Navitar 1-62517 Dimensional Drawing

n
1.60 [40.6]
n
1.25 [31.8]
n
1.44 [36.5]
M25x.75
2-PHASE MOTOR PINOUT
PIN 3 = +5Vdc
PIN13 = COMMON
PIN 8 = FAR LIMIT
PIN 12 = NEAR LIMIT
PIN 1 = MOTOR A+
PIN 7 = MOTOR A-
PIN 6 = MOTOR B+
PIN 11 = MOTOR B- 15 PIN HIGH DENSITY
D-SUB
3.19 [81.0] .80 [20.3]
4.31 [109.6]
4.84 [122.9]
USED ON:
MATERIAL:
FINISH:
CHAMFER ALL THREADS
30
.38 [9.5]
.75 [19.1]
(4) x 4-40 UNC - 2B
.32 [8.3]
.52 [13.3]
+ .000
n
1.312
- .001
P/N SUFFIX DEFINITION
UNLESS OTHERWISE
SPECIFIED
-1 CONVERSION COATING
DIMENSIONS ARE IN INCHES -2 PAINTING
AND INCLUDE CHEMICALLY
-3 MARKING
APPLIED OR PLATED FINISHES
-R REWORK
TOLERANCES:
SCALE:
`
DEC. .XXX .005
`
DR.: R. PODLENA
DEC. .XX .010
`
FRACT. 1/64 CH.: P. BONAFEDE
`
ANGLES 30'
APP.: P. BONAFEDE
CONCENTRICITY .003 TIR
BREAK ALL SHARP EDGES
DATE DR.:
.005 MIN. .010 MAX
MAX. SURF. ROUGHNESS 32
DO NOT SCALE DRAWING
~
TO ROOT DIAM.
REV CHANGE RECORD AND DATE CH
1.33 [33.8]
2.13 [54.2]
1.02 [25.8]
1.82 [46.2]
OUTLINE
THE CONTENTS OF THIS
DOCUMENT ARE PROPRIETARY
TO NAVITAR, ITS USE IS
AUTHORIZED ONLY FOR
RESPONDING TO REQUEST
ROCHESTER, NEW YORK
FOR QUOTATION OR
1:1
PERFORMANCE OF WORK FOR
NAVITAR
MOTORIZED (STEPPER) 6x
0.0 inch 1.0
ULTRAZOOM w/2 POS. LS (HE) &
SIZE
0.0 mm 25.0
11/22/2002
B
MANUAL 12mm FF
REV
1-62517
A
1 1
SHEET OF
