Navitar 1-62516 Dimensional Drawing

n
1.60 [40.6]
n
1.25 [31.8]
n
1.44 [36.5]
M25x.75
DC ENCODED PINOUT
PIN 1 = MOTOR CH A
PIN 2 = FAR LIMIT
PIN 3 = N/C
PIN 4 = +5Vdc
PIN 5 = MOTOR +
PIN 6 = MOTOR CH B
PIN 7 = NEAR LIMIT
PIN 8 = COMMON
PIN 9 = MOTOR -
3.19 [81.0]
4.31 [109.6]
5.07 [128.7]
USED ON:
MATERIAL:
9 PIN MALE D-SUB
.38 [9.5]
.75 [19.1]
(4) x 4-40 UNC - 2B
.32 [8.3]
.80 [20.3]
.76 [19.2]
+ .000
n
1.312
- .001
P/N SUFFIX DEFINITION
UNLESS OTHERWISE
SPECIFIED
-1 CONVERSION COATING
DIMENSIONS ARE IN INCHES -2 PAINTING
AND INCLUDE CHEMICALLY
-3 MARKING
APPLIED OR PLATED FINISHES
-R REWORK
TOLERANCES:
SCALE:
`
DEC. .XXX .005
FINISH:
`
DR.:
DEC. .XX .010
`
FRACT. 1/64 CH.:
`
ANGLES 30'
APP.:
CONCENTRICITY .003 TIR
BREAK ALL SHARP EDGES
DATE DR.:
.005 MIN. .010 MAX
CHAMFER ALL THREADS
MAX. SURF. ROUGHNESS 32
DO NOT SCALE DRAWING
~
30 TO ROOT DIAM.
REV CHANGE RECORD AND DATE CH
1.33 [33.8]
2.13 [54.2]
1.02 [25.8]
1.82 [46.2]
THE CONTENTS OF THIS
DOCUMENT ARE PROPRIETARY
TO NAVITAR, ITS USE IS
AUTHORIZED ONLY FOR
RESPONDING TO REQUEST
ROCHESTER, NEW YORK
FOR QUOTATION OR
1:1
PERFORMANCE OF WORK FOR
NAVITAR
MOTORIZED (ENCODED) 6x
R. PODLENA
0.0 inch 1.0
ULTRAZOOM w/2 POS. LS (HE) &
P. BONAFEDE
P. BONAFEDE
SIZE
0.0 mm 25.0
11/22/2002
B
OUTLINE
MANUAL 12mm FF
REV
1-62516
A
1 1
SHEET OF
