Casambi MINI 1CV Device Manual

FEATURES
 CASAMBI LED DIMMER
 Power Supply: 12-24-48 Vdc
 Voltage output for LED strip and LED module
 Control of the White and Monochromatic Light
 Command: APP CASAMBI
 Local Command: n°1 Normal Open Push Button
 Control voltage outputs for R
 Adjusting the brightness up to completed off (Dim to Dark)
 Minimum Brightness level: down to 0,1%
 PWM Modulation
 Adjusting PWM frequency: 600 / 4000 Hz
 Adjusting output curve: Linear / Logarithmic
 Soft start and soft stop
 Soft Dimming regulation
 Extended temperature range
 100% Functional test
PRODUCT DESCRIPTION
MINI-1CV-CASAMBI is a single channel LED dimmer, controllable via Bluetooth using the Casambi APP or locally with a normally
open push button.
The LED dimmer is suitable for driving Strip LED and LED modules, White and monochromatic constant voltage loads. It is possible
connect a power supply at 12-24-48 Vdc.
The maximum total output current is 12A. The LED dimmer has over voltage protection, under voltage protection, reverse polarity
protection and input fuse protection.
By means of the CASAMBI APP, the MINI-1CV-CASAMBI allows you to make a variety of effects: from simple brightness
adjustments to more complex lighting control system, thanks to the creation of multiple scenarios, animations, timers, daylight
control etc.
CASAMBI APP can be downloaded for free on Apple App Store and Google Play Store.
⇢ For the up-to-date manual, please visit our website:
label.
⇢ For the correct functioning of the CASAMBI APP, please visit the forum on the Casambi website:
https://support.casambi.com/support/home
DALCNET S.r.l.
36077 Altavilla Vicentina (VI) – Italy
Via Lago di Garda, 22
MINI 1CV CASAMBI
Device Manual
www.dalcnet.com or scan the QR Code located on the product's
www.dalcnet.com
Made in Italy
Phone +39 0444 1836680
– info@dalcnet.com
Rev. 15/12/2022 - Pag. 1/8
