Enerpac LG Series Instruction Sheet

POWERFUL SOLUTIONS. GLOBAL FORCE.
L4517 Rev. A

1.0 PRODUCT DATA

1.1 Specifications and Dimensions - Puller Reach and Spread

Jaw
Model Designed for use with puller model:
No.
LG10L LGH210 / LGH310 / LGM211 / LGM318
LG14L
LG24L

1.2 Dimensions and Weights - Puller Jaws

Jaw A
Model
in mm
No.
LG10L 0.59 15
LG14L 0.83 21
LG24L 1.02 26
09/20
A
LGH214 / LGH314 / LGM324
LGH224 / LGH324 / LGM340
B
B
in mm
0.94 24
1.18 30
1.77 45
Hydraulic & Mechanical Lock Grip Pullers
EN
Ø B
A max.
in
13.26
16.33
20.47
L
C
in mm in
0.47 12 0.47
0.63 16 0.59
0.79 20 0.75
Instruction Sheet
LG-Series Long Jaws
Ø B max.
mm in mm
337 16.14 410
415 20.30 516
520 28.03 712
C
D L
mm in mm
12 14.57 370
15 17.64 448
19 21.93 557
Ø B min.
in mm
1.88 48
2.18 55
3.00 77
Weight
lb kg
4.7 2.1
9.3 4.2
20.5 9.3
