-7D-V2-NF
USE AND CARE GUIDE
TOBAGO 7 PIECE WOVEN DINING SET -BARE
(Extension Dining Table)
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8.00 a.m. - 6.00 p.m., EST, Monday - Friday
1-855-HD-HAMPTON
HAMPTONBAY.COM
THANK YOU
7-piece set.
to continually create quality products designed to enhance your home. Visit us online to see our full line of products available
for your home improvement needs. Thank you for choosing Hampton Bay!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TOBAGO 151-115-7D-V2-NF and is the answer not in the manual?

Questions and answers

Summary of Contents for HAMPTON BAY TOBAGO 151-115-7D-V2-NF

  • Page 1 8.00 a.m. - 6.00 p.m., EST, Monday - Friday 1-855-HD-HAMPTON HAMPTONBAY.COM THANK YOU 7-piece set. to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs. Thank you for choosing Hampton Bay!
  • Page 2 Table of Contents Pre-Assembly............Table of Contents............Planning Assembly............Safety Information............Hardware Included............. Warranty ..............Package Contents ............. Two Year Frame and Weave Limited Warranty ....Assembly ..............What Is Covered............What Is Not Covered............Operation ..............7 Care Instructions..
  • Page 3 Pre-Assembly PLANNING ASSEMBLY It will take two people about 10 minutes to complete the assembly process. Please have a rubber mallet ready before assembly. HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Part Description Quantity Long bolt Lock washer Washer Plastic glide Wrench...
  • Page 4 Pre-Assembly (continued) PACKAGE CONTENTS Part Description Quantity Table rim Table leg Glass Glass...
  • Page 5 Assembly Attaching long bolts □ Remove the inner cartons from the table rim (A) and set them aside. □ Place the table rim (A) upside down on a flat, smooth and non-abrasive surface. Screw one long bolt (AA) firmly into each corner of the table rim (A). Attaching table legs □...
  • Page 6 Assembly (continued) Attaching the plastic glides □ Cover the bottom of each table leg (B) with a plastic glide (EE) using a rubber mallet. Placing the table glasses □ Turn the table upright. □ Inset the glass pieces (C and D) into the table rim (A). □...
  • Page 7 Operation Opening the table IMPORTANT: Release the locking mechanism at the beginning of this step. Lock the locking mechanism at the end of this step. The locking mechanism is located underneath the middle of each short side. □ SLOWLY slide ONE of the bigger sections apart until you hear a click at its maximum range. The other big section will also slide apart and the small section will rise to the same level as the big section.
  • Page 8 Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service 8.00 a.m. – 6.00 p.m., EST, Monday-Friday 1-855-HD-HAMPTON HAMPTONBAY.COM Retain this manual for future use.
