Printed Matter No. 9839 0880 01
Publication Date 2021-04-12
Valid for Version No. 06.00x
Issue No. 13
STbench
Read all safety warnings and instructions
Failure to follow the safety warnings and instructions may result in
electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference
WARNING
STbench
Test Bench
Operation Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the STbench and is the answer not in the manual?

Questions and answers

Related Manuals for Atlas Copco STbench

Summary of Contents for Atlas Copco STbench

  • Page 1 STbench Printed Matter No. 9839 0880 01 Test Bench Publication Date 2021-04-12 Valid for Version No. 06.00x Operation Manual Issue No. 13 STbench WARNING Read all safety warnings and instructions Failure to follow the safety warnings and instructions may result in electric shock, fire and/or serious injury.

  • Page 2: Table Of Contents

    Powering Off the STbench with PC .............. 34 Operation ....................... 35 General Safety Information................ 35 Calibrating Power Focus - General Information.......... 35 Calibrating PowerMACS - General Information .......... 36 Calibrating generic controllers - General Information ........ 36 Articulated arm - General information............. 37 © Atlas Copco Industrial Technique AB - 9839 0880 01...
  • Page 3 Cleaning the STbench .................. 47 STbench .................... 47 Touch-screen.................. 47 Batteries replacement.................. 47 Oil replacement.................... 47 Backup of the database .................. 47 Basic troubleshooting .................. 48 "Zero Static Error" message is displayed ............ 48 "Over Torque Error" message is displayed............. 48 © Atlas Copco Industrial Technique AB - 9839 0880 01...

  • Page 4: General Data Protection Regulation (Gdpr)

    EU the GDPR as well as other applicable laws, directives and regula- tions. Atlas Copco can in no way be held liable for any use made by you of the product. © Atlas Copco Industrial Technique AB - 9839 0880 01...

  • Page 5: Legend Of Symbols

    STbench Legend of symbols Legend of symbols Below a list of the symbols found on the STbench: Symbol Description Crushing of hands Risk of electric shock Ethernet port USB port External transducer socket Documentation must be consulted © Atlas Copco Industrial Technique AB - 9839 0880 01...

  • Page 6: Introduction

    The STbench can operate on the assembly line simulating real joints characteristics with high precision: in this way test conditions are very similar to the real scenarios where tools usually work.

  • Page 7: Revision History

    Tool parameters updated (for more information, see "STbench with PC Configuration Manual / STpad Configuration Manual"). ■ Searching a Tool updated (for more information, see "STbench with PC Configuration Manual / STpad Configuration Manual"). ■ Connected transducers updated (for more information, see "STbench with PC Configuration Manual / STpad Configuration Manual").
  • Page 8 Measure screen added (for more information, see "STbench with PC Configuration Manual / STpad Configuration Manual"). ■ Reaction bar added (for more information, see "STbench with PC Con- figuration Manual / STpad Configuration Manual"). ■ Exporting STbench logs added (for more information, see "STbench with PC Configuration Manual / STpad Configuration Manual").
  • Page 9 "STbench with PC Configuration Manual / STpad Configuration Man- ual"). ■ Searching in a route updated (for more information, see "STbench with PC Configuration Manual / STpad Configuration Manual"). ■ Navigating a forced by piece route added (for more information, see "STbench with PC Configuration Manual / STpad Configuration Man-...
  • Page 10 General manual update (for more information, see "STbench with PC Configuration Manual / STpad Configuration Manual"). ■ Filtering a route added (for more information, see "STbench with PC Configuration Manual / STpad Configuration Manual"). ■ Results updated (for more information, see "STbench with PC Configu- ration Manual / STpad Configuration Manual").
  • Page 11 Traceability tag updated (for more information, see "STbench with PC Configuration Manual / STpad Configuration Manual"). ■ Open Protocol added (for more information, see "STbench with PC Con- figuration Manual / STpad Configuration Manual"). ■ General manual update ("STbench with PC Configuration Manual / STpad Configuration Manual").
  • Page 12 Searching a Route updated (for more information, see "STbench with PC Configuration Manual / STpad Configuration Manual"). ■ Editing a tool updated (for more information, see "STbench with PC Configuration Manual / STpad Configuration Manual"). ■ Tool inspections updated (for more information, see "STbench with PC Configuration Manual / STpad Configuration Manual").
  • Page 13 Introduction Software version Change ■ 03.00x Running a Route updated (for more information, see "STbench with PC Configuration Manual / STpad Configuration Manual"). ■ Dimensional inspection added (for more information, see "STbench with PC Configuration Manual / STpad Configuration Manual").
  • Page 14 General information updated (for more information, see "STbench with PC Configuration Manual / STpad Configuration Manual"). ■ Parts added (for more information, see "STbench with PC Configuration Manual / STpad Configuration Manual"). ■ Visual inspection (attribute, binary and dimensional) added (for more in- formation, see "STbench with PC Configuration Manual / STpad Config-...
  • Page 15 STbench Introduction Software version Change ■ 01.02x Results list (for more information, see "STbench with PC Configuration Manual / STpad Configuration Manual") ■ Calibration inspection (for more information, see "STbench with PC Configuration Manual / STpad Configuration Manual") ■ Controllers (for more information, see "STbench with PC Configuration Manual / STpad Configuration Manual")

  • Page 16: Operation Overview

    Handlebar STbench PC / STbench Docking Station There are two types of interfaces of STbench: the first one holds the PC, while the second one holds the Docking Station. The Docking Station is the housing of the STpad. Both PC and STpad have a touch-screen.

  • Page 17: Stbench Top Plate

    The static torque transducers are designed for testing wrenches, click wrenches or for tightening tools where rotary action is not desired during measurement. The number of static torque transducers on the STbench top plate ranges according to customer needs. The static torque transducers can be used to test: ■...

  • Page 18: Tilting Top Plate

    Tilting top plate The STbench can be equipped with a top plate that can be tilt with a maximum angle of 90 degrees. This configuration allows testing tools in horizontal position. Tilting top models require a different frame.

  • Page 19: Wrench Rig

    Push the button Vertical to tilt the plate to the vertical position (90 degrees). Push the button Horizontal to tilt the plate to the horizontal position (0 degrees). In this STbench model, an additional motor moves the top plate. Two limit-switches ensure that the motor stops when the limit positions are reached.

  • Page 20: Articulated Arm

    Motorized Cell The Motorized Cell is a torque transducer that can be installed on the STbench large frame in order to au- tomatize torque wrench tests, thus reducing the operator influence on the measurements.
  • Page 21 Unscrew the four M8x16 screws and remove the slide block (A) from the slide. Slide block Rotate the two handles (A) placed behind the safety cage and remove the slide extension (B). Handles Slide extension © Atlas Copco Industrial Technique AB - 9839 0880 01...
  • Page 22 Insert the slide extension into the slide and fasten it with four M8x16 screws. Insert the slide block into the slide extension and fasten it with four M8x16 screws. Open the safety cage by lifting the safety cage handle (A). Safety cage handle © Atlas Copco Industrial Technique AB - 9839 0880 01...
  • Page 23 Unscrew the reaction bar knob (A) and adjust the position of the support by sliding it forward or back- ward. When the support is correctly positioned in the middle of the handle, screw the reaction bar knob (B). Reaction bar knob © Atlas Copco Industrial Technique AB - 9839 0880 01...
  • Page 24 Unscrew the reaction bar knob (A) and push the reaction bar against the tool handle. When the tool is blocked on the support, screw the reaction bar knob (A). Reaction bar knob © Atlas Copco Industrial Technique AB - 9839 0880 01...
  • Page 25 Messages displayed when running a test on the Motorized Cell Below is a list of the safety and error messages that can be displayed when a test is run on the Motorized Cell: © Atlas Copco Industrial Technique AB - 9839 0880 01...
  • Page 26 Error: Test stopped, click not detected. Please, check the setting of the tool. Error: Test stopped, no torque detected during the test. Please, check that the tool is correctly positioned on the transducer. © Atlas Copco Industrial Technique AB - 9839 0880 01...

  • Page 27: Drawers

    Reaction bar ■ Safety Information ■ USB storage device (containing the STbench Manuals) ■ Power cables Main panel The main panel is the main interface between the STbench and the operator: © Atlas Copco Industrial Technique AB - 9839 0880 01...
  • Page 28 The main panel is marked with the following symbols: Symbol Description Ethernet port USB port External transducer socket Documentation must be consulted Below the main panel, the power supply socket: © Atlas Copco Industrial Technique AB - 9839 0880 01...

  • Page 29: Battery Status Indicators And Battery Charger Switch

    Turn the Battery Charger switch to 1 to activate the battery charger. When the Battery Charger switch is turned to 1 and the STbench is connected to a power plug, the white LED placed over the Battery Charger switch is on.

  • Page 30: Ethernet Port

    15 minutes the battery is not in charge yet. In case the battery is out of charge and the STbench powers off while the operator makes a tighten- ing during a test, the result of this tightening gets lost.

  • Page 31: Start Pc / Stop Pc

    For powering on/off the STbench press respectively Start PC and Stop PC. Power Supply socket From the Power Supply socket, connect the STbench to the AC Power with the correct power supply ca- ble. Do not use the power supply if the plug, the mains cable or other parts are damaged.

  • Page 32: Keyboard

    7 - PLUG PVC: KCS70-5001-85, BLACK Keyboard A keyboard is available into a small drawer placed on the front side panel of the STbench. The keyboard is useful for inserting input data into the STbench software. The keyboard has also an embedded mouse.

  • Page 33: Flange For Srtt-B

    To add an additional SRTT-B transducer on the bench, it is necessary to assemble the flange shown in the following figure. After assembling the flange on the top plate of the STbench, the SRTT-B transducer can be fix on the flange.

  • Page 34: Getting Started

    Powering On the STbench ■ Press Start PC for powering on both the STbench with PC and the STbench with Docking Station. A green light crown around Start PC button is always on during STbench operations. In case of STbench with PC, Windows homepage appears: click QA Inspector icon to start the STbench software.

  • Page 35: Operation

    IRC-Connect ACTA Serial cable / Ethernet cable It is possible to connect the STbench with PC with the Power Focus either with a serial cable or the Ether- net cable (see the schema above). The transducer / mechanical joint simulator / brake capacity must be compatible with the Power Focus programmed torque.

  • Page 36: Calibrating Powermacs - General Information

    STbench ■ The tool connected to Power Focus operates with the transducer (+existing application or mechanical joint simulator), connected to the IRC-Connect via cable. The IRC-Connect is connected to STbench via IRC-B. Calibrating PowerMACS - General Information Below is the list of the devices needed to calibrate a power tool with the PowerMACS: ■...

  • Page 37: Articulated Arm - General Information

    Articulated arm - General information The Articulated Arm is a special tool that may feature the STbench in order to increase the operating range of it. It allows positioning of the brake in case the tool location is located out of the action range of the entire bench.

  • Page 38: Technical Specifications Of The Articulated Arm

    The maximum torque of the Articulated Arm is 250 N·m. DO NOT overload the Articulated Arm: it could break with possible serious injuries otherwise. Do not open the Articulated Arm while the STbench is moving: the STbench may tip over. Ensure that the locking devices of the Articulated arm are also engaged.

  • Page 39: Installing The Articulated Arm On The Stbench

    Loosen the levers that lock the two mechanical blocks, located near the “Articulated arm support”. Then move each mechanical block along the support, as show in the figure: Lever Support Lever © Atlas Copco Industrial Technique AB - 9839 0880 01...

  • Page 40: Installing The Brake On The Articulated Arm

    The following operation MUST be performed by two people. Switch off the STbench. On the Pressure Indicator placed on the STbench main panel, check the oil pressure is equal to zero. Extend the Articulated arm in order to align it with the brake.
  • Page 41 On the upper side of the brake, install the protective flange by means of three screws (M4). Connect the cable coming from the Articulated Arm to the brake. © Atlas Copco Industrial Technique AB - 9839 0880 01...
  • Page 42 Higher connection point: oil leakage tube. ■ Lower connection point: plug to avoid leakage. Lock the locking device placed at the top of the Articulated Arm, as show in the picture below: Locking devices © Atlas Copco Industrial Technique AB - 9839 0880 01...
  • Page 43 Regulate the hardness of the two pistons placed on the Articulated Arm in order to balance the weight of the brake properly Handle to regulate the Handle to regulate the upper piston lower piston 10. Connect the Main oil connector to the relative connector. © Atlas Copco Industrial Technique AB - 9839 0880 01...

  • Page 44: Rotating The Brake Placed On The Articulated Arm

    Operation STbench 11. Working on the STbench, connect the cable coming from the Articulated Arm and the oil tubes as shown in the following picture: Main oil tube Oil leakage tube Signal cable 12. Lock the Articulated Arm within the two mechanical blocks: move the mechanical blocks until they are in contact with the Articulated Arm and tighten the respective levers.
  • Page 45 Lock the Articulated Arm within the two mechanical blocks placed on each side of it: slide the me- chanical blocks until they are in contact with the Articulated Arm and tighten the respective levers. © Atlas Copco Industrial Technique AB - 9839 0880 01...

  • Page 46: Doing A Test With A Brake Place On The Articuated Arm

    STbench Doing a test with a brake place on the Articuated arm For further details about how to execute a free test on the STbench according to the tool, refer to the “STbench Configuration Manual”. Unlock the locking device of the Articulated arm and arrange the Articulated Arm in the desired posi- tion.

  • Page 47: Basic Maintenance

    The STbench is best cleaned with a damp cloth. ■ Use compressed air, a high-pressure cleaner or vacuum cleaner may damage the surface. ■ Use a high-pressure cleaner, the additional risk of water entering the STbench may damage the elec- tronics or touch screen. Touch-screen ■...

  • Page 48: Basic Troubleshooting

    Solution 2: Tighten the lever and start the test again. Cause 3: The transducer is yielded. Solution 3: Contact the local Atlas Copco Customer Center for inspecting/repairing the transducer. "Over Torque Error" message is displayed Cause: The test starts but a very high torque is applied to the transducer.
