1.0.1
Installation Guide and User Manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the BLISS BLS-SHS and is the answer not in the manual?

Questions and answers

Related Manuals for Zline BLISS BLS-SHS

Summary of Contents for Zline BLISS BLS-SHS

  • Page 1 1.0.1 Installation Guide and User Manual...
  • Page 2 REGISTERING YOUR PRODUCT Please register your ZLINE appliance. Begin the simple registration process by scanning the QR code. SCAN ME By registering your appliance, you will have easy and accurate access to: • Technical Support • Warranty Service • Tracking your support inquiries •...
  • Page 3 With an endless selection of features and finishes, our inspiration is your reality. ZLINE is fueled by a passion for innovation; A relentless pursuit of bringing the highest end luxury designs and professional features into everyone’s homes. Because we continually strive...
  • Page 4 The warranty applies only to products installed in the continental United States and the District of Columbia. Warranty shall not apply and ZLINE Kitchen and Bath is not responsible for damage resulting from negligence, improper maintenance, misuse, abuse, alteration of or...

  • Page 5: Table Of Contents

    TABLE OF CONTENTS SAFETY INSTRUCTIONS BLISS SHOWER SYSTEM (BLS-SHS) ZLINE SHOWER FAUCET BLISS SHOWER FAUCET (BLS-SHF) EL DORADO SHOWER SYSTEM (ELD-SHS) EL DORADO SHOWER FAUCET (ELD-SHF) TROUBLESHOOTING...

  • Page 7: Safety Instructions

    SAFETY INSTRUCTIONS PRIOR TO INSTALLATION • Make sure that the cold and hot water lines are turned off. • Wrap all threaded connections with Teflon tape. Always wrap in a clockwise direction. • Cover your drain to avoid losing parts. •...

  • Page 8: Bliss Shower System (Bls-Shs)

    BLISS SHOWER SYSTEM (BLS-SHS) 1. Flange cover 9. Switch handle 2. Shower arm 10. Cap 3. Top spray shower 1 1. Sleeve 4. Wall valve body 12. Flange cover 5. Faceplate 13. Angle valve 6. Sleeve 14. Shower rail 7. Washer 15.
  • Page 9 BLISS SHOWER SYSTEM (BLS-SHS)
  • Page 10 BLISS SHOWER SYSTEM (BLS-SHS) needed:...
  • Page 11 BLISS SHOWER SYSTEM (BLS-SHS) Slide the sleeves onto the pipes and then insert pipes into the wall valve. Tighten the ring around the pipes with the wrench. NOTE: If brazing is involved, you must remove the internal valve components prior to the brazing. Please note the original position of the cartridge.
  • Page 12 BLISS SHOWER SYSTEM (BLS-SHS) Braze the copper together.
  • Page 13 BLISS SHOWER SYSTEM (BLS-SHS) After brazing, purge the water supply system for 30 seconds.
  • Page 14 BLISS SHOWER SYSTEM (BLS-SHS) Reinstall the valve components into their original positions.
  • Page 15 BLISS SHOWER SYSTEM (BLS-SHS) Use this diagram to understand the placement of the wall valve.
  • Page 16 BLISS SHOWER SYSTEM (BLS-SHS) Screw the wall valve body into the system with a screwdriver. Do not overtighten.
  • Page 17 BLISS SHOWER SYSTEM (BLS-SHS) Screw the sleeve and washer into the wall valve body.
  • Page 18 BLISS SHOWER SYSTEM (BLS-SHS) Attach the face plate and remove the plastic.
  • Page 19 BLISS SHOWER SYSTEM (BLS-SHS) Attach the water control handle.
  • Page 20 BLISS SHOWER SYSTEM (BLS-SHS) 10a. 10b. Connect the flange cover to the spout in the wall. Secure with plumber’s tape to prevent leaks.
  • Page 21 BLISS SHOWER SYSTEM (BLS-SHS) Twist the top spray shower into the shower arm.
  • Page 22 BLISS SHOWER SYSTEM (BLS-SHS) 12a. 12b. Connect the angle valve to the flange cover and screw together. Secure with plumber’s tape to prevent leaks.
  • Page 23 BLISS SHOWER SYSTEM (BLS-SHS) 13a. Use a pencil to mark the mounting holes on the wall. Use a wrench to put the screws...
  • Page 24 BLISS SHOWER SYSTEM (BLS-SHS) Connect the components of the shower rail.
  • Page 25 BLISS SHOWER SYSTEM (BLS-SHS) 15a. Screw the shower rail into the wall. Once the screws and shower rail are secured to the wall, then attach the covers.
  • Page 26 BLISS SHOWER SYSTEM (BLS-SHS) 16a. 16b. Connect the shower handle to the shower rail. Tighten with a wrench.
  • Page 27 BLISS SHOWER SYSTEM (BLS-SHS) Review the diagram to understand the hot, cold, and open settings.

  • Page 28: Zline Shower Faucet

    ZLINE SHOWER FAUCET...
  • Page 29 ZLINE SHOWER FAUCET needed:...
  • Page 30 ZLINE SHOWER FAUCET...
  • Page 31 ZLINE SHOWER FAUCET...
  • Page 32 ZLINE SHOWER FAUCET 10a. 11a.

  • Page 33: Bliss Shower Faucet (Bls-Shf)

    BLISS SHOWER FAUCET (BLS-SHF)
  • Page 34 BLISS SHOWER FAUCET (BLS-SHF) needed:...
  • Page 35 BLISS SHOWER FAUCET (BLS-SHF) Slide the sleeves onto the pipes and then insert pipes into the wall valve. Tighten the ring around the pipes with the wrench.
  • Page 36 BLISS SHOWER FAUCET (BLS-SHF) Braze the copper together.
  • Page 37 BLISS SHOWER FAUCET (BLS-SHF) After brazing, purge the water supply system for 30 seconds.
  • Page 38 BLISS SHOWER FAUCET (BLS-SHF) Reinstall the valve components into their original positions.
  • Page 39 BLISS SHOWER FAUCET (BLS-SHF) Screw the wall valve body into the system with a screwdriver. Do not overtighten.
  • Page 40 BLISS SHOWER FAUCET (BLS-SHF) Place the components in the appropriate location.
  • Page 41 BLISS SHOWER FAUCET (BLS-SHF) Screw the sleeve and washer into the wall valve body.
  • Page 42 BLISS SHOWER FAUCET (BLS-SHF) Attach the face plate and remove the plastic.
  • Page 43 BLISS SHOWER FAUCET (BLS-SHF) Attach the water control handle.
  • Page 44 BLISS SHOWER FAUCET (BLS-SHF) 10a. 10b. Connect the flange cover to the spout in the wall. Secure with plumber’s tape to prevent leaks.
  • Page 45 BLISS SHOWER FAUCET (BLS-SHF) Twist the top spray shower into the shower arm.
  • Page 46 BLISS SHOWER FAUCET (BLS-SHF) Review the diagram to understand the hot, cold, and open settings.

  • Page 47: El Dorado Shower System (Eld-Shs)

    EL DORADO SHOWER SYSTEM (ELD-SHS) 1. Flange cover 9. Switch handle 2. Shower arm 10. Cap 3. Top spray shower 1 1. Sleeve 4. Wall valve body 12. Flange cover 5. Faceplate 13. Angle valve 6. Sleeve 14. Shower rail 7.
  • Page 48 EL DORADO SHOWER SYSTEM (ELD-SHS)
  • Page 49 EL DORADO SHOWER SYSTEM (ELD-SHS) needed:...
  • Page 50 EL DORADO SHOWER SYSTEM (ELD-SHS) Slide the sleeves onto the pipes and then insert pipes into the wall valve. Tighten the ring around the pipes with the wrench.
  • Page 51 EL DORADO SHOWER SYSTEM (ELD-SHS) Braze the copper together.
  • Page 52 EL DORADO SHOWER SYSTEM (ELD-SHS) After brazing, purge the water supply system for 30 seconds.
  • Page 53 EL DORADO SHOWER SYSTEM (ELD-SHS) Reinstall the valve components into their original positions.
  • Page 54 EL DORADO SHOWER SYSTEM (ELD-SHS) Screw the wall valve body into the system with a screwdriver. Do not overtighten.
  • Page 55 EL DORADO SHOWER SYSTEM (ELD-SHS) Place the components in the appropriate location.
  • Page 56 EL DORADO SHOWER SYSTEM (ELD-SHS) Screw the sleeve and washer into the wall valve body.
  • Page 57 EL DORADO SHOWER SYSTEM (ELD-SHS) Attach the face plate and remove the plastic.
  • Page 58 EL DORADO SHOWER SYSTEM (ELD-SHS) Attach the Water control handle.
  • Page 59 EL DORADO SHOWER SYSTEM (ELD-SHS) 10a. 10b. Connect the flange cover to the spout in the wall. Secure with plumber’s tape to prevent leaks.
  • Page 60 EL DORADO SHOWER SYSTEM (ELD-SHS) Twist the top spray shower into the shower arm.
  • Page 61 EL DORADO SHOWER SYSTEM (ELD-SHS) 12. 12. 12a. Connect the angle valve to the flange cover and screw together. Secure with plumber’s tape to prevent leaks.
  • Page 62 EL DORADO SHOWER SYSTEM (ELD-SHS) 13a. 13b. Use a pencil to mark the mounting holes on the wall. Use a wrench to put the screws...
  • Page 63 EL DORADO SHOWER SYSTEM (ELD-SHS) Connect the components of the shower rail.
  • Page 64 EL DORADO SHOWER SYSTEM (ELD-SHS) Screw the shower rail into the wall.
  • Page 65 EL DORADO SHOWER SYSTEM (ELD-SHS) 16a. 16b. Connect the shower handle to the shower rail. Tighten with a wrench.
  • Page 66 EL DORADO SHOWER SYSTEM (ELD-SHS) Review the diagram to understand the hot, cold, and open settings.

  • Page 67: El Dorado Shower Faucet (Eld-Shf)

    EL DORADO SHOWER FAUCET (ELD-SHF)
  • Page 68 EL DORADO SHOWER FAUCET (ELD-SHF)
  • Page 69 EL DORADO SHOWER FAUCET (ELD-SHF) Slide the sleeves onto the pipes and then insert pipes into the wall valve. Tighten the ring around the pipes with the wrench. NOTE: If brazing is involved, you must remove the internal valve components prior to the brazing. Please note the original position of the cartridge.
  • Page 70 EL DORADO SHOWER FAUCET (ELD-SHF) Braze the copper together.
  • Page 71 EL DORADO SHOWER FAUCET (ELD-SHF) After brazing, purge the water supply system for 30 seconds.
  • Page 72 EL DORADO SHOWER FAUCET (ELD-SHF) Reinstall the valve components into their original positions.
  • Page 73 EL DORADO SHOWER FAUCET (ELD-SHF) Use this diagram to understand the placement of the wall valve.
  • Page 74 EL DORADO SHOWER FAUCET (ELD-SHF) Place the components in the appropriate location.
  • Page 75 EL DORADO SHOWER FAUCET (ELD-SHF) Screw the sleeve and washer into the wall valve body.
  • Page 76 EL DORADO SHOWER FAUCET (ELD-SHF) Attach the face plate and remove the plastic.
  • Page 77 EL DORADO SHOWER FAUCET (ELD-SHF) Attach the Water control handle.
  • Page 78 EL DORADO SHOWER FAUCET (ELD-SHF) 10a. 10b. Connect the flange cover to the spout in the wall. Secure with plumber’s tape to prevent leaks.
  • Page 79 EL DORADO SHOWER FAUCET (ELD-SHF) Twist the top spray shower into the shower arm.
  • Page 80 EL DORADO SHOWER FAUCET (ELD-SHF) Review the diagram to understand the hot, cold, and open settings.

  • Page 81: Troubleshooting

    TROUBLESHOOTING PROBLEM POSSIBLE CAUSE SOLUTION There is leakage under the The locking nut has come Unscrew the lever on handle. loose. the handle by hand. Loosen set screw with a hex wrench. Remove the handle and unscrew trim cap by hand. Tighten locking nut with an adjustable wrench.
  • Page 84 Installation Guide and User Manual 2.0.1 1-614-777-5004 contact@zlinekitchen.com www.zlinekitchen.com...
