6743335COM
Condor Toolless TV Stand
Date of Purchase ___ / ___ / ___
Lot Number:
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
WARNING
THE TOP SHELF OF UNIT IS DESIGNED TO HOLD LCD
AND PLASMA TVS UP TO 50" WITH A WEIGHT OR NOT
MORE THAN 60 LBS (27KG).THE BASE OF THE TV MUST
REST ON THE SUPPORTING TOP SURFACE OF THE UNIT
WITHOUT OVERHANGING THE EDGES.OVERHANGING THE
EDGES MAY RESULT IN INSTABILTY CAUSING POSSIBLE
DAMAGE OR INJURY.SEE PAGE 8 OF THESE INSTRUCTIONS
FOR FURTHER SAFETY INSTRUCTIONS.
Do Not Return This Product!
Contact our customer service team for help rst.
Call: 1-800-489-3351 (toll free)
Monday-Friday 9am - 5pm CST
Visit: www.ameriwoodhome.com
Easy
Assembly Di culty Meter
Follow Ameriwood Home
B346743335COM01MP
Tough
You
Tube
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Ameriwood HOME Condor 6743335COM
Summary of Contents for Ameriwood HOME Condor 6743335COM
- Page 1 Assembly Di culty Meter MORE THAN 60 LBS (27KG).THE BASE OF THE TV MUST REST ON THE SUPPORTING TOP SURFACE OF THE UNIT Follow Ameriwood Home WITHOUT OVERHANGING THE EDGES.OVERHANGING THE EDGES MAY RESULT IN INSTABILTY CAUSING POSSIBLE DAMAGE OR INJURY.SEE PAGE 8 OF THESE INSTRUCTIONS Tube FOR FURTHER SAFETY INSTRUCTIONS.
-
Page 2: Helpful Hints
Contact Us! Do NOT return this product! Contact our friendly customer service team t for help. Assembly Tips Call us! 1-800-489-3351 Monday-Friday 9am - 5pm CST Tube Visit ameriwoodhome.com to view the limited warranty valid in the U.S. and Canada. Helpful Hints PEOPLE NEEDED FOR ASSEMBLY: 1-2 ESTIMATED ASSEMBLY TIME: 20 MINUTE... -
Page 3: Part List
Not actual size SUPPORT BAR SMALL SHELF LARGE SHELF T6743335040MP T6743335030MP T6743335010MP T6743335020MP (QTY : 4) (QTY : 1) (QTY : 1) (QTY : 1) Part List Not actual Size TOP CAP ROUND LEG SHORT POLE LONG POLE TMP032021 TMP034381 TMP301621 TMP303401 (QTY : 6) - Page 4 STEP 1 - Use long pole & short pole to join the round leg & anti-tip leg with panels (C&D) as below shown. - Make sure the board finishing surface are placed upwards. Please note: Wider side of all anti-tip leg should be placed outward.
- Page 5 STEP 2 - Use long pole & short pole to join the unit with panel (B) as below shown. - Make sure the board finishing surface are placed upwards. 4pcs LONG POLE 2pcs SHORT POLE ameriwoodhome.com...
- Page 6 STEP 3 - Use top cap & short pole to join the unit with panel (C) as below shown. - Make sure the board finishing surface are placed upwards. TOP CAP SHORT POLE 4pcs 4pcs ameriwoodhome.com...
- Page 7 STEP 4 - Use top cap to join the unit with panel (A) as below shown. - Make sure the board finishing surface are placed upwards. TOP CAP 6pcs ameriwoodhome.com...
-
Page 8: Maximum Loads
Maximum Loads This unit has been designed to support the maximum loads shown. Exceeding these load limits could cause sagging, instability, product collapse, and/or serious injury. Certi cate of Conformity 1. This certi cate applies to the Dorel Home Furnishings, Inc. product identi ed by this instruction manual. 2. - Page 9 Visit your local retailer's website, rate your purchased product and leave us some feedback! We would like to extend a big "Thank You" to all of our customers for taking t o assemble this Ameriwood Home product, and to give us your valuable feedback. ameriwoodhome.com...
