- Page 1 EXMICRO2 VER 1.0...
-
Page 2: Table Of Contents
Thank you for purchasing this product The Simplified MFG EXMICRO2 is designed to provide years of reliable service. At Simplified MFG, we want the experience with this device to be the best possible and are committed to helping achieve that experience. -
Page 3: Features
2. Features • HDMI 2.0b, HDCP 2.2 / HDCP 1.4 and DVI 1.0 compliant • Supports input and output video resolution up to 4k2k@60Hz 4:4:4 up to 18Gbps • Supports HDR • Distance up to 164ft / 50 meters • Compact size •... -
Page 4: Specifications
4. Specifications Technical HDMI Compliance HDMI 2.0b HDCP Compliance HDCP 2.2 / HDCP 1.4 Video Bandwidth 18Gbps Video Resolution Up to 4K60Hz 4:4:4 Color Space RGB / YCbCr 4:4:4, YCbCr 4:2:2/4:2:0, YUV 4:4:4 Color Depth 8/10/12-bit (1080P60Hz, 4K30Hz, 4K60Hz YCbCr 4:2:2/4:2:0) 8-bit (4K60Hz 4:4:4 ) HDMI Audio Formats... -
Page 5: Operation Controls And Functions
DC 12V Plug DC 12V/1A power supply into the unit and connect the adapter to an AC outlet. (Note: The EXMICRO2 can be powered from either the RX or the TX by 12V/1A power adapter, only one supply is needed) -
Page 6: Receiver Panel
DC 12V Plug DC 12V/1A power supply into the unit and connect the adapter to an AC outlet. (Note: The EXMICRO2 can be powered from either the RX or the TX by 12V/1A power adapter, only one supply is needed) -
Page 7: Application Example
IR Use Example; 6. Application Example... -
Page 8: Warranty Information
Or b) Replace the product with new or refurbished product. All Simplified MFG products are covered by a 3-year PARTS and LABOR warranty. During this period there will be no charge for unit repair, replacement of unit components or replacement of the product if deemed necessary. - Page 9 AC. • IR Commands are returned from the CAT6/6A/7/8 display to the Transmitting unit for source control Simplified MFG • 550 W Baseline Road Ste 102-121 • Mesa, AZ 85210 • www.simplifiedmfg.com • 833-HDMI-411 (436-4411)
- Page 10 (YUV4:4:4),4K2K@30Hz,1080P@120Hz, and 1080P Resolutions 3D@60Hz Color Space RGB, YCbCr 4:4:4, YCbCr 4:2:2 The EXMICRO2 is a HDMI over cate- Color Depth 8-Bit, 10-bit, 12-bit gory cable extender that supports the HDMI Audio LPCM 2/5.1/7.1CH, Dolby Digital, DTS 5.1, Dolby Digi- entire HDMI 2.0b format including all...
