- Page 1 Assembly Instruction for UP1 Height-Adjustable Desk Suite 150, Building 525 Technology Drive, Irvine, CA.92618 sunonglobal.com 949-337-8838 info.us@isunon.com Please read this manual carefully before any operation and keep it properly for future use...
- Page 2 These drawings identify the parts included with your Height Adjustable Desk. Some of these parts are considered by regulatory bodies to be criftical components. If any parts shown here do not match your order, please contact Sunon at 949-337-8838 Dismantling Schematic...
- Page 3 1. Insert Cantilevers on each end, lifting the leg a bit, if needed, to ease into a flush fit. Tab 1.Slide leg columns into place and attach with 8 M6x10 screws. into place (fit is snug). 2.Match inside holes first and lightly tighten at this point. 2.
- Page 4 Attach feet using 8 M6x14 screws. Match all 4 holes first to confirm fit before tightening completely. 1. Adjust to desired width, once at correct width. 2. Attach the beams using M6x10 screws. M4 Allen Wrench (x1)
- Page 5 1. To attach the worksurface, start by laying the worksurface down on the floor with the top down. 1. Make sure that the both side motors plugs into the control box ports. 2. Lay the base assembly upside down on top of the worksurface. 2.
- Page 6 3 level up/down default heights setting desk height 69.5 Please make sure there is no obstacle during the operation, and there Note is a gap between desk and wall. And all wires are long enough to allow the up-down of desk. Please set up as 1 the most comfortable height when you sit down, Advice and set up as 2 the most comfortable height when you stand up.
- Page 7 Centimeter/inch display switch Delete limit position Under the reset condition(digital tube shows RST), long press“M”for 5s, you can switch between inch display Press M button, the digital tube shows“S-”, release the 69.5 and cm display. 69.5 button. Press M button again for 2S, it shows“555". When it shows “10.3”, the height after reset will be The upper and lower limits have been deleted.
