- Page 1 Operation and Maintenance Manual Enerpac Load Skates MLSF, MLSD, MLSR Document Number: L4535 Document Revision: B Document Revision Date: JUN-2022 Document Language: ENGLISH EN To reduce the risk of injury, user must read and understand this document before use.
- Page 3 Enerpac for quality tools, services and solutions. For additional information, visit www.enerpac.com. WARRANTY Refer to the Enerpac Global Warranty document for terms and conditions of the product warranty. Such warranty information can be found at www.enerpac.com. NAMEPLATE MLSF-3 MAX CAP 3,000 kg | 6,614 lbs WEIGHT 14 kg | 30.8 lbs...
-
Page 4: Table Of Contents
Contents 1. SAFETY ................................3 1.1 SAFETY PRECAUTIONS ........................3 2. COMPLIANCE STATEMENT ......................... 4 2.1 EU DECLARATION OF CONFORMITY ....................4 3. FEATURES & COMPONENTS ........................5 3.1 MLSF FEATURES DIAGRAM ........................ 5 3.2 MLSD FEATURES DIAGRAM ....................... 6 3.3 MLSR FEATURES DIAGRAM ....................... -
Page 5: Safety
Property damage could also occur. tags, or decals. In the event that any questions or • Always wear protective head-wear, ear protectors, concerns arise, contact Enerpac or a local Enerpac footwear and gloves (at a minimum rigger type distributor for clarification. -
Page 6: Compliance Statement
CE and UKCA. occur to avoid possible damage to the load or the Enerpac declares that these product(s) have been tested facility in which the load is being moved. and conforms to applicable standards and the product(s) are compatible to all EU and UK Requirements. -
Page 7: Features & Components
3. Features & Components 3.1 MLSF Features Diagram 1. MLSF Chassis 2. Handle 3. Load Pad 4. Polyurethane (or optional Nylon) wheels 5. Wheel box Figure 1: Major features and components of MLSF load skates L4535_b... -
Page 8: Mlsd Features Diagram
3.2 MLSD Features Diagram 1. MLSD Chassis 2. Load Pad 3. Connecting Bar 4. Polyurethane (or optional Nylon) wheels Figure 2: Major features and components of MLSD load skates L4535_b... -
Page 9: Mlsr Features Diagram
3.3 MLSR Features Diagram 1. MLSR Chassis 2. Wheel Box 3. Nylon Wheels 4. Load Pad Figure 3: Major features and components of MLSR load skates L4535_b... -
Page 10: Technical Product Data
[567] [1620] [180] 4.1.3 MLSF Load Skate Description Enerpac MLSF load skates are an ideal solution for a wide variety of transporting applications, in which moving high weight material in a non linear path is required. MLSF load skates are high load capacity carts with different number of wheels depending on the load capacity, which ranges from 3 to 35 tons. -
Page 11: Mlsd Load Skate
7.0 [180] MLSD35 (420-1660) 4.2.3 MLSD Load Skate Description Enerpac MLSD load skates are an ideal solution for a wide variety of transporting applications, in which moving high weight materials is required. MLSD load skates are high load capacity carts composed of two MLS single load skates joined by a connecting bar. -
Page 12: Mlsr Load Skate
36.3 - 76.4 922 - 1940 MLSR9 4.3.3 MLSR Load Skate Description Enerpac MLSR load skates are an ideal solution for a wide variety of transporting applications, in which moving high weight material with high manoeuvrability is required. MLSR load skates are high load capacity carts with different number of nylon wheels depending on the load capacity required, which ranges from 3 to 9 tons. -
Page 13: Connecting Bars
MLSF and MLSD skates can be ordered as 1 single set. The available sets are in the following table. Set Model Components Set Capacity Nº. (Tons) MLSS7 x1 MLSF3 and x1 MLSD3 MLSS13 x1 MLSF7 and x1 MLSD7 13.2 MLSS20 x1 MLSF10 and x1 MLSD10 19.8 MLSS27 x1 MLSF13 and x1 MLSD13 26.4... -
Page 14: Moving The Load
WARNING Keep hands away from the load skate wheels to avoid injury. This especially applies while the load is on the skates, but also as a general re- quirement to avoid risk of injury even when the skates are unloaded and stationary. WARNING Do not use the load skates if the load pad is dam- aged or slick with oil. -
Page 15: Removing The Load
Authorized Enerpac Service Center and source load, which is on the steering skate, with a lifting device. replacement components only from Enerpac. This will Remove the skate and lower the load to the floor. Repeat ensure that the safety of the device is maintained. -
Page 16: Service Parts List
Kit includes 4 wheels MLSF13 MLSF17 Polyurethane Wheel Kit MLSF27 MLSWPU140854 140mm diameter X 85mm width Kit includes 4 wheels MLSF35 MLSF3, MLSF7 MLSHT T Handle, Load Skate MLSF10, MLSF13 MLSHR Ring Handle, Load Skate MLSF17, MLSF27, MLSF35 MLSHF Frame Handle, Load Skate... -
Page 17: Mlsd Exploded View
7.1.2 MLSF Accessories MLSF Load Skate Accessories Item Compatible Skates Part Number Description Qty. Per Skate MLSF3 Nylon Wheel Kit MLSF7 MLSWNY85874 85mm diameter X 87mm width MLSF10 Kit includes 4 wheels MLSF13 MLSF17 Nylon Wheel Kit MLSF27 MLSWNY140854 140mm diameter X 85mm width... -
Page 18: Mlsr Exploded View
7.2.2 MLSD Accessories MLSD Load Skate Accessories Item Compatible Skates Part Number Description Qty. Per Skate MLSD3 MLSD7 Nylon Wheel Kit 85mm diameter x MLSWNY85874 87mm width Kit includes 4 wheels" MLSD10 MLSD13 MLSD17 Nylon Wheel Kit 140mm diameter X MLSD27 MLSWNY140854 85mm width Kit includes 4 wheels... -
Page 19: Troubleshooting
1. Load is more difficult to move. a. Fatigue or corrosion on the skate Clean corrosion. If damaged, reach out body. to your nearest Authorized Enerpac Service Center for repair/replacement b. Corrosion on the wheel bearings. options. c. Load path with debris. - Page 20 NOTES ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________...
