Lumin User Manual
Part Number: 15-2500-074
Rev: B, April - 2016

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Lumin 15-2500-074 and is the answer not in the manual?

Questions and answers

Related Manuals for Teledyne Tekmar Lumin 15-2500-074

Summary of Contents for Teledyne Tekmar Lumin 15-2500-074

  • Page 1 Lumin User Manual Part Number: 15-2500-074 Rev: B, April - 2016...
  • Page 2 Trademarks The companies indicated own the following trademarks: Tekmar .......... Teledyne Instruments, Inc. All other brands or product names are trademarks or registered trademarks of their respective owners. Teledyne Tekmar 4736 Socialville Foster Road Mason, OH 45040 U.S.A www.teledynetekmar.com Toll Free: 800-543-4461...

  • Page 3: Table Of Contents

    P.1 Warranty ..........P-1 P.2 Teledyne Tekmar Customer Support Center..... . . P-1 P.3 Essential Instructions.
  • Page 4 2.5.2 Connect the USB Interface Cable ......2-10 2.5.3 GC I/O (Input/Output) Connection......2-10 2.6 Connecting the Lumin Sample Purge Gas Supply .
  • Page 5 Chapter 4: Instrument Operations 4.1 Concentrator Mode Descriptions ....... . 4-1 4.2 Lumin Valve Output Chart .
  • Page 6 5.34 Technical Assistance ........5-73 5.34.1 Teledyne Tekmar Customer Support ..... . 5-73 Appendix A: Diagrams A.1 Lumin Electrical Schematic .
  • Page 7 1-16 CPU Communication Board Location ......1-17 1-17 DC Valve Control Board........1-18 1-18 DC Valve Control Board Location .
  • Page 8 3-34 History Form - Instrument History......3-30 3-35 History Form Filter - Instrument History ......3-31 3-36 Upgrade Firmware Dialog.
  • Page 9 5-32 Mass Flow Controller ........5-35 5-33 6-Port Valve .
  • Page 10 A-14 Lumin With GFS & Eliminator - Desorb Flow Diagram ... . . A-15 A-15 Lumin With GFS & Eliminator - Bake Flow Diagram ....A-16 List of Tables 1-1 General Specifications .

  • Page 11: Preface

    NOTE It is important that you read this page before proceeding! Teledyne Tekmar designs, manufactures, and tests its products to meet many national and international standards. The Lumin is a sophisticated technical product and must be properly installed, used, and maintained to ensure that it operates within normal specifications.

  • Page 12: Notations And Hazard Severity Levels

     When replacement parts are required, ensure that qualified individuals use replacement parts specified by Teledyne Tekmar. Unauthorized parts and products can affect the product’s performance and jeopardize safety. Using look-alike substitutions may result in fire, electrical hazards, or improper operation.

  • Page 13: Lumin Safety Symbols

    P.5 Lumin Safety Symbols The Lumin instrument is labeled in compliance with the marking and nomenclature specified in the EN61010-1:2010 safety standard. The following symbols and their associated signal words are used in the manual and on instrument labels. L’instrument Lumin est étiqueté en conformité avec le marquage et la nomenclature spécifiés dans le standard de sécurité...
  • Page 14 High Pressure Hazard! Risque de haute pression! Risk of Eye Injury. Wear safety glasses and other appropriate PPE. Risque de blessures aux yeux. Porter des lunettes de sécurité et autres équipements de protection personnel appropriés Lumin Safety Symbols P - 4 Lumin User Manual...

  • Page 15: Lumin Safety Labels

    P.6 Lumin Safety Labels Electrical Ground Prise de terre WARNING: Electrical shock hazard. Do not operate without cover. DANGER - Risque d’électrocution. Ne pas utiliser sans capot. WARNING: To avoid electrical shock, disconnect supply before changing fuses. DANGER - Pour éviter le risque d’électrocution, débrancher l’alimen- tation avant de remplacer les fusibles.

  • Page 16: Working Safely

    Please be aware that if the Lumin, its components, and/or accessories are used in a manner not specified by Teledyne Tekmar, protection by the equipment may be impaired. Only use replacement parts supplied or approved by Teledyne Tekmar when performing maintenance on the Lumin. Use of unapproved parts could result in damage to the instrument, as well as personal injury.
  • Page 17 Sample and associated waste may contain hazardous and toxic substances. Follow the proper safety and health practices, as well as anticipating all regulatory limitations before using or disposing of chemicals. To avoid electrical shock:  Do not operate without the panels, covers and guards installed. ...
  • Page 18 P - 8 Lumin User Manual...

  • Page 19: Chapter 1: Introduction

    Lumin User Manual Chapter 1: Introduction The Lumin is a modern laboratory instrument designed to concentrate Volatile Organic Compounds (VOCs) from samples using the Purge and Trap (P&T) technique. The Lumin uses advanced P&T technology that allows accelerated automatic processing of liquid samples for analysis by Gas Chromatograph (GC).

  • Page 20: Brief History

    1.1.2 Brief History In the 1960’s, P&T was used in the study of bodily fluids. In the mid-to-late 1970’s, P&T became a technique that was well-known and widely applied due the need to monitor VOCs in drinking water. Using this technique, it was possible to detect sub-ppm level VOCs of a wide variety.

  • Page 21: Trapping, Adsorption And Desorption

    At this point a portion of the headspace can be removed and injected into the GC for analysis. This technique isknown as Equilibrium Analysis or Static Headspace Analysis. The amount of material in the vapor phase will be proportionalto the partial pressure of the component.

  • Page 22: Lumin Specifications

    GC Interface Designed to Interface with virtually all commercially available GC instru- ments. Column Compatibility Teledyne Tekmar recommends the use of 20 m x 0.18 mm ID Fast Vola- tiles columns. Table 1-2 Performance Specifications Cycle Time The cycle time for the unit is ≤ 15 minutes when using an 11 minute purge time.
  • Page 23 Table 1-3 Methods, Applications, and Certifications Official Methods USEPA 502.1, 502.2, 524.2, 524.3, 524.4, 503.1 USEPA 601,602, 603, 624 USEPA 8010, 8015, 8020, 8021, 8030, 8240, 8260 ASTM and Standard Methods Massachusetts VPH and GRO Methods Applications Environmental Food and Beverage Petrochemical Plastics and Polymers Certifications...
  • Page 24 Optional Sample Heater Assembly for all glassware types. Optional Guardian™ Foam Sensor and Foam Eliminator senses foam, stops purge, and adds defoaming agent for samples prone to foaming. Optional Teledyne Tekmar AQUATek 100 liquid autosampler. Chapter 1: Introduction 1 - 6...

  • Page 25: Lumin Component Overview

    1.4 Lumin Component Overview Table 1-11 Lumin Components Component Function Sample Mount /Sparger Sample gas is passed through the sample in the sparger and then conveyed through the sample mount. Sample Heater Jacket Assembly for Heats the sparger between the range of 20-90 °C. all Glassware Types (Optional) Guardian™...

  • Page 26: Sample Mount And Sparger

    1.4.1 Sample Mount and Sparger The front panel contains a heated sample mount and glass sparge vessel. The Sample Mount is heated via the 6-port valve oven plate on one end and a cartridge heater inside of the mount itself. A standard 5 mL frit sparger is included with the Lumin. The following options are also available: ...

  • Page 27: Status Light

    “Sample Gas”. The sample gas is also used for the Dry Purge and Bake Modes. NOTE Teledyne Tekmar recommends a sample gas flow of 40mL/min. ±5mL for 11 minutes to achieve a 440 mL purge volume. Chapter 1: Introduction...

  • Page 28: Mass Flow Controller (Mfc)

    1.4.5 Mass Flow Controller (MFC) The Lumin incorporates a patented (US 7,651,866) mass flow controller to monitor and control the gas flow rates throughout the entire purge and trap process. Once set, the parameters remain precisely controlled throughout all modes of operation and achieve highly repeatable analyses.

  • Page 29: Analytical Trap

    1.4.7 Analytical Trap The analytical trap is used to capture and release VOCs swept out of the sample by the purge gas. Once VOCs are captured, the trap is heated, causing the VOCs to desorb. The trap is then back-flushed with carrier gas carrying the VOCs to the GC for analysis. The analytical trap is heated using a heating jacket which surrounds it and cooled by a fan at the top of the analytical trap compartment.

  • Page 30: Carrier Gas Inlet Line/Heated Sample Transfer Line

    Figure 1-6 Moisture Control System 1.4.9 Carrier Gas Inlet Line/Heated Sample Transfer Line The Carrier Gas Inlet line is the inert tubing that runs down the side of the heated sample transfer line from the GC. Carrier gas is used to desorb VOCs off the analytical trap and carry them through the sample transfer line back to the GC.

  • Page 31: Valving

    1.4.10 Valving NOTE Each valve and its function is detailed in Table 1-8 "Valving". Solenoid Valves The Purge Valve, Bake Valve, Drain Valve and Vent Valve are mounted on a Valve Manifold, which supplies gas to various locations within the system. If the system is equipped with the Foam Eliminator option, the valve manifold will have two additional solenoid valves used to add anti-foam to foaming samples and rinse the anti-foam lines between samples.

  • Page 32: 3-Port Sample Valve

    Three-Port Sample Valve The three-port sample valve controls the flow between the sparger and the drain line and is used for standalone operation of the Lumin as well as for troubleshooting. Figure 1-10 3-Port Sample Valve Flow Switch 3-Port Sample Valve Table 1-13 Valves and Functions Actions Valve...

  • Page 33: 24Vdc Power Supply

    1.4.11 24VDC Power Supply The 24VDC Power Supply is located on the left side of the Lumin. The 24VDC power supply is identified by its brown/orange wiring. This power supply powers motors and valves within the Lumin including the 6-Port valve and solenoid valves. Figure 1-11 24VDC Power Supply 24VDC Power Supply 1.4.12 5VDC Power Supply...

  • Page 34: Multi-Channel Temperature Control Board

    1.4.13 Multi-Channel Temperature Control Board The Multi-Channel Temperature Control Board is located in the right side of the concentrator. It is responsible for all AC control and RTD feedback for the standard temperature zones (6-Port Valve Oven, heated sample mount, heated analytical trap, sample transfer line heater and optional sample heater assembly for sparger glassware).

  • Page 35: Cpu Communication Board (Master Board)

    1.4.14 CPU Communication Board (Master Board) The CPU Communication Board (Master Board) is located on the concentrator’s right side. This board has a 25-pin, Sub-D connector for communications to the GC via GC I/O cable, USB Port for external communication to the controlling PC and interface for the AQUATek 100 autosampler.

  • Page 36: Dc Valve Control Board

    1.4.15 DC Valve Control Board The DC Valve Control Board is located in the right side of the concentrator. This board controls all DC valve outputs. DC Valve Control Board Figure 1-17 Figure 1-18 DC Valve Control Board Location DC Valve Control Board Chapter 1: Introduction...

  • Page 37: Optional Autosampler

    1.5 Optional Autosampler For automated sample analysis, the Lumin was designed to be combined with the Teledyne Tekmar AQUATek100 autosampler and can process up to 100 liquid samples without manual intervention. The AQUATek 100 is a purge and trap autosampler that automates the sample preparation steps for the analysis of liquid samples utilizing a fixed volume sample loop filled using a pressurization gas.
  • Page 38 Chapter 1: Introduction 1 - 20 Lumin User Manual...

  • Page 39: Chapter 2: Installation And Setup

    Lumin User Manual Chapter 2: Installation and Setup 2.1 Pre-Installation 2.1.1 Overview This chapter contains information on:  Pre-installation requirements including electric, gas and software/computer.  Unpacking the concentrator and checking for shipping damage and/or missing items.  Concentrator overview ...

  • Page 40: Electrical Requirements

    WARNING Ensure that the installation location allows the concentrator to be easily turned off and the power cord disconnected, in the event of an emergency. 2.1.4 Electrical Requirements After selecting and clearing a location for the concentrator, check the availability of the required grounded outlets.
  • Page 41  reduces a high source pressure to that required by the concentrator. NOTE Teledyne Tekmar recommends using a single, two-stage regulator rather than two single-stage pressure regulators to meet the concentrator’s pressure specifications. ON/OFF valves, while not essential, are very useful when mounted on the ...

  • Page 42: Minimum Computer Requirements

    2.1.6 Minimum Computer Requirements Connect the Lumin to a computer that meets or exceeds the specifications shown in Table 2-1 "Minimum Computer Requirements": Table 2-1 Minimum Computer Requirements Component Specification Processor 300 MHz Pentium II (Or Equivalent) Memory 512 MB Hard Drive Space 6.4 MB Display...

  • Page 43: Unpacking The Lumin

    Installation Kit Box parts and their location are identified on the diagram on the inside of the Installation Kit Box lid. If there are any damaged or missing items contact Teledyne Tekmar customer service, using the information in Section P.2 "Teledyne Tekmar Customer Support Center", immediately.

  • Page 44: Concentrator Overview

    2.4 Concentrator Overview Figure 2-2 Front of Lumin Analytical Trap Sample Mount Sparger Status Light Valve Manifold Chapter 2: Installation and Setup 2 - 6 Lumin User Manual...
  • Page 45 Figure 2-3 Back of Lumin Heated Sample Transfer Line and Carrier Gas Line GC I/O Connection USB Connection Ethernet Connection Autosampler Connection Power Entry Module Sample Gas Tubing Drain Tubing Chapter 2: Installation and Setup 2 - 7 Lumin User Manual...
  • Page 46 Figure 2-4 Right Side of Lumin Right Access Panel Figure 2-5 Left Side of the Lumin Left Access Panel Top Access Panel Analytical Trap Access Door Chapter 2: Installation and Setup 2 - 8 Lumin User Manual...

  • Page 47: Electrical And Data Connections

    2.5 Electrical and Data Connections 2.5.1 AC Power Cord NOTE For electrical requirements refer to Section 2.1.4 "Electrical Requirements". 1. Ensure the switch on the Power Entry Module (PEM) is in the OFF (O) position. 2. Plug the AC power cord into the PEM and connect it to a properly rated and grounded AC receptacle.

  • Page 48: Connect The Usb Interface Cable

    2.5.2 Connect the USB Interface Cable The Lumin is connected to a controlling computer with Lumin TekLink installed using the supplied USB cable. Connect the cable to the USB port at the back of the Lumin to a USB port on the computer. NOTE If the Lumin is disconnected from the USB port on the controlling computer, and then reconnected to another USB port, USB drivers will need to be reinstalled and...

  • Page 49: Connecting The Lumin Sample Purge Gas Supply

    Lumin TekLink for the GC, refer to Section 2.11 "Create an Instrument Profile". 2.6 Connecting the Lumin Sample Purge Gas Supply NOTE For sample gas requirements refer to Section 2.1.5 "Gas Supply Requirements". Helium or nitrogen sample purge gas enters the back panel through the blue 1/8” tubing labeled “Sample Gas”.

  • Page 50: Lumin Carrier Gas And Sample Transfer Line Connection To The Gas Chromatograph (Gc)

    Figure 2-8 Rear of Lumin - Sample Purge Gas Connection Sample Purge Gas 2.7 Lumin Carrier Gas and Sample Transfer Line Connection to the Gas Chromatograph (GC) The Lumin makes two gas tubing connections to the Gas Chromatograph: 1. Carrier Gas Supply Lumin carrier gas is supplied either from the regulated carrier gas flow of the GC or directly from the unregulated carrier gas supply.
  • Page 51 Procedure In the standard installation configuration the GC supplies and controls carrier gas flow to the Lumin. The Lumin sample transfer line is then connected to the GC injection port. Follow the instructions below to connect the Lumin to the GC. Connecting to the GC Carrier Gas Figure 2-9 Warning! - Hot surface! Allow the injection port to cool prior to...

  • Page 52: Routing The Drain Tubing

    NOTE Some injection ports have multiple pieces of tubing connecting to the Injection Port. Do not cut any lines until you are certain that you know which line is the carrier gas inlet line. 3. Connect to the GC carrier gas inlet line between the GC control pneumatics and the GC injection port (approximately one inch from the injection port).

  • Page 53: Install Lumin Teklink Software

    2.9 Install Lumin TekLink Software NOTE For computer requirements refer to Section 2.1.6 "Minimum Computer Requirements". 1. Ensure the controlling computer is connected to the Lumin with the supplied USB cable. 2. Power on the concentrator and the controlling computer. 3.

  • Page 54: Microsoft ® Sql Server Installation

    Figure 2-11 Microsoft® SQL Server Installation Notification Message NOTE If a .NET setup error is displayed, install the .NET Framework for x86 Architecture according to Section 2.9.2 ".Net Installation". Figure 2-12 .NET Setup Installation Notification Message Follow the installation prompts to the completion of the Lumin TekLink software installation.

  • Page 55: Net Installation

    Figure 2-13 Microsoft SQL Server Installation Wizard 2.9.2 .Net Installation .NET Framework for x86 architecture must be installed for Lumin TekLink to function properly. To install the .NET Framework: 1. If necessary, return to the Lumin TekLink S OFTWARE NSTALLATION 2.

  • Page 56: Create An Instrument Profile

    NOTE If the Lumin is replaced or a second Lumin added, the USB connection will need to be reselected via Tools Screen>Configuration Dialog>General Tab. NOTE If the Lumin is disconnected from the USB port on the controlling computer, and then reconnected to another USB port, USB drivers will need to be reinstalled and the USB connection reselected via Tools Screen>Configuration Dialog>General Tab.
  • Page 57 Figure 2-14 Creating an Instrument Profile  Select the default USB C , then choose the available ONNECTION HECK USB connection from the drop-down menu. NOTE If no USB connections are shown in the drop-down menu, USB drivers have not been installed. Refer to Section 2.10 "USB Driver Installation". Select the OK B to save the instrument profile.

  • Page 58: Leak Check Tab

    Figure 2-15 Options Tab 4. On the L HECK Customize L pressure settings,  HECK RESSURIZE HECK and L (amount of change in pressurization that indicates a HECK ELTA leak). Figure 2-16 Leak Check Tab Chapter 2: Installation and Setup 2 - 20 Lumin User Manual...
  • Page 59 5. Select the OK B to create the instrument profile. Lumin TekLink will UTTON automatically connect to the new profile, and the I NSTRUMENT TATUS ANEL and S will display the connected instrument ETHODS CREEN CHEDULES CREEN profile name. Once a profile is created, methods, schedules, system properties, and preferences can be saved to that profile when it is connected.

  • Page 60: Autosampler Setup And Connection

    2.12 Autosampler Setup and Connection NOTE If the configuration includes an AQUATek 100 autosampler, ensure that the “Model” is set to “Lumin/AQUATek 100” in the Instrument Configuration Dialog’s General Tab. 2.12.1 Communication Cable Connection The Lumin will control the AQUATek 100 autosampler via a 9-pin autosampler communication cable.

  • Page 61: Autosampler Method Configuration

    Figure 2-18 Aqueous Transfer Line Access Point Aqueous Transfer Line Access Point Prior to Installation Installed 2.12.3 Autosampler Method Configuration Method parameters for the AQUATek 100 autosampler are configured on the AQUAT 100 T of the Lumin TekLink M . For more information refer to Section ETHODS CREEN 3.4.5 "AQUATek 100 Tab".
  • Page 62 Lumin with Guardian™ Foam Sensor 1. When foam is sensed, the Lumin shuts off the purge gas and drains the sample. 2. Y will be displayed in the F of the sample schedule, and the event OLUMN will be recorded in the S >V >S AMPLE...

  • Page 63: Configuring The Guardian™ Foam Sensor & Eliminator

    2.13.1 Configuring the Guardian™ Foam Sensor & Eliminator To activate and configure the Guardian™ Foam Sensor and Foam Eliminator: 1. Navigate to T >C >O OOLS ONFIGURATION PTIONS 2. Select the check-box beside E NABLE GUARDIAN FOAM SENSOR 3. Use the drop-down menu to configure the Guardian™ Foam Sensor and Eliminator actions.
  • Page 64 Chapter 2: Installation and Setup 2 - 26 Lumin User Manual...

  • Page 65: Chapter 3: Lumin Teklink Software Overview

    Lumin User Manual Chapter 3: Lumin TekLink Software Overview NOTE For Lumin TekLink computer requirements refer to Section 2.1.6 "Minimum Computer Requirements". For information on installing Lumin TekLink refer to Section 2.9 "Install Lumin TekLink Software". 3.1 About Lumin TekLink Software Lumin Teklink is a software user interface designed for the following functions: ...

  • Page 66: Pinnable" Screens

    Figure 3-1 On-Screen Keyboard 3.2.2 “Pinnable” Screens All screens can be “pinned” so that they remain in view when the H CREEN reduced. Use the pin in the upper right-hand corner of the screen to “pin” and “unpin” each screen. When the pin is horizontal, the screen will be reduced from view when the ...

  • Page 67: Open, Save, Load, And Print Buttons

    Figure 3-3 Schedules Screen Title Bar Instrument Profile Model Schedule Name Instrument Profile Model Method Name 3.2.4 Open, Save, Load, and Print Buttons Figure 3-4 Open, Save, Load, and Print Buttons - Opens a previously saved method or schedule. The O ...

  • Page 68: Instrument Control Buttons

    When a method is loaded, the concentrator will begin heating to temperature set-points as defined in the method. Once temperature set-points are achieved, the schedule will begin to run. - Print the currently open method or schedule.  RINT UTTON 3.2.5 Instrument Control Buttons The I and the S...

  • Page 69: Primary Screens

    Figure 3-7 Open Dialog Source Drop-down Menu 3.3 Primary Screens 3.3.1 The Home Screen The H contains buttons to navigate to TekLink’s three primary screens and CREEN the Lumin TekLink Help:  - used for defining Standby, Purge, Desorb and Bake method ETHODS CREEN parameters as well as opening, saving, loading, and printing methods.

  • Page 70: Instrument Status Panel

    3.3.2 Instrument Status Panel The I contains information related to the activities of the NSTRUMENT TATUS ANEL concentrator including the schedule that is running, the current method, the current position in the schedule being run, as well as the mode and time remaining. Similar to the S , control buttons can be used to A or H...

  • Page 71: Methods Screen

    Figure 3-10 Instrument Status Zone Display Options 3.4 Methods Screen The M contains S and B for defining ETHODS CREEN TANDBY URGE ESORB method parameters. NOTE Also refer to 4.4.13 "Analytical Trap Recommended Operating Conditions". NOTE Multiple Methods Screens can be opened for comparison of one method to another.

  • Page 72: Purge Tab

     TANDBY The amount of carrier gas flow sweeping the sample pathway while the concentrator is idle.  URGE EADY The temperature set-point for the analytical trap that must be reached before stepping to Purge Mode. Set approximately 10-20 degrees higher than ambient air temperature to decrease cycle time.
  • Page 73 The following settings can be made on the P URGE  URGE The amount of time gas is passed through the sample to concentrate the analytes on the trap.  URGE The flow rate at which the sample is purged with gas and analytes are collected on the trap.

  • Page 74: Desorb Tab

    NOTE The following parameters are only shown on the Purge Tab when the Enable Sample Heater Check-box is selected.  (Sample Heater Enabled) AMPLE The sample temperature range is 20-90 °C. For environmental samples, the typical range is 40-60 °C. Flavor and fragrance analysis may have much higher temperatures.

  • Page 75: Bake Tab

    Figure 3-13 Methods Screen - Desorb Tab 3.4.4 Bake Tab The B is used to define the time, flow and temperature of the Bake Mode. Click in the V to revise the method’s bake parameters. ALUE OLUMN The following settings can be made on the Bake Tab: ...

  • Page 76: Aquatek 100 Tab

    Figure 3-14 Methods Screen - Bake Tab 3.4.5 AQUATek 100 Tab If an AQUATek 100 autosampler is installed, the M will have an additional ETHODS CREEN AQUAT . The AQUAT is used to define the time and water temperature parameters for the AQUATek 100 autosampler. Click in the V to revise the ALUE OLUMN...
  • Page 77 Figure 3-15 AQUATek 100 Tab The following settings can be made on the AquaTek Tab:  AMPLE The amount of time the vial is pressurized to allow for the sample to be displaced to fill the sample loop  AMPLE RANSFER The amount of time the sample and standards are swept to the sparge vessel of the concentrator.

  • Page 78: Schedules Screen

    3.5 Schedules Screen The S is used for creating and saving new sample schedules, opening CHEDULES CREEN previously created schedules, and printing an open schedule. Schedules are “loaded” using the L on the S . Once a schedule is loaded, the UTTON CHEDULES CREEN...

  • Page 79: Tools Screen

    Figure 3-16 Schedules Screen 3.6 Tools Screen The T is used for direct control of the concentrator’s functions for OOLS CREEN troubleshooting and diagnostics. It also contains software configuration options and settings as well as sample, instrument, and error logs. Figure 3-17 Tools Screen Chapter 3: Lumin TekLink Software Overview 3 - 15...

  • Page 80: Prime Menu

    3.6.1 Prime Menu The P contains functions related to priming the AQUATek 100 standards and RIME DI water supply tubing. NOTE Priming removes air from the tubing lines and should be performed whenever the standard addition vials or DI water supply has been disconnected. ...
  • Page 81 Activates the Lumin leak check function. The concentrator performs a leak  check by closing certain valves and shutting down the Mass Flow Controller (MFC) to isolate the pressurized system. Once isolated, the Lumin will take pressure readings to identify any pressure loss that would indicate a leak. NOTE Leak check settings (Check Pressurize Time, Flow and Delta) are defined on the Tools>Configuation>Leak Check Tab.

  • Page 82: System Menu

    Desorb The D manually steps the concentrator to Desorb Mode. The concentrator ESORB UTTON will use the desorb settings as configured in the currently active method. NOTE The Desorb Button is typically used for diagnostic and troubleshooting functions when using Top of Trap (TOT) injections. pH Probe Check Checks the pH probe (if installed) on the AQUATek 100.

  • Page 83: Tools - Configuration - General Tab

    Figure 3-20 Tools - Configuration - General Tab Configuration - Options Tab  - Enables/disables the concentrator beeper for instrument NABLE EEPER errors. - Adds/removes a V ID column  NABLE COLUMN IN SCHEDULES to/from the S on the S CHEDULE ABLE CHEDULES...
  • Page 84 NOTE For more information on Guardian Foam Sensor and Eliminator actions according to instrument configuration, refer to 2.13 "Guardian™ Foam Sensor and Foam Eliminator (Optional)". - Specifies the type of carrier gas. Choose between Ultra-high purity  URGE helium or nitrogen. The default gas is helium. NOTE If this configuration is made incorrectly, the gas flow from the Mass Flow Controller (MFC) will not be accurate.

  • Page 85: Tools - Configuration - Leak Check Tab

    Configuration - Leak Check Tab options Include: HECK - the amount of time allowed for the system to  HECK RESSURIZE become fully pressured. NOTE If using 25 mL sparger, change the Leak Check Pressurize Time to 2 minutes.  - the flow rate for the pressurization of the system during HECK leak check.

  • Page 86: Tools - Instrument Manager

    Instrument Manager The I is used to create, connect and view the properties of NSTRUMENT ANAGER IALOG instrument profiles. Figure 3-23 Tools - Instrument Manager System Properties The S g contains settings and information related to data and YSTEM ROPERTIES IALO communication.
  • Page 87 Email Server Tab The E is used to configure Lumin TekLink to send email alerts. Enter the MAIL ERVER SMPT server from which the email will be sent, along with its corresponding port. If the mail account uses a Secure Sockets Layer (SSL) security login enter the Account (User Name) and Password for the account.
  • Page 88 Email Alerts Tab The E is used to choose events for email alerts and designate to whom MAIL LERTS the alerts will be sent. NOTE To enable email alerts, ensure “Allow the TekLink server to send email alerts” is selected on the Email Server Tab of the System Properties Dialog. Figure 3-26 System Properties - Email Alerts Tab Enable email alerts by selecting the S ...
  • Page 89 Figure 3-27 History Filter for Email Events Dialog Data Tab The D displays the default location where Lumin TekLink stores methods, schedules, configurations, instrument history, and archived data. NOTE The data storage location is not editable. Archive data immediately by selecting the “archive data right now” command or schedule regular intervals for archiving information.
  • Page 90 Figure 3-28 System Properties - Data Tab Connection Tab The C is used to accept controlling computer connections through a ONNECTION network, allowing remote access to Lumin TekLink. Connections are made according to instrument profiles created via T >S . The two radio buttons OOLS YSTEM ROPERTIES...
  • Page 91 Figure 3-29 System Properties - Connection Tab Miscellaneous Tab The M contains settings to enable/disable the on-screen I S C E L L A N E O U S alpha-numeric keyboard for use with a touchscreen computer. NOTE The keyboard can be reduced and closed. If closed it will be available again when the software is re-opened.

  • Page 92: About

    Lumin TekLink software and the firmware BOUT IALOG installed on the Lumin concentrator. When troubleshooting, information from the may be requested by a Teledyne Tekmar Customer Service representative. BOUT IALOG Information in the A can be printed by using the P...

  • Page 93: Diagnostics - Valves And Flows

    Figure 3-32 Diagnostics - Valves and Flows AQUATek 100 The AQUAT 100 D provides manual control of the AQUATek 100 autosampler and IALOG should be only be used for diagnostics and troubleshooting. Caution Exercise caution when using the motor diagnostics. Damage to the AQUATek 100 autosampler can result.
  • Page 94 Figure 3-33 AQUATek100 Dialog View History Log The V displays the H . The S ISTORY ISTORY IALOG AMPLE ISTORY and E display their respective events. NSTRUMENT ISTORY RROR ISTORY Figure 3-34 History Form - Instrument History Sample, instrument, and error events can be filtered so that they are included/excluded using the C on each tab.
  • Page 95 NOTE Event filters can be returned to their default settings by using the “Click here to return to the default filter for this view link”. Figure 3-35 History Form Filter - Instrument History Upgrade Firmware The U is used to upgrade the firmware for the concentrator’s PGRADE IRMWARE UTTON...

  • Page 96: Create An Instrument Profile

    Benchmark The B starts the Benchmark function. The benchmark test is an ENCHMARK UTTON interactive program that tests heaters, LEDs, and the continuity of inputs and outputs on the CPU board. During the benchmark test the system will present a series of questions to the user.
  • Page 97 Figure 3-37 Creating an Instrument Profile Select the default USB Connection check-box.  Select the OK B to save the instrument profile.  UTTON On the O PTIONS  If you would like the concentrator to notify you of errors enable the beeper option.
  • Page 98 Figure 3-38 Options Tab On the L HECK  Customize Leak Check Time, pressure settings and delta, or use the default settings. Figure 3-39 Leak Check Tab Chapter 3: Lumin TekLink Software Overview 3 - 34 Lumin User Manual...

  • Page 99: Connect To An Instrument Profile

    3. Select the OK B to create the Instrument Profile. UTTON Lumin TekLink will automatically connect to the new profile, and the I NSTRUMENT and S will display the connected TATUS ANEL ETHODS CREEN CHEDULES CREEN instrument profile name. Once a profile is created, methods, schedules, system properties, and preferences can be saved to that profile when it is connected.

  • Page 100: Deactivate An Instrument Profile

    Figure 3-40 Instrument Manager 5. Select the C to connect to the profile. ONNECT UTTON 6. Once connected, a check mark will appear in the box beside the profile. NOTE The Instrument Status Panel and the title bar on the Method and Schedules Screens will display the instrument profile name.

  • Page 101: Creating A Method

    3.10 Creating a Method NOTE The Lumin Default method cannot be overwritten. If it is opened and revised, it must be saved under a different name. If necessary connect to the appropriate instrument profile. The current instrument profile is shown on the I and the title bar of the M NSTRUMENT TATUS...

  • Page 102: Save The Method

    3.10.1 Save the Method NOTE The Lumin default method cannot be overwritten. If it is opened and revised it must be saved under a different method name. 1. Save the new method by selecting the S . Name the method, then select UTTON the O UTTON...

  • Page 103: Open A Method

    Figure 3-43 New method Saved - Name in Title Bar New Method Name 3.11 Open a Method Use the O on the M to open an existing or archived method. UTTON ETHODS CREEN Use the S to select the current or archived location. OURCE NOTE Methods are specific (saved) to each Instrument Profile and cannot be opened...
  • Page 104 Figure 3-44 Methods Screen Figure 3-45 Open Method Dialog Select Method NOTE The Instrument Status Panel and the title bar on the Methods and Schedules Screens will display the opened method. Chapter 3: Lumin TekLink Software Overview 3 - 40 Lumin User Manual...

  • Page 105: Print A Method

    Figure 3-46 25 mL Method Open Method Opened 3.11.1 Print a Method Print Method Use the P on the M to print the current or completed RINT UTTON ETHODS CREEN method. A P will be displayed. RINT IALOG Figure 3-47 Method Print Dialog Chapter 3: Lumin TekLink Software Overview 3 - 41 Lumin User Manual...
  • Page 106 3.12 Creating a Schedule NOTE Multi-line schedules can only be created when the Lumin is combined with the AQUATek 100 autosampler. If no autosampler is installed, schedules are limited to one line. NOTE The schedule is created using a combination of manual entries, drop-down menus and right-click options on each line.
  • Page 107 3. Use the following commands to build the schedule: NOTE A Vial ID Column can be added via Tools>Options. Use Column Select or deselect the U to include/exclude the schedule line from the HECK current schedule. The use check-box is an easy way to easily modify a previously created schedule.
  • Page 108 Choose Method The method for each line of the schedule can be chosen in one of two ways: 1. Double-click in the method column to display the O ETHOD IALOG 2. Right-click in the M and select C to display the O ETHOD OLUMN HOOSE...

  • Page 109: Save Schedule

    Figure 3-51 Schedules Screen Right-Click Options 3.12.1 Save Schedule Use the S to save the active schedule. The S will display the S UTTON UTTON where a name for the schedule can be entered. Select the O CHEDULE IALOG to save the schedule. UTTON Figure 3-52 Save Schedule Chapter 3: Lumin TekLink Software Overview...

  • Page 110: Load (Run) The Schedule

    3.12.2 Load (Run) the Schedule To run the schedule, select the L on the S . The S UTTON CHEDULES CREEN TATUS will update to P , indicating that the concentrator is heating to OLUMN ENDING temperature set-points. The I will update with the current NSTRUMENT TATUS...

  • Page 111: Abort A Sample Or Schedule

    3.12.3 Abort a Sample or Schedule 1. To Abort a sample or schedule that has been loaded to the concentrator use the on the S or the I BORT UTTON CHEDULES CREEN NSTRUMENT TATUS ANEL 2. Once aborted, Lumin TekLink will ask if the abort command is for: 1.
  • Page 112 Figure 3-56 Confirm Selected, Schedule Aborted Step Schedule Use the S to sequentially move through each of the concentrator’s modes. UTTON When using the S , use the I to view the current UTTON NSTRUMENT TATUS ANEL mode of the concentrator. Hold Schedule Once the schedule has been loaded to the concentrator the H can be used to...
  • Page 113 Figure 3-57 Schedule Hold - Instrument Status Panel Print Schedule Use the P on the S to print the current or completed RINT UTTON CHEDULES CREEN schedule. A P will be displayed. RINT IALOG Open Schedule Use the O on the S to open an existing or archived schedule.
  • Page 114 Chapter 3: Lumin TekLink Software Overview 3 - 50 Lumin User Manual...

  • Page 115: Chapter 4: Instrument Operations

    Lumin User Manual Chapter 4: Instrument Operations 4.1 Concentrator Mode Descriptions The concentrator system performs a programmed series of operating steps. These steps are referred to as modes and vary depending on installed equipment and your system configuration. Mode descriptions are provided inTable 4-1 "Lumin Mode Descriptions" and more specific descriptions for the Lumin combined with the AQUATek 100 autosampler are given in Table 4-3 "Lumin with AQUATek 100 - Valve Output Chart".
  • Page 116 Table 4-1 Lumin Mode Descriptions Mode Description Standby This mode indicates that the system is waiting for all temperature zones and flow rates to reach their set-points. Purge Ready This mode indicates all method set-points are at equilibrium and the concentrator is ready to analyze samples.

  • Page 117: Lumin Valve Output Chart

    4.2 Lumin Valve Output Chart Table 4-2 Lumin Valve Output Chart Mode Description Variables Default Min Max Unit MFC Purge Vent Drain Aux 6-port This mode indi- 500 mL/min cates that the Trap Temp ° C system is wait- Transfer ing for all tem- °...
  • Page 118 Table 4-2 Lumin Valve Output Chart (Continued) Mode Description Variables Default Min Max Unit MFC Purge Vent Drain Aux 6-port When the Lumin Preheat is working in Time conjunction with an external sample heater, Preheat Purge (A) ON this mode allows Preheat °...
  • Page 119 Table 4-2 Lumin Valve Output Chart (Continued) Mode Description Variables Default Min Max Unit MFC Purge Vent Drain Aux 6-port This mode is used to drain the sample from the sparger and send it to a Drain waste container. Drain Flow 500 mL/min Desorb (B) OFF This mode...

  • Page 120: Lumin With Aquatek 100 Valve Output Chart

    4.3 Lumin with AQUATek 100 Valve Output Chart Table 4-3 Lumin with AQUATek 100 - Valve Output Chart Mode Description Variables Default Min Max Unit MFC Purge Vent Drain Bake 6-port This modes indi- 500 mL/min cates that the Trap Temp °C system is wait- Transfer Line...
  • Page 121 Table 4-3 Lumin with AQUATek 100 - Valve Output Chart (Continued) Mode Description Variables Default Min Max Unit MFC Purge Vent Drain Bake 6-port When the Lumin is con- nected to a liq- autosampler, this mode indi- cates that a liq- uid sample is being intro- duced into the...
  • Page 122 Table 4-3 Lumin with AQUATek 100 - Valve Output Chart (Continued) Mode Description Variables Default Min Max Unit MFC Purge Vent Drain Bake 6-port When the Lumin is con- nected to a liq- Purge autosampler, Loop Purge Loop (dur- 0.25 Desorb (B) ON this mode Time...
  • Page 123 Table 4-3 Lumin with AQUATek 100 - Valve Output Chart (Continued) Mode Description Variables Default Min Max Unit MFC Purge Vent Drain Bake 6-port When the Lumin is con- nected to a liq- autosampler, this mode allows hot water Bake Fill Bake Fill Time 0.25 Purge (A)

  • Page 124: Optimization

    Table 4-3 Lumin with AQUATek 100 - Valve Output Chart (Continued) Mode Description Variables Default Min Max Unit MFC Purge Vent Drain Bake 6-port This mode is Bake Time used to heat Bake Flow 500 mL/min and backflush the analytical Bake trap and con- Purge (A)

  • Page 125: Purge Ready Mode

    If an autosampler is being used in conjunction with the Lumin, a higher standby temperature may be selected for the trap and condenser since these zones will continue to cool after the Lumin has advanced to purge ready. This can be done since the autosampler will require a period of time to prepare the next sample.

  • Page 126: Purge Mode

    4.4.6 Purge Mode During Purge Mode, gas is passed through the sample. This causes volatiles to be removed for analysis. Purge has two controlling factors: the duration of purging and the flow rate of the gas. This determines the total amount of gas passed through the sample referred to as the purge volume.

  • Page 127: Desorb Mode

    4.4.10 Desorb Mode In desorb, the 6-port valve rotates to backflush analytes from the analytical trap to the GC. You must select time and temperature values for desorb. The temperature should be selected on the basis of what type of trap you are using. The desorb temperature range is 20-350 °C.

  • Page 128: Analytical Trap Recommended Operating Conditions

    4.4.13 Analytical Trap Recommended Operating Conditions Table 4-5 Analytical Trap Recommended Operating Conditions Description Part # Standby Desorb Desorb Bake Temp Purge Purge Purge Preheat Temp Temp Flow Time Temp Temp (#1) Tenax® 12-0083-403 (#1A) Tenax® 12-0083-503 (#2) Tenax®/Silica Gel 12-0084-403 (#3) Tenax®/Silica Gel/Charcoal 14-0124-403...

  • Page 129: Chapter 5: Maintenance And Troubleshooting

    DANGER - Débrancher le câble d’alimentation avant toutes interventions de maintenance et/ou d’entretien sur l’instrument. 5.1 Replacing Parts For replacement part numbers contact Teledyne Tekmar Customer Support using the information in Section 5.34 "Technical Assistance". WARNING Only use replacement parts supplied or approved by Teledyne Tekmar when performing maintenance on the Lumin.

  • Page 130: Preventative Maintenance Checks

    5.2 Preventative Maintenance Checks The following checklists outline the preventative maintenance required for continued successful operation of the Lumin. 5.2.1 Daily Maintenance Checks Table 5-1 Daily Maintenance Checklist Sample Purge Gas Verify the gas source is supplying an input pressure of 65 -100 psi Supply (4.48 bar -6.89 bar) to the Lumin.

  • Page 131: Preventative Maintenance Chart

    5.3 Preventative Maintenance Chart Table 5-4 Preventative Maintenance Chart Rate Action Check When Completed Daily Sample Purge Gas: 500+ psi (34.5+ bar) from tank Verify stage 2 pressure: 65 - 100 psi (4.48 bar -6.89 bar) Waste container has sufficient volume DI Water: fresh and ample supply Leak Check Initials &...

  • Page 132: Gc/Io Cable And Gc Type Reference

    5.4 GC/IO Cable and GC Type Reference NOTE If Table 5-5 "GC/IO Cable and GC System Reference" does not contain your GC System, contact Teledyne Tekmar Customer Support using the contact information in Section 5.34 "Technical Assistance". Table 5-5 GC/IO Cable and GC System Reference...

  • Page 133: Instrument Access Panels

    5.5 Instrument Access Panels The Lumin has the following access panels:  Sparger Panel Door  Analytical Trap Door  Left-Side Access Panel  Right-Side Access Panel  Top Access Panel Access panels are secured to the instrument chassis with phillips-head screws and locator pins.
  • Page 134 Figure 5-2 Analytical Trap Compartment and Sparger Panel Open Analytical Trap Sample Mount Sparger Valve Manifold Figure 5-3 Right Side of Lumin Top Access Panel Right Access Panel Chapter 5: Maintenance and Troubleshooting 5 - 6 Lumin User Manual...
  • Page 135 Figure 5-4 Left Side of Lumin Top Access Panel Left Access Panel Chapter 5: Maintenance and Troubleshooting 5 - 7 Lumin User Manual...

  • Page 136: Plumbing Overview

    5.6 Plumbing Overview NOTE Also refer to Section A.2 "Lumin Plumbing Diagram". Figure 5-5 Plumbing Components Moisture Control System Analytical Trap Sample Mount and Sparger 4-Way Tee 6-Port Valve Valve Manifold 3-Port Sample Valve Chapter 5: Maintenance and Troubleshooting 5 - 8 Lumin User Manual...
  • Page 137 Figure 5-6 Plumbing Components Check Valve Pencil Filter Valves 6-Port Valve Drain and Controller Carrier Gas Lines Chapter 5: Maintenance and Troubleshooting 5 - 9 Lumin User Manual...

  • Page 138: Electrical Overview

    5.7 Electrical Overview NOTE Also refer to Section A.1 "Lumin Electrical Schematic". 5.7.1 Power Supplies Figure 5-7 5 VDC (Left) and 24 VDC (Right) Power Supplies 5VDC Power Supply 24VDC Power Supply Chapter 5: Maintenance and Troubleshooting 5 - 10 Lumin User Manual...

  • Page 139: Printed Circuit Boards

    5.7.2 Printed Circuit Boards The Lumin has three primary Printed Circuit Boards (PCB): Multi-Channel Temperature Control Board  DC Valve Control Board  CPU Communication Board  Locations of the boards are shown in Figure 5-8. Diagrams of the boards are affixed to the interior of the concentrator, as well as shown in relevant maintenance procedures.

  • Page 140: Glassware Cleaning Procedures

    Consult your laboratory’s standard operating procedures for keeping glassware clean. In addition to your standard glassware protocol Teledyne Tekmar recommends the following:  Clean only with DI water and do not use soaps or cleaning products which could introduce contamination.

  • Page 141: Sparger Replacement

    5.9 Sparger Replacement Tools Required 1/2” Open-ended Wrench  1/4” Open-ended Wrench  Procedure Warning! - Hot surface! Turn OFF power to the Lumin and remove the AC power line from the back of the instrument. Allow the Sample Mount and surrounding area to cool to room tempera- ture.
  • Page 142 1. Turn the unit off, remove the AC power cord and allow the Sample Mount and surrounding areas to cool. 2. Open the Sparger Panel Door on the front of the Lumin concentrator. NOTE The guard has a keyhole slotted hinge that can be removed by lifting the guard up and out if necessary.

  • Page 143: Analytical Trap Replacement

    5.10 Analytical Trap Replacement Tools Required Phillips-head Screwdriver  3/8” Open-ended Wrench  7/16” Open-ended Wrench  Figure 5-10 Analytical Trap Compartment Figure 5-11 Analytical Trap Diagram Chapter 5: Maintenance and Troubleshooting 5 - 15 Lumin User Manual...
  • Page 144 Procedure Warning! - Hot surface! The trap and surrounding areas can be extremely hot. Allow adequate time to cool. Warning! - To avoid electrical shock turn OFF and unplug the Lumin before servicing. 1. Turn the unit off, remove the power cord, and allow the instrument to cool to room temperature.
  • Page 145 3. The analytical trap is connected at the top of the compartment using a 3/8” male nut on one side and a 7/16” female nut on the other. Using an open-ended wrench loosen both nuts and remove the analytical trap. Figure 5-13 Analytical Trap Connections 7/16”...

  • Page 146: Analytical Trap Conditioning

    5.11 Analytical Trap Conditioning NOTE Refer to 4.4.12 "Analytical Trap Recommended Conditioning Settings" or the trap manufacturer’s instructions for conditioning. 1. From the H select the T to display the T . Select CREEN OOLS UTTON OOLS CREEN the B to display the B UTTON IALOG...

  • Page 147: Analytical Trap Heater Jacket

    5.12 Analytical Trap Heater Jacket Tools Required 3/8” Open-ended Wrench  7/16” Open-ended Wrench  Figure 5-15 Analytical Trap Compartment Figure 5-16 Analytical Trap Diagram Chapter 5: Maintenance and Troubleshooting 5 - 19 Lumin User Manual...
  • Page 148 Procedure Warning! - Hot surface! The trap and surrounding areas can be extremely hot. Allow adequate time to cool. Warning! - To avoid electrical shock turn OFF and unplug the Lumin before servicing. 1. Turn the unit off, remove the power cord, and allow the instrument to cool to room temperature.

  • Page 149: Analytical Trap Cooling Fan

    5.13 Analytical Trap Cooling Fan Figure 5-18 Analytical Trap Cooling Fan Tools Required  Phillips-head Screwdriver  M4 Nut-Driver or Open-Ended Wrench  Wire Clippers Procedure Warning! - To avoid electrical shock turn OFF and unplug the Lumin before servicing. 1.
  • Page 150 Figure 5-19 DC Valve Printed Circuit Board (PCB) 4. Clip any wire ties binding the fan electric cable to other wiring, so that it can be removed. 5. Remove the two M4 kep-nuts that secure the fan mounting bracket to the ceiling of the right compartment.
  • Page 151 Figure 5-20 Analytical Cooling Fan Mounting Bracket 6. Remove the two phillips securing the fan to the mounting bracket. 7. Secure the new fan to the fan mounting bracket using the previously removed phillips-head screws. 8. Install the fan mounting bracket to the ceiling of the right compartment using the previously removed M4 kep-nuts.
  • Page 152 Figure 5-21 Analytical Trap Cooling Fan Opening at Insulation Box 9. Route the fan electrical cable toward the back of the concentrator and plug it into location J5 on the Valve Printed Circuit Board (PCB). Tuck the cable into any wire holders and install new wire ties to secure the cable.

  • Page 153: Mcs Cooling Fan

    5.14 MCS Cooling Fan Figure 5-22 MCS Cooling Fan Tools Required Phillips-head Screwdriver  Wire clippers  Procedure Warning! - To avoid electrical shock turn OFF and unplug the Lumin before servicing. 1. Turn the unit off and remove the AC power cord. 2.
  • Page 154 Figure 5-23 DC Valve Printed Circuit Board (PCB) 4. Clip any wire ties binding the fan electric cable to other wiring, so that it can be removed. 5. Remove the two phillips securing the fan, then pull the fan and electric cable from the chassis.
  • Page 155 Figure 5-24 MCS Cooling Fan Cable Routing 8. Route the fan electrical cable toward the back of the concentrator and plug it into location J6 on the Valve Printed Circuit Board (PCB). Tuck the cable into any wire holders and install new wire ties to secure the cable. 9.

  • Page 156: Pencil Filter Replacement

    5.15 Pencil Filter Replacement Tools Required Phillips-head Screwdriver  Two 7/16” Open-ended Wrenches  The Pencil Filter removes impurities from the carrier gas. When ghost peaks start appearing in the chromatograms, often the pencil filter needs to be replaced. Procedure Warning! - To avoid electrical shock turn OFF and unplug the Lumin before servicing.

  • Page 157: Check Valve

    5.16 Check Valve The check valve prevents back flow into the pencil filter and beyond. A common symptom that the check valve needs to be replaced is when a high level of carryover is observed. Tools Required  Phillips-head Screwdriver ...

  • Page 158: Valve Manifold Replacement

    5.17 Valve Manifold Replacement Tools Required Phillips-head Screwdriver  Warning! - To avoid electrical shock turn OFF and unplug the Lumin before servicing. Turn the unit off and remove the AC power cord. 1. Open the analytical trap door, remove the right-side panel, and locate the valve manifold (Figure 5-27).

  • Page 159: Valve Replacement

    NOTE If you are replacing a bad valve, make sure you replace the correct one based on the troubleshooting symptoms and the labels on the Valve Manifold. 6. Reinstall the valves and valve gaskets to the new valve manifold using the retained phillips-head screws.
  • Page 160 Figure 5-28 Front and Back Valve Manifold 2. Identify the valve to be replaced. NOTE Make sure you replace the correct valve based on the troubleshooting symptoms and the labels on the Valve Manifold. 3. Disconnect the electrical connections at the back of the valve to be replaced by pulling it straight out.

  • Page 161: Moisture Control System (Mcs)

    5.19 Moisture Control System (MCS) Tools Required Phillips-head screwdriver  3 mm Hex wrench  3/8” Open-ended wrench  Procedure Warning! - Hot surface! The trap and surrounding areas can be extremely hot. Allow the Analytical Trap and MCS to cool to room temperature.
  • Page 162 Figure 5-30 MCS Cover Plate Removal 5. Remove the nut on the top of the MCS that connects the 6-port valve tubing to the MCS (Figure 5-31). 6. Loosen the two hex set screws that secure the RTD and cartridge heater in the MCS block (Figure 5-31).

  • Page 163: Mass Flow Controller (Mfc)

    5.20 Mass Flow Controller (MFC) Tools Required Phillips-head Screwdriver  5/16” Open-ended Wrench  7/16” Open -ended Wrench  Procedure Warning! - To avoid electrical shock turn OFF and unplug the Lumin before servicing. 1. Turn the unit off, unplug the AC power cord, and turn off the gas supply to the unit. 2.

  • Page 164: 6-Port Valve

    4. Disconnect the blue gas supply line using a 7/16” wrench and the out gas line using a 5/16” wrench. 5. Remove the three mounting screws at each corner of the base plate and remove the MFC. 6. Remove the barrel connector plug on the top of the MFC and insert it into the barrel connector opening on the top of the new MFC.

  • Page 165: Power Entry Module (Pem) Fuse Replacement

    This section explains the procedure for replacing blown fuses. If a fuse has blown, the root cause of the blown fuse should be determined before repowering the instrument. If you require assistance, contact Teledyne Tekmar Customer Service using information in Section 5.34 "Technical Assistance".
  • Page 166 Figure 5-34 Lumin Power Entry Module (PEM) To avoid electrical shock turn OFF and unplug the Lumin before servicing. 1. Ensure the Lumin is OFF and the AC power cable removed rom the back of the unit. 2. Open the hinged fuse module cover by inserting a small flat-head screwdriver at the top, and then pulling the cover down.

  • Page 167: Fuse Module Removed

    Figure 5-36 Fuse Module Removed 4. Remove the blown fuse(s). 5. Install fuses by pressing them into the fuse module. The correct fuse ratings and specifications are listed on the back of the instrument below the PEM as well as in Table 5-7 "Lumin Fuse Ratings (2 IEC 5 x 20 mm Fuses)".

  • Page 168: Multi-Channel Temperature Control Board Fuse Replacement

    5.23 Multi-Channel Temperature Control Board Fuse Replacement Tools Required Phillips-head screwdriver  Insulated Flat-head screwdriver  Procedure Warning! - To avoid electrical shock turn OFF and unplug the Lumin before servicing. 5.23.1 Main Fuse 1. Turn the unit off, remove the AC power cord, remove the right access panel, and locate the Temperature Control Board.
  • Page 169 2. Using a properly insulated flathead screwdriver, pry the plastic cover off of the main fuse compartment. Figure 5-39 Multi-Channel Temperature Control Board Diagram - Main Fuse Main Fuse 3. Carefully pry the fuse at location “F_AC” from the fuse compartment. Chapter 5: Maintenance and Troubleshooting 5 - 41 Lumin User Manual...

  • Page 170: Heater Output Fuses

    4. Carefully insert a new fuse, rated according to Table 5-8 "Main Fuse", in the fuse compartment. Table 5-8 Main Fuse Heated Zone Fuse Location Fuse Rating J_AC F_AC 10 Amps DANGER Do not use a fuse of any other rating. 5.
  • Page 171 2. Refer to Figure 5-41 to locate the appropriate heater output fuse(s). Heater output fuses are cylinder shaped fuses located adjacent to each heated zone at the top of the board. Heated zones are identified on the board (AA, JJ, etc.) The fuse that corresponds to each zone will have the same letter identifier prefixed by the letter “F”.

  • Page 172: Multi-Channel Temperature Control Pcb Replacement

    3. Carefully pry the fuse out of the board at appropriate location. 4. Carefully insert a new fuse, rated according to Table 5-9 "Heater Output Fuses", into the board ensuring both pins of the fuse are aligned with the receiving holes. Table 5-9 Heater Output Fuses Heated Zone Fuse Location...
  • Page 173 Procedure Warning! - To avoid electrical shock turn OFF and unplug the Lumin before servicing. 1. Turn the unit off and remove the AC power cord. 2. Remove the right access panel and locate the Multi-Channel Temperature Control Board. Figure 5-43 Multi-Channel Temperature Control Board Chapter 5: Maintenance and Troubleshooting 5 - 45 Lumin User Manual...
  • Page 174 Figure 5-44 Multi-Channel Temperature Control Board Diagram Chapter 5: Maintenance and Troubleshooting 5 - 46 Lumin User Manual...

  • Page 175: Cpu Communication (Master) Pcb Replacement

    NOTE Use a grounding strap during the removal/installation procedure to prevent electrostatic discharge. 3. Disconnect all electrical connections from the Multi-Channel Temperature Control Board. NOTE Note the location of the electrical connections. There are multiple identical connections on this board. Make sure that the labels on the connectors are visible or make your own label with a piece of tape.
  • Page 176 Procedure Warning! - To avoid electrical shock turn OFF and unplug the Lumin before servicing. 1. Turn the unit off and remove the AC power cord. 2. Remove the right access panel and locate the CPU Communication Board (Master Board) (See Figure 5-11). Figure 5-46 CPU Communication Board (Master Board) Chapter 5: Maintenance and Troubleshooting 5 - 48...
  • Page 177 Figure 5-47 CPU Communication Board (Master Board) Diagram NOTE Use a grounding strap during the removal/installation procedure to prevent electrostatic discharge. 3. Disconnect all external connections to the CPU Communication Board (Master Board) at the rear of the unit (USB, GC/IO, Autosampler, etc.) and remove the cable mounting hex nut studs that the exterior cable connections screw into.

  • Page 178: Dc Valve Control Pcb Replacement

    NOTE Note the location of the electrical connections. 5. Remove the PCB retaining screw and retain for reinstallation. 6. Remove the PCB by pulling it away from the mounting studs. 7. Install the new PCB using the retaining screw removed earlier in this procedure. 8.
  • Page 179 Procedure Warning! - To avoid electrical shock turn OFF and unplug the Lumin before servicing. 1. Turn the unit off and remove the AC power cord. 2. Remove the right access panel and locate the DC Output Board. Figure 5-49 DC Valve Control Board Chapter 5: Maintenance and Troubleshooting 5 - 51 Lumin User Manual...
  • Page 180 Figure 5-50 DC Valve Control Board NOTE Use a grounding strap during the removal/installation procedure to prevent electrostatic discharge. 3. Disconnect all electrical connections from the DC Valve Control Board. NOTE Note the location of the electrical connections. There are multiple identical connections on this board.

  • Page 181: 5Vdc Power Supply Replacement

    5.27 5VDC Power Supply Replacement Tools Required Phillips-head screwdriver  Grounding strap  Procedure Warning! - To avoid electrical shock turn OFF and unplug the Lumin before servicing. Figure 5-51 5 V DC Power Supply 1. Turn the unit off and remove the AC power cord. 2.
  • Page 182 NOTE Use a grounding strap during the removal/installation procedure to prevent electrostatic discharge. 4. Disconnect all electrical connections from the 5VDC Power Supply, NOTE Note the location of the electrical connections. 5. Remove the power supply retaining screw and retain for reinstallation. 6.

  • Page 183: 24Vdc Power Supply Replacement

    5.28 24VDC Power Supply Replacement 1. Turn the unit off and remove the AC power cord. 2. Remove the left access panel and locate the 24VDC Power Supply. 3. Remove the protective cover over the power supply by removing the screws that secure it.

  • Page 184: Upgrade Firmware

    5.29 Upgrade Firmware First download the firmware and then install it according to the directions below. 5.29.1 Download Firmware 1. Click this hyperlink: Software Downloads (www.teledynetekmar.com/resources/downloads) or go to the software downloads page at www.teledynetekmar.com 2. Under VOC Firmware and Software, find the appropriate firmware update. 3.

  • Page 185: Troubleshooting

    5.31 Troubleshooting 5.31.1 Benchmark Test The B is a troubleshooting tool that tests the components and ENCHMARK software routines (heaters, LEDs, continuity of inputs and outputs on the CPU board, etc.) to ensure that the concentrator is in working order. If any sequence of the benchmark test fails, the failure should be addressed before analysis of samples is attempted.

  • Page 186: Benchmark Test Prompt

    Figure 5-56 Benchmark Test Prompt 4. As the benchmark test is conducted, Lumin TekLink will prompt the user for responses. Read the prompt and respond accordingly using the buttons in the ENCHMARK INDOW 5. Prior to completion of the test, Lumin TekLink will prompt if the benchmark test results should be printed.

  • Page 187: Initial Leak Check

    5.31.2 Initial Leak Check A leak check can be initiated by navigating to T >L . Once initiated, OOLS HECK UTTON the I will indicate that the leak Check is in progress. NSTRUMENT TATUS CREEN Figure 5-58 Instrument Status During Leak Check Figure 5-59 illustrates the path of events that occur during a Leak Check sequence.
  • Page 188 Figure 5-59 Leak Checking Flow Chart Chapter 5: Maintenance and Troubleshooting 5 - 60 Lumin User Manual...

  • Page 189: Advanced Leak Check Guidelines

    5.31.3 Advanced Leak Check Guidelines If the instrument fails the leak checking sequence as outlined in Section 5.31.2 "Initial Leak Check", the Advanced Leak Check should be performed to isolate the problem area. The Advanced Leak Check manually isolates sections of the pressurized system and then checks the integrity of each component connection.
  • Page 190 Figure 5-62 Vent Valve on Valve Manifold 2. Isolate the drain valve and drain line by turning the flow switch on the three-port sample valve to the left position (closed). Figure 5-63 Sample Valve Flow Switch  If the unit fails the leak check proceed to step 3. ...
  • Page 191 Figure 5-64 Purge Valve Normally Open (NO) tubing to the 4-Way Tee  If the system passes, then the leak is between the Mass Flow Controller (MFC) and Valve Manifold. If the system fails, then the leak is between the valve manifold and port ...

  • Page 192: Advanced Leak Checking Flow Chart

    5.31.4 Advanced Leak Checking Flow Chart Chapter 5: Maintenance and Troubleshooting 5 - 64 Lumin User Manual...

  • Page 193: No Power Flow Chart

    5.31.5 No Power Flow Chart NOTE Refer to Section 5.22 "Power Entry Module (PEM) Fuse Replacement" for information on accessing the PEM fuses. Figure 5-65 No Power Flow Chart Chapter 5: Maintenance and Troubleshooting 5 - 65 Lumin User Manual...

  • Page 194: Top-Of-Trap (Tot) Injection Port

    5.31.6 Top-of-Trap (TOT) Injection Port NOTE It is recommended that a Leak Check be performed according to Section 5.31.2 "Initial Leak Check" before the TOT injection port is installed to confirm that the system is leak tight. A TOT injection port can be installed into the Sample Mount of the Lumin to aid in troubleshooting potential problems associated with the concentrator or in the evaluation of purge efficiencies of target analytes.
  • Page 195 Install the Assembled TOT Injection Port NOTE If both an autosampler and the foam eliminator are installed on the unit, one of them must be removed. Otherwise, the autosampler can remain in place and the TOT injection port can be installed into the other available mount fitting. ™...
  • Page 196 TOT Injection Port Assembled and Installed Figure 5-68 Figure 5-9: Software Configuration Once the TOT Injection Port fitting has been installed and is leak tight, perform the analyses in a standalone configuration (without autosampler). NOTE For SolaTek 72, non-Tekmar autosamplers or no autosampler, the unit is already configured as a standalone unit.
  • Page 197 Sample Mount. NOTE Teledyne Tekmar recommends the use of a 10 μL syringe or smaller for TOT injection to prevent the injection port septum from being “cored” and, subsequently, causing a leak.

  • Page 198: No Response Flow Chart

    5.31.7 No Response Flow Chart Figure 5-70 No Response Flow Chart Chapter 5: Maintenance and Troubleshooting 5 - 70 Lumin User Manual...

  • Page 199: Low Response Flow Chart

    5.31.8 Low Response Flow Chart Figure 5-71 Low Response Flow Chart Chapter 5: Maintenance and Troubleshooting 5 - 71 Lumin User Manual...

  • Page 200: Carryover Contamination Flow Chart

    Figure 5-72 Carryover Contamination Flow Chart 5.32 Returning the Lumin Do not return the Lumin unless a Teledyne Tekmar representative authorizes you to do so. A service representative may be able to help you solve the problem over the telephone. If the instrument must be returned, the representative can tell you how to prevent damage during shipment.

  • Page 201: Unit And Parts Disposal

    5.33 Unit and Parts Disposal Please contact Teledyne Tekmar or your local distributor for instructions on returning the system for proper disassembly and disposal. Contact Teledyne Tekmar Customer Support using information in Section 5.34.1 "Teledyne Tekmar Customer Support". 5.34 Technical Assistance If you need assistance solving a problem, follow the steps below: 1.
  • Page 202 Chapter 5: Maintenance and Troubleshooting 5 - 74 Lumin User Manual...

  • Page 203: Appendix A: Diagrams

    Lumin User Manual Appendix A: Diagrams Appendix A: Diagrams A - 1 Lumin User Manual...

  • Page 204: Lumin Electrical Schematic

    A.1 Lumin Electrical Schematic Figure A-1 Lumin Electrical Schematic Appendix A: Diagrams A - 2 Lumin User Manual...

  • Page 205: Lumin Plumbing Diagram

    A.2 Lumin Plumbing Diagram Figure A-2 Lumin Plumbing Diagram Appendix A: Diagrams A - 3 Lumin User Manual...

  • Page 206: Lumin Flow Diagrams

    A.3 Lumin Flow Diagrams A.3.1 Lumin - Basic Flow Diagram Figure A-3 Lumin - Basic Flow Diagram Appendix A: Diagrams A - 4 Lumin User Manual...

  • Page 207: Lumin - Standby Dry Purge Flow Diagram

    A.3.2 Lumin - Standby Dry Purge Flow Diagram Figure A-4 Lumin - Standby/Dry Purge Flow Diagram Appendix A: Diagrams A - 5 Lumin User Manual...

  • Page 208: Lumin Purge Flow Diagram

    A.3.3 Lumin Purge Flow Diagram Figure A-5 Lumin - Purge Flow Diagram Appendix A: Diagrams A - 6 Lumin User Manual...

  • Page 209: Lumin Desorb Flow Diagram

    A.3.4 Lumin Desorb Flow Diagram Figure A-6 Lumin - Desorb Flow Diagram Appendix A: Diagrams A - 7 Lumin User Manual...

  • Page 210: Lumin Bake Flow Diagram

    A.3.5 Lumin Bake Flow Diagram Figure A-7 Lumin - Bake Flow Diagram Appendix A: Diagrams A - 8 Lumin User Manual...

  • Page 211: Lumin With Guardian™ Foam Sensor (Gfs) & Eliminator Flow Diagramsa-9

    A.4 Lumin With Guardian™ Foam Sensor (GFS) & Eliminator Flow Diagrams A.4.1 Lumin With GFS & Eliminator - Basic Flow Diagram Defoamer Rinse Figure A-8 Lumin With GFS & Eliminator - Basic Flow Diagram A - 9 Lumin User Manual...

  • Page 212: Lumin With Gfs & Eliminator - Standby/Dry Purge Flow Diagram

    A.4.2 Lumin With GFS & Eliminator - Standby/Dry Purge Flow Diagram Defoamer Rinse Figure A-9 Lumin With GFS & Eliminator - Standby/Dry Purge Flow Diagram A - 10 Lumin User Manual...

  • Page 213: Lumin With Gfs & Eliminator - Eliminator Ready Flow Diagram

    A.4.3 Lumin With GFS & Eliminator - Eliminator Ready Flow Diagram Defoamer Rinse Figure A-10 Lumin With GFS & Eliminator - Eliminator Ready Flow Diagram A - 11 Lumin User Manual...

  • Page 214: Lumin With Gfs & Eliminator - Purge Flow Diagram

    A.4.4 Lumin With GFS & Eliminator - Purge Flow Diagram Defoamer Rinse Figure A-11 Lumin With GFS & Eliminator - Purge Flow Diagram A - 12 Lumin User Manual...

  • Page 215: Lumin With Gfs & Eliminator - Add Defoamer Flow Diagram

    A.4.5 Lumin With GFS & Eliminator - Add Defoamer Flow Diagram Defoamer Rinse Figure A-12 Lumin With GFS & Eliminator - Add Defoamer Flow Diagram A - 13 Lumin User Manual...

  • Page 216: Lumin With Gfs & Eliminator - Eliminator Rinse Flow Diagram

    A.4.6 Lumin With GFS & Eliminator - Eliminator Rinse Flow Diagram Defoamer Rinse Figure A-13 Lumin With GFS & Eliminator - Eliminator Rinse Flow Diagram A - 14 Lumin User Manual...

  • Page 217: Lumin With Gfs & Eliminator - Desorb Flow Diagram

    A.4.7 Lumin With GFS & Eliminator - Desorb Flow Diagram Defoamer Rinse Figure A-14 Lumin With GFS & Eliminator - Desorb Flow Diagram A - 15 Lumin User Manual...

  • Page 218: Lumin With Gfs & Eliminator - Bake Flow Diagram

    A.4.8 Lumin With GFS & Eliminator - Bake Flow Diagram Defoamer Rinse Figure A-15 Lumin With GFS & Eliminator - Bake Flow Diagram A - 16 Lumin User Manual...
