- Page 1 MACHEREY‑NAGEL Test strip reader QUANTOFIX Relax ® Quick start guide www.mn-net.com www.mn-net.com...
-
Page 2: Safety Instructions
Quick start guide Important information: This separate quick start guide is delivered together with the test strip reader QUANTOFIX Relax. The quick start guide is not intended to be a comprehensive operating ® instruction. Further information, including detailed operating procedures, can be found in the complete operating instruction of the device. -
Page 3: Explanation Of Symbols
Explanation of symbols This symbol indicates that there is a risk of electric shock. This symbol indicates that the designated area can become hot and should not be touched without suitable protective measures. This symbol indicates that the chemicals used have a corrosive effect. Observe the safety measures in the laboratory and wear the prescribed protective equipment. -
Page 4: Technical Data
Technical data Specification Description Size 7.5 cm × 16 cm × 20 cm (H × W × D) Weight 710 g (without batteries and power pack) Power supply External power pack 100–240 V, Output 9 V, 1.5 A Alternative: battery operation with 6 mignon batteries 1.5 V (AA) Operating conditions: 10 °C –... - Page 5 WARNING Risk of injury: Familiarize yourself with the device before working with it and read this document carefully. Do not use the device unless you have received instruction in its use. NOTICE Defects of the power supply and housing can lead to malfunction of the device. If the device shows an apparent breakage of the housing or a damaged power supply, it must be taken out of operation.
- Page 6 If correctly stored, the test strips may be used until the use-by-date printed on the packaging. haltbar. MACHEREY-NAGEL GmbH & Co. KG · Valencienner Str. 11 · 52355 Düren · Deutschland MACHEREY-NAGEL GmbH & Co. KG · Valencienner Str. 11 · 52355 Düren · Germany Tel.: +49 24 21 969-0 ·...
- Page 7 Step 4: Perform measurement Place the test strip on the strip holder with the test field facing upwards. The test strip must be flush with the recess of the strip holder at the front. To do this, the inserted test strip can be pushed forward with your finger.
-
Page 8: Quality Control
Cleaning NOTICE For all cleaning work, the unit must be switched off and disconnected from the power supply. WARNING Fire hazard. Do not use flammable detergents or organic solvents to clean the unit. NOTICE Do not clean the device with acetone or similar products. 1. -
Page 9: Changing The Printer Paper
Changing the printer paper 1. Press the button next to the printer paper slot to open the paper tray. Remove the old roll. 2. Insert the new roll of printer paper as shown. The roll must unroll from the bottom. 3. -
Page 10: Accessories And Spare Parts
Accessories and spare parts NOTICE Only use accessories and spare parts approved by the manufacturer. If parts not approved by the manufacturer are used, the operator is responsible for the conformity of the device and the warranty will become void. For information on accessories and spare parts, refer to the complete operating instruction of the device or contact MACHEREY‑NAGEL. -
Page 11: Electromagnetic Compatibility
Electromagnetic Compatibility Target environment of device use: Application in the commercial laboratory environment. • This device has been developed and tested in accordance with CISPR 11 Class A. It can cause radio interference in a domestic environment. In this case, you may need to take action to correct the interference. - Page 12 www.mn-net.com MACHEREY‑NAGEL GmbH & Co. KG Tel.: +49 24 21 969‑0 info@mn‑net.com Valencienner Str. 11 Tel.: +41 62 388 55 00 sales‑ch@mn‑net.com 52355 Düren · Germany Tel.: +33 388 68 22 68 sales‑fr@mn‑net.com Tel.: +1 888 321 62 24 sales‑us@mn‑net.com...
