System Q Zip ZIPE204 Quick Start Manual

1

Channel Select

2 All Channels
3

Play/Pause

4

Record

5 Menu/ Exit

Step by Step First Time Setup

1. Connect a monitor to the NVR using a HDMI or VGA cable for the video, and turn on the monitor.
2. Connect the cameras to the NVR PoE Ports (Or PoE Switch) then power the NVR using the power supply provided.
Note - do not use a 3rd party or different power supply unless instructed to do so by the manufacturer.
3. Once the NVR has booted up, connect the USB, see Operation below and connect the Network cable to the NVR.
See Troubleshooting if you do not get an image on the monitor after "System Configuring".
4. Program the basic settings using Smart Setup.

Operation

IR Remote
Numeric Buttons
1
Control
Display All
2
Menu / Escape
3
Mute
4
Sub-menu
5
Navigation / Enter
6
Rewind
7
Fast Forward
8
Play
9
10 Record
Stop
11
Pause
12
Document ref: ZIPE204
6

Direction Control

7 Ok (select) / PTZ Control
8 Power LED
9 HDD Indicator
10 USB Port
Mouse
Left-
Click
Right-
Click
Scroll-
Wheel
OSD Keyboard
ZipNVR.com
ZIPE 4ch PoE NVR Quick Start Guide
Zip is a registered trademark of System Q Ltd
Full Instruction Manual
https://systemq.com/PDF/
manual/xZIP2.pdf
1

Power Switch

2 4 Pin Power Socket
3 Alarm Inputs/ Outputs/ RS485 Interface
4 Audio Line Input
5 Audio Output
6

VGA Output

7

HDMI Output

8 USB Port
9

Reset Button

10

WAN Interface

11

PoE LAN Interface

12 eSATA Interface
Live view: display Quick Setting toolbar
Single Click
Menu: select and enter
Live view: drag channel
Privacy Masking and Motion Detection: select
Click & Drag
Digital zoom-in: zoom in to target area
Single Click Live view: show menu
Menu: exit current menu to upper level menu
Scrolling Scroll up / down through highlighted field /
drop down list
Delete character to left of the cursor
Confirm input
Switch keyboard to upper case letters and
Insert a space
Move courser left / right
target area
symbols
© 2022 System Q Ltd
