- Page 1 中国·厦门蒙发利电子有限公司 Xiamen Healthcare Electronic Co., Ltd. 产 品 维 修 手 册 Maintenance Service Manual 产品型号/Model: EI-8602A-TIT 适用电压规格/ Voltage Specification: 110-120V~ 蒙发利集团·客服 By the Easepal`s Customer Service Dept.
-
Page 2: Table Of Contents
Catalogue 1.Fault code list ------------------------------------------------------------ 3-4 2.List of tools to use ------------------------------------------------------------ 5 3.Cloak replacement -------------------------------------------------------------6 4.Replacement of flannelette in backrest ----------------------------------------- 7 5.Movement disassembly-1 ----------------------------------------------------- 8 6.Movement replacement -2 --------------------------------------------------- -9 7.Movement replacement -3 --------------------------------------------------- 10 8.Remove the back cover --------------------------------------------------------11 9.Replacement of upper cover of central box --------------------------------------12 10.Remove side plate ----------------------------------------------------------- 13 11.calves replacement----------------------------------------------------------- 14... -
Page 3: Fault Code List
Fault code list open: (1) Under the condition of shutdown, At the same time, hold down the three keys pointed to by the arrow, and you will hear a beep of the hand controller in a few seconds. Select one of the two project patterns shown in the following figure as needed Status ,indications Fault... - Page 4 Check the connection between Detection when Abnormal speed senso of the The motor is broken the motor and the movement function is turned on Movement walking moto ， or blocked board Shut down That is ,no change of speed Drive circuit device Check or replace moto automatically in the code disk was detected in...
- Page 5 Tools List Electric Screw Driver Diagonal Cutter Electric Screw Driver Cable Ties Slot Type Screwdriver Cross Batch 2*6.35*100 2*6.35*65 Screwdriver...
-
Page 6: Cloak Replacement
Cloak replacement 1. Pass through the zipper head with a small Cable Ties and pull it apart (figure 1), as shown in figure 2 after opening at 7 position 图 1 图 2 2. Put on the new cloak and zip up 7 position zippers as shown in figure 3 below 图... -
Page 7: Replacement Of Flannelette In Backrest
Replacement of flannelette in backrest Press P6 to remove the cloak in the first step . Open 4 zippers of flannelette according to figure 1 图 2 图 1 . Remove the two screws behind the back and the two screws under the pedestal As shown in figure 2 Replace the new flannelette with the steps in figure 2 and figure 1 to return to the operation。... - Page 8 Remove of the Movement -1 Press P7 step 1 / 3 to remove the cloak and flannelette Remove the baffle from the left and right guideway with a 2. Use a screwdriver to revolve the worm screwdrive ove the machine core to the position of the left and through the repair hole to move the ，M right guideway disassembly baffle...
- Page 9 The walking gear comes out first and the front gear comes out again.
- Page 10 Remove of the movement -2 Cut off the Cable Ties n the three positions shown in Remove the earth wire figure 3 with Diagonal Cutter of the machine core Pull out the trachea and terminal Connect the trachea to the terminal with a new Lock the earth wire to the machine core machine core Tie a Cable Ties on the trachea and dorsal rack line...
- Page 11 Remove of the movement -3 12. The screwdriver removes the machine core The front gear is advanced, and the walking gear is away from the baffle area of the left and right re-entered. guideway through the repair hole Pass the inverted hook through the elastic cloth 13.
-
Page 12: Remove The Back Cover
Remove the back cover 1. Run the massage chair to its original state, and then cut off the power supply. 2.Pull out the cloth pin on the back cover vertically as shown in figure 1 and remove the four screws in figure 2. -
Page 13: Replacement Of Upper Cover Of Central Box
Replacement of upper cover of central box 1.Run the massage chair to the initial state, then cut off the power supply and unplug the plug; 2.Pull out 5 cloth pins in turn perpendicular to the direction of the upper cover, as shown in figure 1; 3.Remove the screws as shown in figures 2 and 3 4.Hold the inner side of the top cover of the center box on the left hand, hold the outer edge of the upper cover on the right hand, gently drag it out and remove the upper cover, as shown in figure 4... -
Page 14: Remove Side Plate
Remove side plate 1. Run the massage chair to its original state, then cut off the power supply and unplug it； 2.Press P11 to remove the rear cover and cut the inner band of the lower cover with oblique pliers, as shown in figure 1；... - Page 15 Replacement of calves 1.Unzipper as shown in figure 1； 2.Break the DK Card bolt open with your fingers or pliers and take it up, as shown in figure 2； 3. Remove the trachea and power cord connector, as shown in figure 3 图...
-
Page 16: Movement Backrest Bus Disassembly -1
Movement backrest bus disassembly -1 1. Adjust the center position of the Movement Backrest center positiont through the maintenance hole through the screwdriver for removing the cloak and velvet through P7 step 1 / 3； 2. Press P11 to remove the rear cover, cut off the tie tape shown in the figure below, pull out the terminal shown in the figure below and remove the earth wire terminal；... -
Page 17: Movement Backrest Bus Disassembly -2
Movement backrest bus disassembly -2 Tie tight in two places The reserved position here is not tight. The nine-core connecting wire is connected Fastening of core spring and nine-core connecting 图 2 with the movement, and the tape is pierced into wire (3 places) the card slot. -
Page 18: Movement Backrest Bus Disassembly -3
Movement backrest bus disassembly Straighten the line, tie the belt and The nine-core connection line is fix it. connected to the 32 core wire. 图 8 图 7 Nine-core connecting wire and 32 core wire earth wire with lock Cloth cover tie belt fixation 图... -
Page 19: Gas Pump Replacement
Gas pump replacement 1.Remove 5 cloth sleeve pins on the top cover of the central box 2.Remove 3 screws 3.Remove 4 screws of the air pump and cut off the bandage so that you can take it out and replace it. -
Page 20: Centre Plate、Transformer、Fuse Replacement
centre plate、transformer、Fuse replacement 1. Transformer replacement：Cut the tie、Unplug the terminal、Remove the fixing screw from the transformer、Remove transformer 2.Center plate replacement：Unplug the terminal from the center board，Remove 6 screws，That is, the center board can be removed 3.Fuse replacement：Remove insurance from socket，You can replace the fuse.
