- Page 1 Installation Manual BATH TUB FILLER www.zlinekitchen.com...
- Page 2 ZLINE Kitchen and Bath provides Attainable Luxury, where the kitchen and bath of your dreams is never out of reach. Through our unique designs and unparalleled quality, we’re dedicated to providing you an elevated experience in the heart of your home. With an endless selection of...
- Page 3 ZLINE is fueled by a passion for innovation; A relentless pursuit of bringing the highest end luxury designs and professional features into everyone’s homes. Because we continually strive to improve our products, we may change specifications and designs without prior notice.
-
Page 4: Table Of Contents
TABLE OF CONTENTS SAFETY INSTRUCTIONS BEFORE INSTALLATION INSTALLATION CARE AND MAINTENANCE TROUBLESHOOTING WARRANTY... -
Page 5: Safety Instructions
SAFETY INSTRUCTIONS PRIOR TO INSTALLATION • We highly recommend using a plumber or certified professional for installation of this product. • To keep the faucet from clogging, flush the water pipe before installation. • Wrap all threaded connections with plumber’s tape. Always wrap in a clockwise direction. -
Page 6: Before Installation
BEFORE INSTALLATION A. Shower handle B. Shower hose C. Main tub filler body D. Short bolts (4) Brass mounting ring (1) Long bolts (4) G. 1/4” steel mounting plate (1) H. Rubber gasket (1) 1/16” steel mounting plate (1) Flat washers (4) K. - Page 7 BEFORE INSTALLATION Shower Spout Open 45° 45° 25° Cold Close TOOLS NEEDED: • Adjustable wrench or 10 mm socket wrench • Phillips-head screwdriver • Pencil • Drill...
-
Page 8: Installation
INSTALLATION STEP 1 5/16” 2” • Place the 1/4” steel mounting plate on the wooden subfloor where you plan to install the filler and use a pencil to mark 4 holes. • Remove the plate and pre-drill those 4 holes using a 5/16” bit. •... - Page 9 INSTALLATION STEP 2 Wooden subfloor • Place your 1/4” steel mounting plate over the pre-drilled holes with the recessed bolt fittings facing up. • Insert long bolts through the mounting plate and through the wooden subfloor where the tub filler will be mounted.
- Page 10 INSTALLATION STEP 3 Rubber gasket Lock washer • Place your rubber gasket through the same long bolts on the underside of the subfloor. • Next, slide in the 1/16” steel mounting plate. • Place flat washers first, followed by lock washers, then hand screw fastening nuts. •...
- Page 11 INSTALLATION STEP 4 Next, on the main tub filler body, slide the mounting cap over the hot and cold water lines at the bottom and up to the base. Use caution to avoid scratching or damaging your equipment in the process.
- Page 12 INSTALLATION STEP 5 • Slide the brass mounting ring through the hot and cold water lines on the main tub filler body at bottom (see arrow), ensuring extended portion with 4 screw holes points up. • Screw in 4 Phillips-head screws to connect brass mounting ring to tub filler. •...
- Page 13 INSTALLATION STEP 6 • Install short bolts through wider holes on brass mounting ring. • Using adjustable/socket wrench, tighten bolts to attach to steel mounting plate.
- Page 14 INSTALLATION STEP 7 • Adjust the spout direction clockwise or counter clockwise to the proper position, then tighten bolts into place with adjustable/socket wrench.
- Page 15 INSTALLATION STEP 8 Lower mounting cap into position.
- Page 16 INSTALLATION STEP 9 Cold (Blue) (Red) Cold water inlet water inlet Carefully attach cold and hot water lines, ensuring connections are firm.
- Page 17 INSTALLATION STEP 10 Remove plastic coverings on shower handle and shower hose and use washers to connect to main tub filler body. Use care to not overtighten.
- Page 18 INSTALLATION STEP 1 1 With installation now complete, turn hot and cold water lines back on to the unit, then pull water valve lever. Note: It may take a few seconds for water to fill the pipes and begin flowing.
- Page 19 water water inlet inlet INSTALLATION STEP 12 Lastly, to set the shower handle system, pull on the diverter valve knob with the water on (see arrow).
-
Page 20: Care And Maintenance
CARE AND MAINTENANCE To keep the product clean and shiny, follow the steps below: Rinse clean with water and dry with a soft cloth. 2. Do not clean with soaps, acid, polish, abrasives, or harsh cleaners. 3. Do not use any cloth with a coarse surface. 4. -
Page 21: Troubleshooting
If you have troubleshooting the hose. correctly in the hose issues, call our Customer Service line connection. at 1-614-777-5004. Need to purchase a part or accessory for your ZLINE product? Visit ZLINEparts.com, ZLINE's official parts distribution partner. -
Page 22: Warranty
WARRANTY COVERAGE ZLINE Kitchen and Bath bath tub fillers have a limited lifetime warranty from the original purchase date for the original purchaser of the product. TERMS This warranty applies only to the original purchaser of a bath tub filler installed for normal residential use. - Page 23 2.0.0 www.zlinekitchen.com 1-614-777-5004 contact@zlinekitchen.com...
