Navitar 1-51322 Dimensional Drawing

1
2-50026
26.0-36RMS
.800-36RMS
1
2-50025
n
1.73 [43.9]
1 1/2-32 UN - 2A
2.48 [62.9]
5-PHASE MOTOR PINOUT
PIN 3 = +5Vdc
PIN13 = COMMON
PIN 8 = FAR LIMIT
PIN 12 = NEAR LIMIT
PIN 15 = MOTOR 1
PIN 5 = MOTOR 2
PIN 10 = MOTOR 3
PIN 4 = MOTOR 4
PIN 14 = MOTOR 5
4.70 [119.5]
5.82 [147.9]
15 PIN HIGH DENSITY
D-SUB
.80 [20.3]
.32 [8.1]
.38 [9.5]
.75 [19.1]
(4) x 4-40 UNC - 2B
+ .000
n
1.312
- .001
n
1.91 [48.4]
n
1.88 [47.6]
.28 [7.2]
USED ON:
MATERIAL:
UNLESS OTHERWISE
SPECIFIED
DIMENSIONS ARE IN INCHES
AND INCLUDE CHEMICALLY
APPLIED OR PLATED FINISHES
TOLERANCES:
`
DEC. .XXX .005
FINISH:
`
DEC. .XX .010
`
FRACT. 1/64
`
ANGLES 30'
CONCENTRICITY .003 TIR
BREAK ALL SHARP EDGES
.005 MIN. .010 MAX
CHAMFER ALL THREADS
MAX. SURF. ROUGHNESS
~
30 TO ROOT DIAM.
REV CHANGE RECORD AND DATE CH
VIEW A-A
(VIEW ROTATED)
3.29 [83.6]
2.34 [59.4]
P/N SUFFIX DEFINITION THE CONTENTS OF THIS
DOCUMENT ARE PROPRIETARY
-1 CONVERSION COATING
TO NAVITAR, ITS USE IS
-2 PAINTING
AUTHORIZED ONLY FOR
-3 MARKING
RESPONDING TO REQUEST
-R REWORK
FOR QUOTATION OR
1:1
SCALE: PERFORMANCE OF WORK FOR
NAVITAR
DR.: R. PODLENA
0.0 inch 1.0
CH.: P. BONAFEDE
APP.:
0.0 mm 25.0
9/18/2003
DATE DR.:
32
DO NOT SCALE DRAWING
A
1.05 [26.8]
.95 [24.2]
2.09 [53.1]
A
OUTLINE
ROCHESTER, NEW YORK
MOTORIZED (5PH) 12X ULTRA
w/12mm FF & 2 POS LS (HE)
SIZE
REV
1-51322
A
B
1 1
SHEET OF
