16000/16200 Appliance Rear Panel
26000/28000 Appliance Rear Panel
Item
Description
1
Cooling fan unit (fan numbers 1 and 2) from right to left
2
Cooling fan unit (fan numbers 3 and 4) from right to left
3
ESD ground plug
4
Cooling fan screws
Note - 26000/28000 appliance fans are different from 16000/16200 fans, as there are 4
stacks of 2 fans.
Replacing Cooling Fans in Check Point 16000, 26000, and 28000 Security Appliances
16000, 26000, and 28000 Appliances Replacing Cooling Fans | 6
