H3 Chair Series
Installation Manual
This manual is used for the installation of CAM0431PJ
Please read this manual carefully before use and keep it properly.

Advertisement

loading
Need help?

Need help?

Do you have a question about the H3 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for SUNON H3 Series

  • Page 1 H3 Chair Series Installation Manual This manual is used for the installation of CAM0431PJ Please read this manual carefully before use and keep it properly.
  • Page 2: Assembly Note

    Assembly note: Use a protective mat and handle the product with care. Note: At least two people are required. Contact Sunon if you have any confusions.
  • Page 3: Exploded Diagram

    This picture shows all the accessories required, among which some are key accessories. If you have missed any, please contact Sunon at 949-337-8838 Exploded diagram: Name Casters 5-Star base Gas lift Seat plate Arms Seat Backrest Headrest base Headrest...
  • Page 4: Accessory List

    Accessory list: bolts M8*25 bolts M6*45 bolts M6*35 d=6 D=16 d=8 D=20 big washers washers Allen wrench H=1.5 H=1.2...
  • Page 5 1.Place the armrest on the seat and secure it with M6*45 scerws and two big washers and four small washers . The front of seat Backrest direction d=8 D=20 d=6 D=16 H=1.2 H=1.5 Seat Arms M6*45 (x2) (x1) (x2) (x4) (x6) (x1)
  • Page 6 2. Place the adjustable mechanism on the seat ,and fix it with four M6*35 screws. Seat plate M6*35 (x1) (x4) (x1)
  • Page 7 3. Fix the backrest to the seat with three M8*25 screws. Back (x1) M8*25 (x3) (x1)
  • Page 8 4. Insert five casters into the base.Then insert the gas lift into the central hole.Connect the installed chair body with the base. Gas lift (x1) 5-Star base (x1) Casters (x5)
  • Page 9 5. Place the headrest atop the backrest,then adjust it into the proper place and fix it with M6*35 screws. Done Headrest (x1) Headrest base (x1) M6*35 (x2) 5# (x1)
  • Page 10 Function: 1. Adjust Seat Height Upward: get your body off the seat and pull the lever to lift the seat to the appropriate height. Downward: press down and pull the lever to lower the seat to the appropriate height.
  • Page 11 Function: 1.99 2. Adjust Seat length Forward: Slide your body forward and pull the seat to the proper length. Backward: Slide your body back to bring your seat into position.
  • Page 12 Function: 3. Adjust backrest Angle To the outside: Lean back and adjust your back to the right Angle. Inward: Lock the backrest in place.
  • Page 13 Function: 4. Adjustable headrest Up/down,rotation,back tilt...
  • Page 14 Function: 5.Adjustable armrest 3D adjustable armrest: up/down adjustment,forward/backward adjustment,rotation adjusiment.
  • Page 15 Acceptance note: Clean the surface. Acceptance note: Tidy up. Check and deliver.
  • Page 16 Suite 150, Building 525 Technology Drive, Irvine, CA.92618 info.us@isunon.com sunonglobal.com 949-337-8838...
