Memphis Shades 9874 Instructions And Parts List

1. Install the mounting plates onto the windshield using the pre-assembled bolts on the mounting plates. The
rubber grommet should be inserted through the holes in the windshield so that the flat round washer part
of the grommet lays flat on each side of the windshield. On each plate, get both started before you tighten
either. (see Figure 1.1 & 1.2)
Note: *(Wide)
2. Loosen the four mounting bolts that are to hold the mounting plates to the fork clamps, and slide the
mounting plates onto the fork clamps. (see Figure 3)
3. Adjust the height, angle, and alignment of the shield. Carefully check gas tank clearance, and tighten all
mounting bolts.
WARNING: This is a quick disconnect kit. Always tighten down all mounting bolts after removing or
installing the windshield every time.
Fig. 1.1 Left side plate
To clean your windshield, use only warm water and a mild non-abrasive, dishwashing liquid. Use a soft cloth,
such as a T-shirt or flannel cloth. To protect your windshield, please use Novus #2 to remove minor scratches,
or use a polish like Memphis Shades Shinola which is specially designed for plastic windshields; glass cleansing
agents will cause severe damage to your windshield and will void your warranty.
Never use any glass products, petroleum based chemicals, or cleaning agents with ammonia, bleach or any harsh
SPORTSHIELD MOUNTING KIT, KAWASAKI MEANSTREAK
INSTRUCTIONS / PARTS LIST
– Tabs point in towards each other.
Fig.1.2 Right side plate

Care and Cleaning Instructions

chemicals. This includes Rain-X, brake fluid, acetone, and gasoline.
MEM 9874
Fig. 3 Mounting plate
