- Page 1 Zen Spa Pro by Mark Sadler Installation Manual...
- Page 2 Proper preparation of the premises and systems will ensure a safe and rapid installation of the spa. For this reason we advise you to read this manual carefully and to carefully follow all the information contained herein. The Aquatica team is always available for any information or request for assistance that may be required during preparation.
-
Page 3: Table Of Contents
CONTENTS 1 SAFETY INSTRUCTIONS ........................... EXPLANATION OF PICTOGRAMS ....................PRELIMINARY OPERATIONS ....................... PREPARATIONS AND CHOICE OF POSITION ..............CHECKING MINIPOOL INTEGRITY ....................OUTDOOR INSTALLATION ........................INDOOR INSTALLATION ........................... TRANSPORT AND POSITION ......................MOVING ..................................POSITIONING ..............................TEMPORARY POSITIONING ......................... POSITIONING IN THE PLANNED LOCATION ................. -
Page 4: Safety Instructions
SAFETY INSTRUCTIONS SAFETY INSTRUCTIONS During the installation of the minipool, do Read this guide carefully before installing the appliance, and conserve this booklet not place objects inside it, even temporarily: they with care for any future consultation of users. If you may fall down the drain. -
Page 5: Preliminary Operations
PRELIMINARY OPERATIONS PRELIMINARY OPERATIONS PREPARATIONS AND CHOICE OF More information POSITION The pre-installation sheet supplied at the time purchase provides OUTDOOR INSTALLATION information necessary correct Preparations: in cold areas, to avoid possible preparation installation damage due to freezing, it is recommended to environments. -
Page 6: Transport And Position
TRANSPORT AND POSITION TRANSPORT AND POSITION MOVING To move the minipool to the place of installation a suitable lifting device (e.g., pallet jack) is required. As an alternative, provide for the availability of eight people. If the installation is indoor, before moving the minipool make sure that it can easily pass through the doors and hallways to reach the desired place of installation. -
Page 7: Positioning
TRANSPORT AND POSITION POSITIONING TEMPORARY POSITIONING The installation of the minipool should be done immediately upon receipt. In any case, once unpacked, if it is necessary to temporarily place it on a surface awaiting the installation, it will be necessary to place level concrete slabs having a minimum thickness of 5 cm under the entire bottom of the minipool. -
Page 8: Preliminary Operations
PRELIMINARY OPERATIONS PRELIMINARY OPERATIONS PREPARATION OF THE SAND FILTER More information The minipools have an empty filter and so it has WHAT IS THE SAND FILTER? to be filled. The sand filter is an effective minipool filter HOW TO FILL THE SAND FILTER connected to the recirculation pump's feed line. - Page 9 PRELIMINARY OPERATIONS ø 0,5-1mm ø 1-3mm INTERIOR - top view Caution! Make sure that the six internal filters correctly positioned secured (see Caution! Do not inhale figure). Carefully clean verify that the gaskets are still in place Ø0,5-1mm Ø1-3mm...
-
Page 10: Installation
INSTALLATION INSTALLATION DESCRIPTION OF MAIN COMPONENTS Control Panel Compensation tank Sand filter Electric pump 1 Electric pump 2 (optional) Electronic control units 2 x Blowers (of which 1 is optional) Heater Drain valve 10 Ozone 11 Compensation tank inspection 12 Overflow edge QUALIFICATIONS OF THE INSTALLER Before installation it is recommended to carefully read the safety warnings at the beginning of this manual and to always operate in perfect physical and mental condition. -
Page 11: Connections Required
INSTALLATION CONNECTIONS REQUIRED To be used, the minipool requires only two connections: Room for the electrical plumbing connections (incoming connections and outgoing water) electrical connection (power supply) electrical plumbing connection to an exchanger (optional - if present) - see following page. The following pages will provide detailed explanations of how to perform these preparations. - Page 12 INSTALLATION CONNECTION TO AN OPTIONAL EXTERNAL EXCHANGER (NOT SUPPLIED) Room for the electrical connections Exchanger is the device with which domestic Inlet connection: Outlet connection: water is heated 1 “1/4 female - socket 1 “1/4 female socket (in this manual represented by a boiler connected to the solar...
-
Page 13: Plumbing Connections
INSTALLATION PLUMBING CONNECTIONS All water connection operations must be More information performed after making sure that the minipool's water supply valve is CLOSED. WATER HARDNESS connection must made Water hardness (TH) is determined by the total experienced, qualified plumber. content of calcium and magnesium present in the water, coming from their soluble salts. - Page 14 INSTALLATION EXAMPLE OF PRE-INSTALLATION PLUMBING FOR A MINIPOOL Connection to the minipool using the 1/2 inch female hose Connect the drain of the floor provided. minipool. plumber If the minipool is installed outdoors provide an adequate responsible for the choice and type thermal insulation pipes.
-
Page 15: Electrical Connections
INSTALLATION ELECTRICAL CONNECTIONS The Aquatica minipools are built in compliance with European laws (EN 60 335-2-60) and are tested during production to ensure the safety of the installer and user. The connection must be made by an experienced, qualified electrician. All electrical connections must be made only after disconnecting the electricity in the work area. -
Page 16: Safety Zone
INSTALLATION SAFETY ZONE Local regulations prohibit any electrical installation (plug sockets, switches, lamps, etc.) in the area surrounding the minipool for a distance of at least 60 cm and a height of 230 cm. TESTING AFTER INSTALLATION MAKE SURE THAT... √... -
Page 17: First Run
FIRST RUN FIRST RUN once the water has reached the maximum level FILLING THE MINIPOOL inside the tank - the bathtub is filled through a Perform a preliminary cleaning of the minipool recirculation pump, passing through the sand filter and the heater. using a bit of water and a mild detergent. -
Page 18: First Run
FIRST RUN FIRST RUN With the bathtub full, recirculation active and Main page ozone active, start in sequence all the functions of the bathtub in the presence of the owner to verify proper operation: BLOWER The minipool can be equipped with: A single blower motor (standard) activates the nozzles on the bottom. - Page 19 FIRST RUN "OK" To stop the emptying test, disconnect the If pressed for more than three seconds you access a submenu page where other system power supply to the bathtub for about 30 functions available (empty, manual seconds. backwash, keypad lock, SILENCE mode). When accessing special...
-
Page 20: Partial Minipool Empty Test
FIRST RUN SILENCE MODE (SILENT HOURS) This function provides access to a page How to set the SILENCE function: where the hours of the day can be specifed A Press the "OK" key for at least three seconds. during which the control enters SILENCE B This provides access to a submenu page. -
Page 21: Alarms
ALARMS ALARMS If any alarms appear during initial startup, read the instructions provided in the following table. If the solution is not possible, immediately contact the Manufacturer to request technical support. In the meantime, do not try to repair or use the minipool but rather disconnect it from the electricity and water supplies. - Page 22 ALARMS Screen displayed DESCRIPTION OF THE PROBLEM ALARMS POSSIBLE SOLUTIONS NOTIFICATIONS Damage to the circulation pump. Once the minipool restarts, verify that circulation pump functions correctly. Try to perform a manual backwash of the flter (see page 20); Excessive dirtiness of the sand in the flter due to an incorrect treatment of water in the minipool (see the section on water treatment on page 13).
-
Page 23: Troubleshooting
TROUBLESHOOTING DESCRIPTION OF THE PROBLEM ALARMS Screen displayed POSSIBLE SOLUTIONS NOTIFICATIONS Leaks in the bathtub's pipes (make sure that there are no leaks in the bathtub). Check that there are no water leaks in the drain of the minipool (make sure that there is no dirt in the drain valves). -
Page 24: Decorative Panels
DECORATIVE PANELS DECORATIVE PANELS Mount the wood or laminate resin panels as shown in the figures below. -
Page 25: Covering
COVERING COVERING Do not leave the empty minipool in DIRECT SUNLIGHT. The surface temperature could rise above 80°C resulting in serious damage, including cavitation and the deformation of the surface and components (damage caused by direct exposure to sunlight is not covered by the warranty). - Page 26 NOTE...
- Page 27 Function : Form : Fashion aquaticausa.com aquaticabath.ca aquaticabath.co.uk aquaticabath.eu...
