Tecnoautomazione T181P User Manual

T181P.
ROLLING SHUTTERS CONTROL UNIT 230 VAC POWER SUPPLY. 433.92 MHz FREQUENCY. 100 STORABLE CODES.
ON
1 2 3 4 5 6 7 8 9 10 11 12
RC1 RC2
R1
R2
REMOTE
R3
R4
A
TIME
B
C
5
3 4 6
INPUT
3 4 5 6
INTERNAL
RECEIVER
LEDs:
S1.S2.S3. ROLLING SHUTTER STATUS / CONTROL BOARD STATUS LEDS
RC1. SHOWS THAT A SIGNAL HAS BEEN RECEIVED FROM THE INTERNAL RADIO RC1
RC2. SHOWS THAT A SIGNAL HAS BEEN RECEIVED FROM THE EXTERNAL RADIO RC2
R1. START / OPEN OR DEAD-MAN OPEN
R2. STOP STOP THE ROLLING SHUTTER
R3. START / FAST CLOSURE OR DEAD-MAN CLOSURE
R4. OUT1 ON/OFF: light on enable or disable OUT1. Courtesy light will automa cally switch off a er the
me programmed with DIP 11 and DIP 12. OUT1 is enabled and disabled via remote and will not switch off automa cally.
A. C. PROGRAMMING LEDS B.
1.2.3.4.5.6.7. INPUTS
AUXILIARY OUTPUTS:
OUT1. ENABLED/DISABLED VIA REMOTE (R4)
OUT2. ENABLED DURING OPENING, CLOSING AND PAUSE. IDEAL FOR 230V FLASHING LAMP.
POWER SUPPLY
L
20 19
OPEN OR DEAD-MAN OPEN
3 4 5 6 7 8 9 10 11 12
PHOTOCELL RECEIVER
3 4 5 6 7 8 9
RX N.C. +VDC
PROGRAMMING ROLLING SHUTTER WORKING TIMES. The programming must be operated while the rolling shu er is closed.
1
To start the procedure
DIP 3 - 4 - 5 must be set
to OFF posi on.
1 2 3 4 5 6 7 8 9 10 11 12
PRESS TIME BUTTON FOR 5 SECONDS
Led A is steady on.
The rolling shu er opens.
The working me is being
acquired. The rolling shu er
reaches the limit switch.
A
S1 S2 S3
B
C
EXTERNAL
RECEIVER
7
7 8 9 10 11 12
TERMINAL BLOCK CONNECTIONS
START OR DEAD-MAN OPEN
3 4 5 6 7 8 9 10 11 12
10 11 12
GND
S1 S2 S3
OUT2. ENABLED DURING OPENING, CLOSING AND PAUSE. IDEAL FOR 230V FLASHING LAMP.
GROUND
2A FUSE
N L
230 VAC
x
13 14 15
COURTESY LIGHT 230 VAC
3 4
CLOSE OR DEAD-MAN CLOSE
3 4 5 6 7 8 9 10 11 12
PHOTOCELL TRANSMITTER
3 4 5 6 7 8 9 10 11 12
GND
TX TEST
2
PRESS THE TIME BUTTON
or a start command
Led A s steady on. The rolling
shu er is stopped completely
opened. Led C flashing every
A
second. The automa c closure
me is being acquired, (pause
B
me during opening).
C
This step depends on
the working mode set.

TERMINAL BLOCK:

3. OPEN / DEAD-MAN CLOSE
4. CLOSE / DEAD-MAN CLOSE
5. STOP
6. PHOTOCELL
7. START / DEAD-MAN OPEN
8. +VDC / COMMON / +24VAC
9. PHOTOCELLS TEST
10. GND
11.12. FLASHING LAMP
13. MOTOR CLOSE
14. MOTOR COMMON
15. MOTOR OPEN
20.X.19. 230 VAC (FLASHING LAMP STEADY)
ON
1 2 3 4 5 6 7 8 9 10 11 12
OFF
S1 S2 S3 BOARD STATUS:
STAND BY, ROLLING SHUTTER CLOSED
ROLLING SHUTTER IN OPENING OR
CLOSING PHASE, ROLLING SHUTTER
MOTOR
OPEN ON GOING PROGRAMMING
CONTROL BOARD IN PROGRAMMING
PHASE
PHOTOCELLS TEST ERROR
COURTESY LIGHT ERROR
PROGRAMMING ERROR:
INCORRECT PROCEDURE
STOP
5 6 7 8 9 10 11 12
FLASHING LAMP
3 4 5 6 7 8 9 10 11 12
AUXILIARY OUTPUTS
OUT1. ENABLE OR
DISABLEVIA REMOTE.
OUT2. ENABLED DURING
OPENING, CLOSING AND
PAUSE.
Ideal for 230V flashing lamp.
MOTOR
13 14 15
M
MAX 5 W
OUT 1 OUT 2
3
PRESS THE TIME BUTTON
or a start command
The programming has ended.
The rolling shu er closes.
A
S1 S2 S3
B
C
