Vonets VAR1200-H Quick Setting Manual

Gigabit industrial bridge repeater

Advertisement

VONETS——Gigabit Industrial Bridge Repeater
Gigabit Industrial Bridge Repeater
VAR1200-H/VAR1200-L/VAR1800-H/
VAR1800-L/VAR600-H/VAR600-L
Quick Setting Guide
Statement
Copyright © 2022 Shenzhen Houtian Network Communication Technology Co., Ltd.
Copyright, all rights reserved
Without the express written permission of Shenzhen Houtian Network Communication
Technology Co., Ltd., no unit or individual may copy, copy, transcribe or translate part or all
of the contents of this book. Not to be used for commercial or profit-making purposes in any

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VAR1200-H and is the answer not in the manual?

Questions and answers

Summary of Contents for Vonets VAR1200-H

  • Page 1 VONETS——Gigabit Industrial Bridge Repeater Gigabit Industrial Bridge Repeater VAR1200-H/VAR1200-L/VAR1800-H/ VAR1800-L/VAR600-H/VAR600-L Quick Setting Guide Statement Copyright © 2022 Shenzhen Houtian Network Communication Technology Co., Ltd. Copyright, all rights reserved Without the express written permission of Shenzhen Houtian Network Communication Technology Co., Ltd., no unit or individual may copy, copy, transcribe or translate part or all...
  • Page 2 (electronic, mechanical, photocopying, recording or other possible means). VONETS is a registered trademark of Shenzhen Houtian Network Communication Technology Co., Ltd. All other trademarks or registered trademarks mentioned in this document are the property of their respective owners. The product specifications and information mentioned in this manual are for reference only and may be updated without prior notice.
  • Page 3 VONETS——Gigabit Industrial Bridge Repeater 3. POE related issues:  3.1 If the product has PSE function (POE output), it needs 48V power supply voltage and meets the power requirements of POE output before it can be used;  3.2 If the network port of the product has a POE output port, if it is connected to...
  • Page 4: Table Of Contents

    VONETS——Gigabit Industrial Bridge Repeater Contents Chapter 1 Application Mode ............................... 1 1.1 Bridge + Repeater Mode(In the actual application environment, if the POE output port (PSE) is connected to a non-POE network port (PD is an access network port), please use it with caution, and ensure that the access network port is isolated from the power supply ground, otherwise it may cause the access device.
  • Page 5: Chapter 1 Application Mode

    There are three application modes for the bridge mode of VONETS device: WiFi repeater, WiFi bridge and WiFi AP.
  • Page 6: Router Mode(In The Actual Application Environment, If The Poe Output Port (Pse) Is Connected

    (the shell is marked with WAN/LAN ports);  The VONETS device is used as a wireless router, and the WAN port can be set to connect to a WiFi hotspot and used as a secondary router. Its Ethernet port and Ethernet...
  • Page 7: Chapter 2 Bridge+Repeater Mode Configuration Instruction

    Power on VONETS device by 12V/3A power supply, then connect to PC, there are two connection ways as below: A.
  • Page 8: Bridge+Repeater Application Configuration

    VONETS——Gigabit Industrial Bridge Repeater 2.2 Bridge+Repeater Application Configuration The configuration steps of VONETS device for WiFi repeater and WiFi bridge are basically the same, so this manual combines the configuration instructions of the two application modes. 1. After computer is connected to VONETS device, open browser, input configured page: http://vonets.cfg (or IP: 192.168.254.254), then press Enter;...
  • Page 9  The option “The configuration parameters of WiFi repeater security is synchronized with source hotspot” is default ticked, it means the SSID of VONETS repeater is associated with the SSID of the source hotspot, and the WiFi password is the same as the password of the source hotspot;...
  • Page 10: Ap Application Configuration

    2.3 AP Application Configuration VONETS device can be configured as an AP application, the wireless terminal device can connect to VONETS device hotspot to connect to the network; however, it is best to change its WiFi name and password for network security.
  • Page 11 4. Reboot device, jump to “System Settings”---- “Reboot Device”, click “Reboot”, when it is finished, all revised options will take effort. Remark 2: When VONETS device connects to external network, its IP address will be changed. At this time, when log in configured page, we suggest you enter configured domain...
  • Page 12: Chapter 3 Router Mode Configuration Instruction

    VONETS——Gigabit Industrial Bridge Repeater name: http://vonets.cfg. Or in Windows command window, enter the command: ping vonets.cfg, to get the IP address of the device, then log in configuration page by this IP address Chapter 3 Router Mode Configuration Instruction 3.1 Change device mode (In the actual application environment, if the POE output port...
  • Page 13 VONETS——Gigabit Industrial Bridge Repeater (After the WiFi parameters are configured, the WiFi will be disconnected, that is normal.) 2. After computer is connected to VONETS device, open browser, input configured page domain name: http://vonets.cfg (or IP: 192.168.254.254), then press Enter;...
  • Page 14: Wan Port Settings

    LAN port, and the WAN/LAN can be interchanged; The WiFi of the VONETS device is the WAN port by default, and the Ethernet cable is the LAN port by default. If the interface mode is changed to "WAN/LAN interchange", the Ethernet cable is the WAN port, and the WiFi is the LAN port (no modification required);...
  • Page 15: Wan Port Wired Connect Network--Dhcp

    VONETS——Gigabit Industrial Bridge Repeater 3.2.3 WAN port wired connect network——DHCP The default WAN port connection method of VONETS device is DHCP. WAN port can automatically obtain an IP address after connecting to the source network. 3.2.4 PPPoE WAN port wired connect network——PPPoE In “WAN settings”, select “Basic settings”, change the connection type to “PPPoE (ADSL)”,...
  • Page 16  The option “The configuration parameters of WiFi repeater security is synchronized with source hotspot” is default ticked, it means the SSID of VONETS repeater is associated with the SSID of the source hotspot, and the WiFi password is the same as the password of the source hotspot;...
  • Page 17 “V Series WiFi Bridge Advanced Features Instruction”; 4. Click “Reboot”, VONETS device will connect to the configured WiFi hotspot automatically, if connection is successful, the WiFi LED light will flash quickly;(Please refer to Remark 1...
  • Page 18: Set Wifi Hotspot Parameters

    VONETS——Gigabit Industrial Bridge Repeater Remark 3: After VONETS device sets the WAN port to access the WiFi hotspot in the routing mode, its LAN port IP is still 192.168.254.254, and the terminal device also obtains the IP address of the same network segment, can login configuration page by 192.168.254.254 or http://vonets.cfg.
  • Page 19: Chapter 4 Other Components And Installation Method

    VONETS——Gigabit Industrial Bridge Repeater 3. Reboot device, jump to “System Settings”---- “Reboot Device”, click “Reboot”, when it is finished, all revised options will take effort. Chapter 4 Other components and installation method 4.1 Other components 1、 Power Adapter 2、 Power Adapter (POE option)(48V/1.2A)...
  • Page 20: Industrial Chassis Rail Hook Kit Installation

    Do VONETS device support firmware upgrade, how to upgrade? VONETS devices support firmware upgrade, and support online upgrade, please visit website: www.vonets.com to refer to the related documents The device WiFi hot spot can be found, but the smart phone or PC can’t connect to this device hotspot? ...
  • Page 21 The smart phone or PC has been connected the device by WiFi or Ethernet cable, but user can’t log in the device WEB page, or after log in the WEB it shows error?  Reason 1. The users don’t use the browser recommended by VONETS(IE,Google Chrome, Safari, the mobile phone browser);...
  • Page 22 VONETS——Gigabit Industrial Bridge Repeater FCC Warning  This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
