- Page 1 User Guide TGT. 12.03.2019 Technical Page 1 of 21 Original User Guide Version: 03 HIT-TRAC 64E 08325_ HIT-TRAC 64E v=0.5-4.6m/min 7.5kW 100/30 08329_BA for HIT-TRAC 64E 7.5kW ©Copyright by Habegger Maschinenfabrik AG Version 03 / 12.03.2019...
- Page 2 133091 / HSS-ID-no. 124 Art. Nr./ N° art./ Art. no.: 08360 Motor-Nr. / N° du moteur / Motor no.: 7.5 kW Steuerung-Nr / N° du contrôle / control no.: HI.64-128.075.G18V000 Datum/Date/Date: 22/02/2019 Unterschrift/Visa/Visa: ©Copyright by Habegger Maschinenfabrik AG Version 03 / 12.03.2019...
-
Page 3: Table Of Contents
Lowering ..................................18 Faults ....................................19 Emergency lowering ..............................20 Maintenance ..................................20 Replacement parts ................................21 Disposal ....................................21 Accessories ..................................21 10.1 Wireless remote control ............................. 21 10.1 Generators .................................. 21 ©Copyright by Habegger Maschinenfabrik AG Version 03 / 12.03.2019... - Page 4 Page 4 of 21 Warranty and Guarantee Habegger will grant the user replacement as well as installation and removal of any parts which are rendered unusable due to material or manufacturing errors. The warranty period (guarantee period) is 12 months.
- Page 5 Applicable EC directives: EC Machinery Directives 2006/42/EG Applied harmonised standards: DIN EN 14492-1: 2010-06 EN 60204-1: 2006 EN ISO 12100: 2011-01 Location: Thun Date: 12. March 2019 Technical manager Thomas Gerber Urs Schneider ©Copyright by Habegger Maschinenfabrik AG Version 03 / 12.03.2019...
-
Page 6: General Specifications
The motor-driven rope pulling machine HIT-TRAC 64 is designed for pulling, hoisting and lowering loads. Drive mechanism A special HABEGGER steel cable of desired length which is guided over the relevant guide elements by the driving wheel and then ejected in an unloaded state is used as the drive mechanism. -
Page 7: Limit Switch
Heavier loads may only be lowered over short distances. Optional apparatus The HIT-TRAC can be equipped with braking resistors. This increases the permitted lowering period. ©Copyright by Habegger Maschinenfabrik AG Version 03 / 12.03.2019... -
Page 8: Assembly And Performance
Driving wheel Pendant station Rocker “Raise” button Thrust roller “Lower” button Anchor bolts Rotating knob for cable speed Rope shaft Emergency stop button Latch Actuator pin Plug for three-phase A.C. current ©Copyright by Habegger Maschinenfabrik AG Version 03 / 12.03.2019... -
Page 9: Safety Instructions
Page 9 of 21 Safety instructions The HABEGGER motor-driven rope pulling machine HIT-TRAC 64 complies with current technical stand- ards. To protect against accidents it is equipped with effective safety devices as required by the recog- nised safety standards, guidelines and laws. -
Page 10: General Safety Instructions
- strong/heavy boulders - Trees - other suitable objects Technical anchorage points: - Habegger field anchor with piles - Rock bolt, concrete anchor - Round timber anchor in the ground - These anchors are highly dependent on soil conditions. Secure the machine to the anchoring bolts with sufficiently strong straps or loops. - Page 11 The reliability of the driving system is dependent on the condition of the traction cable. Cable construction and inherent stability (crush resistance, impact resistance) must be able to withstand the active loads. You should therefore only use cables provided or approved by HABEGGER. The traction cable should not be lubricated.
- Page 12 Never allow the hook to touch the housing. When lowering, ensure that the rope is long enough. Stop at least 2 m before the end of the cable and place the load under- neath or rehang it. ©Copyright by Habegger Maschinenfabrik AG Version 03 / 12.03.2019...
-
Page 13: Approved Users
Actions in case of emergency Check before starting operation if and where you can get mobile phone reception or where there is an available telephone. Check the availability of a first-aid kit. ©Copyright by Habegger Maschinenfabrik AG Version 03 / 12.03.2019... -
Page 14: Technical Specifications
400 mm Dead weight rope pulling machine 330 kg Gear oil 4 and 0.2l / 80 W 90 Traction rope: Model HABEGGER 6 x 26 WS + FC galvanised, compressed Diameter 20 mm Length optional Breaking load 304 kN Driving motor:... -
Page 15: Operation
When pulling at right-angles through a wall or pulling vertically through the floor, the rope pulling machine can be supported against the wall or directly on the floor using the supporting frame. In this case, the unloaded rope should be led upwards through the upper rope guide. Laying the rope. ©Copyright by Habegger Maschinenfabrik AG Version 03 / 12.03.2019... -
Page 16: Insert Rope
Push rocker downwards using rear operating lever until lever clicks into place Keep actuator pin pressed in and gently tighten rope using motor. Double check cable placement is correct. Replace cover and secure with the fixing screws. ©Copyright by Habegger Maschinenfabrik AG Version 03 / 12.03.2019... - Page 17 User Guide TGT. 12.03.2019 Technical Page 17 of 21 Rear view ©Copyright by Habegger Maschinenfabrik AG Version 03 / 12.03.2019...
-
Page 18: Pulling And Hoisting
Danger of falling! Pay attention to end of rope! The unloaded rope should slide into the machine freely and without kinks. Stop lowering at least 2 m before the end of the cable. ©Copyright by Habegger Maschinenfabrik AG Version 03 / 12.03.2019... -
Page 19: Faults
Insert correct cable inserted Cable severely worn out Insert new cable Driving wheel or rope too heavily clean greased Groove in driving wheel heavily soiled clean no load on rope Load cable ©Copyright by Habegger Maschinenfabrik AG Version 03 / 12.03.2019... -
Page 20: Emergency Lowering
The checks should be arranged by the operator. Additionally, local regulations, as well as additional checks for severe operating conditions in short operating distances, must be implemented by a qualified professional. ©Copyright by Habegger Maschinenfabrik AG Version 03 / 12.03.2019... -
Page 21: Replacement Parts
TGT. 12.03.2019 Technical Page 21 of 21 Replacement parts Replacement parts are provided on a separate list. This can be requested from HABEGGER. Disposal Please refer to country-specific regulations for disposal. Empty the HIT-TRAC completely of oil. Dispose of even the smallest quantity of oil professionally, i.e. take it to the relevant location.
