- Page 1 2110-2170 MHz Operation Manual G3L-2100-30-B (DC) / G3L-2100-30-C (AC) Wideband Multi-Carrier Power Amplifier Operation Manual 2110 MHz – 2170 MHz 044-05133 Rev. A March 2003...
- Page 2 © 2003 Powerwave Technologies Incorporated. All rights reserved. Powerwave Technologies, and the Powerwave logo are registered trademarks Powerwave Technologies, Inc. reserves the right to make changes to the documentation and equipment, including but not limited to component substitution and circuitry changes. Changes that impact this manual may subsequently be incorporated in a later revision of this manual.
-
Page 3: Section 1 General Description
G3L-2100-30-B/G3L-2100-30-C Operation Manual Section 1 General Description 1-1 Introduction This manual contains information and procedures for the operation of the model G3L-2100-30-B and G3L-2100-30-C Wideband (WCDMA) Multi-Carrier Power Amplifier (MCPA). The manual is organized into the following sections and appendix. - Page 4 WPA_ID_BIT1 BIT0=LSB, BIT!=MSB WPA_ID_BIT2 OPEN=1=Logical High Gnd=0=Logical Low Ground Connected to WPA chassis ground Free 6, 7, 14. 15, 16, 22, Reserved for WPA manufacture Copyright Powerwave Technologies, Inc., March 2003. All rights reserved 044-05133 Rev. A March 2003...
- Page 5 The WPA monitors the internal temperature. The measured temperature must represent the base plate temperature of the main power amplifier. The alarm is given according to the limits listed in table 1-5. Copyright Powerwave Technologies, Inc., March 2003. All rights reserved 044-05133 Rev. A March 2003...
-
Page 6: Status Indicator
LED state as it was before disconnection TCP/IP connection is lost for two minutes Yellow (stable) TCP/IP connection is lost and WPA is in standby state Copyright Powerwave Technologies, Inc., March 2003. All rights reserved 044-05133 Rev. A March 2003... -
Page 7: Functional And Physical Specifications
A. 1-7 Equipment Changes Powerwave Technologies, Inc. reserves the right to make minor changes to the equipment, in- cluding but not necessarily limited to component substitution and circuitry changes. Changes that impact this manual may subsequently be incorporated in a later revision of this manual. To that end, we ask that you, our customer, share with us any information acquired in field situations that would enhance this manual. - Page 8 G3L-2100-30-B/G3L-2100-30-C Operation Manual Figure 1-1 G3L-2100-30-B and G3L-2100-30-C Front and Rear Views Copyright Powerwave Technologies, Inc., March 2003. All rights reserved 044-05133 Rev. A March 2003...
-
Page 9: Section 2 Operation
G3L-2100-30-B/G3L-2100-30-C Operation Manual Section 2 Operation 2-1 Introduction This section contains operating instructions for the G3L-2100-30-B or G3L-2100-30-C wideband power amplifier (WPA). 2-2 Initial Start-Up and Operating Procedures The manual main power supply ON/OFF switch is located on the WPA front panel (refer to figure 1-1 and paragraph 1-5 for status indicator conditions). -
Page 10: Appendix A. Specifications
10 MHz lower than the lowest carrier in the operating band. Copyright Powerwave Technologies, Inc., March 2003. All rights reserved All specifications are subject to change without notice. Contact the factory for complete performance data.
