Page 1 Installation Manual 1200 SC ® SELF CONTAINED DFS AIR CLEANING SYSTEM...
Page 3 50/60Hz Phase 3 HealthWay’s DFS Technology (Disinfecting Filtration System) surpasses all other types of filtration. This revolutionary technology traps microorganisms such as bacteria, mold and viruses, reduces bioburden and inhibits microorganism’s growth through Microbiostatic condition, resulting in the most powerful indoor air purification in the world.
Page 4 This one year Limited Warranty applies only to the repair and replacement of any manufactured or supplied part of this product which, upon inspection by HealthWay authorized personnel, proves to have failed in normal use due to defects in material or workmanship. A return authorization must be obtained before any product is shipped to the manufacturer for warranty repair and all transportation charges must be prepaid all work must be performed by a HealthWay authorized technician.
Page 5 Self Contained DFS Air Cleaning 1200 SC Self Contained DFS Air Cleaning 8:00 AM-5:00 PM EST a HealthWay representative will help you troubleshoot and diagnose the problem. System System Warranty matters involving products sold through a manufacturer representative should be directed to the appropriate representative.
Page 6: Table Of Contents
Parts List ..................22 Troubleshooting ................23 DFS Troubleshooting Guide ............24 Figures and Schematics ............. 1-1 Figure A ..................1-1 1200SC-120-1AL Schematic ............1-2 1200SC-220-1AL Schematic ............1-3 1200SC-220-3AL Schematic ............1-4 1200SC-440-3AL Schematic ............1-5 #1005 ©HealthWay #1005 ©HealthWay 2015 2015...
Page 7: Safety Precautions
This symbol will be used throughout this manual to indicate safety checkpoints. Failure to heed these warnings and notices may result in damage to the unit and/or injury or death to personnel. #1005 ©HealthWay #1005 ©HealthWay 2015 2015...
Page 8: System Overview
Please confirm your model number and follow the instructions for that model. The electrical power requirements for each individual unit are on the data plate label adjacent to the electrical connections. These requirements supersede all other inferences to power requirements. #1005 ©HealthWay #1005 ©HealthWay 2015 2015...
Page 9: Component Description
Green LED to indicate HVPS power status. inspected at the factory and barring damage in transit, should be received in good condition. When a freight carrier signs the HealthWay bill of lading, the carrier accepts the responsibility for any Components...
Page 10: Installation Procedures
Do not install the filtration system in an exterior environment, unless it is specifically made for exterior installations. Standard units are for indoor use only. The wiring or strapping must be at least 350-pound test weight. #1005 ©HealthWay #1005 ©HealthWay 2015...
Page 11: Standard Inlet/Return Duct Connection
1200 SC Self Contained DFS Air Cleaning 1200 SC Self Contained DFS Air Cleaning System System Installation Procedures Installation Procedures ELECTRICAL CONNECTION STANDARD INLET / RETURN DUCT CONNECTION A 20” x 16” (out flanged) duct may be connected to the unit using the instructions below, refer to (fig-A)*: After mounting the electrical box, remove the electrical knock-out that is not being used.
Page 12 1200 SC Self Contained DFS Air Cleaning 1200 SC Self Contained DFS Air Cleaning System System larger figure if needed #10057 ©HealthWay #1005 ©HealthWay 2015 2015...
Page 13: System Operation
Turn on the Main Switch located on the top of the unit, it should illuminate, indicating the power is on, the Green LED should also come on. (fig-B,C) TO TURN OFF THE UNIT To turn off the unit, simply turn off the main switch located on the top of the unit. #1005 ©HealthWay #1005 ©HealthWay 2015 2015...
Page 14 1200 SC Self Contained DFS Air Cleaning 1200 SC Self Contained DFS Air Cleaning System System fig-B fig-C #1005 ©HealthWay #1005 ©HealthWay 2015 2015...
Page 15: Maintenance
Maintenance When replacing filters use only HealthWay certified filters. HealthWay filters are designed for high voltage operation. Use of non-HealthWay filters can be hazardous to personnel and equipment voiding the warranty. Always turn off the electrical switches and circuit breakers/disconnects before maintenance on the unit.
Page 16: V-Bank Main Filter Replacement
Reconnect the High Voltage Lead. (fig-7) Return the Filter Access Door. (fig-8) When returning the Filter Access Door, the Safety Switch Screw must be placed in the appropriate location to complete the electrical path through the Safety Switch. #1005 ©HealthWay #1005 ©HealthWay 2015 2015...
Page 17: Parts List
PARTS LIST For additional troubleshooting assistance refer to the DFS Troubleshooting Guide on the following page or contact HealthWay; Monday-Friday, 8am-5pm EST: HealthWay recommends that the following spare parts be available on-site at all times. Phone No: 315-298-2904 Order all parts by contacting:...
Page 18: Dfs Troubleshooting Guide
(H) Stand the V-Bank Main Filter and High Energy Grid Assembly up (as it sits in the unit) and inspect the gasket on the seal side of the Assembly. Replace the gasket if it is damaged #1005 ©HealthWay #1005 ©HealthWay...
Page 19 If the High Voltage Power Supply indicator light is on with no Voltage Multiplier attached the fault is either in the High Energy Grid or in the Voltage Multiplier. Variable Frequency Drive High Voltage Power Supply Voltage Multiplier #1005 ©HealthWay #1005 ©HealthWay fig-9 2015 2015...
Page 20 5.833 5.833 5.833 14 Total 14 Total 7.000 7.000 7.000 1.250 6.500 6.335 14.000 15.500 16.670 6.500 6.335 1.250 2.250 1.250 22.000 Inlet - Intake Side Duct Connection Outlet - Exhaust Side Duct Connection HealthWay Products, Inc 1200SC Installation Dimensions...
Page 26 ® ™ We breathe innovation...
