- Page 1 O U T D O O R B O O S T E R S Y S T E M M C P A O U T D O O R S Y S T E M I N S T A L L A T I O N A N D S E R V I C E M A N U A L O S - 1 9 3 3 - E 0 - 0 0 3 Installation and 044-05243 Rev A...
- Page 2 © 2008 Powerwave Technologies Incorporated. All rights reserved. Powerwave Technologies, and the Powerwave logo are registered trademarks. This Powerwave product is intended only for installation in a RESTRICTED ACCESS LOCATION and this Powerwave product is designed to operate within the normal operating (typical operating) ranges or conditions specified in this document.
- Page 3 OS-1933-E3-003 Revision Record Revision Record Revision Date of Change Reason for Change Rev A June 2008 Initial Release 044-05243 Rev A...
- Page 4 OS-1933-E3-003 Revision Record This page intentionally left blank 044-05243 Rev A...
-
Page 5: Safety
Preface Warning, Cautions, and Notes Warnings, Cautions, and Notes are found throughout this manual where applicable. The associated icons in warnings and cautions are used to quickly identify a potential condition that could result in the consequences described below if precautions are not taken. Notes clarify and provide additional information to assist the user. - Page 6 Safety OS-1933-E3-003 This page intentionally left blank. viii 044-05243 Rev A...
-
Page 7: Table Of Contents
OS-1933-E3-003 Table of Contents TABLE OF CONTENTS Warning, Cautions, and Notes............vii Safety . - Page 8 Table of Contents OS-1933-E3-003 MCPA APC ..............3-14 MCPA Front Panel Switch.
- Page 9 OS-1933-E3-003 Table of Contents List of Figures 1-1 Outdoor System Block Diagram ........... . . 1-4 1-2 Outdoor System .
- Page 10 Table of Contents OS-1933-E3-003 List of Tables 1-1 Faults ............... . . 1-3 2-1 Unpacking and Inspection Instructions .
-
Page 11: Chapter 1 - Product Description
Introduction This manual provides information and procedures for installation, operation, and maintenance of the OS-1933-E0-003 Multi-Carrier Power Amplifier (MCPA) Outdoor Booster System. Scope of Manual This manual is intended for use by service technicians familiar with similar types of equipment. It contains service information required for the equipment described and is current as of the printing date. -
Page 12: Controller Module
OS-1933-E3-003 Scope of Manual Controller Module The Controller Module shown in Fig. 1-7 provides control and monitoring of the OS operation through two Ethernet ports, Form-C alarms, external alarm inputs and LED status indicators. Status and configuration details are available through Ethernet web pages. Power System The power system shown in Figure 1-8, contains up to four +28.5 VDC plug-in 1300 watt rectifier modules.The rectifier modules convert the system AC input power to supply +28.5 VDC to each MCPA and the Controller... -
Page 13: External Alarms
Scope of Manual OS-1933-E3-003 External Alarms The OS booster is capable of monitoring and reporting external Form-C alarms. Four channels are provided and each channel is programmed via the Controller Module for NO or NC conditions. For example, NO will fault when shorted to Common (C) and NC will fault when open to Common (C).The four channels are mapped to Form-C alarm outputs configured as such via the Ethernet web pages. -
Page 14: Outdoor System Block Diagram
OS-1933-E3-003 Scope of Manual Internal User Input Power, I/O_1, Rear Interface and I/O_2 Interface Panel Panel External Alarm Ethernet Form-C Inputs Interface Interface AC Input Ethernet Ext. Alarm Info. Form-C Data Out Rectifier Fan Assy. (x2) Shelf Controller (x4) PA Control I/O DC Power RFCU Control I/O RFCU_Sector_0... -
Page 15: Outdoor System, Front View, Door Open
Scope of Manual OS-1933-E3-003 Intrusion Alarm Switch Controller Module Power System (Rectifier Modules) MCPAs RF Conditioning Unit(s) Figure 1-3 Outdoor System, Front View, Door Open External Alarms Form-C Alarms Intrusion Alarm Switch AC Input Terminal RF Input and Output Interface Panel Power/Alarm Cable Access... -
Page 16: Mcpa
OS-1933-E3-003 Scope of Manual Front Rear Figure 1-5 MCPA Front Rear Figure 1-6 RF Conditioning Unit Figure 1-7 Control Module Front Panel 044-05243 Rev A... -
Page 17: Power System
Scope of Manual OS-1933-E3-003 Rectifier 2 Rectifier 0 Rectifier 1 Rectifier 3 Figure 1-8 Power System 044-05243 Rev A... - Page 18 OS-1933-E3-003 Scope of Manual This page intentionally left blank 044-05243 Rev A...
-
Page 19: Chapter 2 - Installation
Chapter 2 Installation Introduction This chapter provides unpacking, inspection, installation instructions, and recommendations for installing the OS-1933-E3-003 Multi-Carrier Power Amplifier (MCPA) Outdoor Booster System. • Review this chapter prior to equipment installation. • Review any government and local codes applicable to this installation. •... -
Page 20: Installation Instructions
OS-1933-E3-003 Installation Instructions Installation Instructions CAUTION: After commissioning, ensure that all power cable and control cables are properly sealed to pre- vent moisture and contaminants from entering the cabinet. The outdoor system is designed for installation in an exterior location. The outdoor system must be installed in a designated location that permits access to the lower rear of the cabinet for connection of AC power, RF, communications, and alarm cables. -
Page 21: Ac Power
Installation Instructions OS-1933-E3-003 Table 2-4 Tools Needed for Installation Tools Needed Where Used Tools Needed Where Used Crimp tool Ground cables Screwdriver, slotted, Securing alarm cables 2.5mm (0.1 in) maximum width Electrician’s knife Earth ground Wire cutters Cut tie wraps Cable cutters Ground cables Digital volt-ohm meter... -
Page 22: Rf Cable
OS-1933-E3-003 Installation Instructions Spring Cage Terminal Block L G N 0.5 to 0.625" AC Power Connections Common Earth Ground Terminal Figure 2-1 AC Power Connections Example RF Cable All cable connections are made at the system cabinet lower-rear RF interface bulkhead panel as listed in Table 2-6. -
Page 23: Interface Bulkhead Rfcu Connections
Installation Instructions OS-1933-E3-003 M8 Studs 3/4” (19 mm) Ground Studs Figure 2-2 Interface Bulkhead RFCU Connections Control Module Thumbscrews Figure 2-3 Controller Module Installation 044-05243 Rev A... -
Page 24: Form-C Alarms
OS-1933-E3-003 Installation Instructions Figure 2-4 Form-C Alarms and External Alarms Connections Form-C Alarms The Form-C alarm connections are made at the terminal block located at the rear of the Control Module. The contacts accept a 28 - 16 AWG wire. The alarm cable connection is shown in Figure 2-4 and the alarm wiring and relay conditions are listed in Table 2-7. -
Page 25: External Alarms (Ea)
Installation Instructions OS-1933-E3-003 Table 2-8 Form-C Alarm Terminal Block Relay Connections and Conditions Relay Continuity Measurement - No AC Applied or All Rectifiers Faulted Minor Major Critical (All) NO - C Closed NO - C Closed NO - C Closed NC - C Open NC - C... -
Page 26: Mcpa 21-Pin D-Sub Connector Location
OS-1933-E3-003 Installation Instructions Table 2-10 MCPA Installation Step Action Inspect MCPA rear-mounted 21-pin D-Sub connector. Verify all pins are straight, not broken or recessed, and alignment shield is not bent. Verify MCPA RF OFF/ON/RESET switch in OFF (down) position. Figure Verify MCPA top and bottom quarter-turn fasteners are in unlocked position as shown in 2-5. -
Page 27: Power System Installation
Installation Instructions OS-1933-E3-003 Power system Installation The power system is comprised of rectifier modules that are inserted into the rectifier shelf. A minimum of two rectifier modules minimum is a practical consideration. Reference the recommended configurations detailed in Table 2-11. Install the Rectifier modules as instructed in Table 2-12. CAUTION: Do not slam the Rectifier Modules into the subrack. - Page 28 OS-1933-E3-003 Installation Instructions This page intentionally left blank 2-10 044-05243 Rev A...
-
Page 29: Chapter 3 - Operation
Chapter 3 Operation INTRODUCTION This chapter provides steps for configuring and operating the OS System. The main topics are: • Initial Start-Up Procedure • OS System Configuration Procedure • Rectifier • MCPA • Controller / Web Page Functions • Alarm Functions Initial Start-Up Procedure Ensure that the OS System is installed per Chapter 2. -
Page 30: Os System Configuration
OS-1933-E3-003 OS System Configuration Table 3-1 Initial Start-Up Procedure (Continued) Measure the output DC voltage. There is a fused output for each MCPA and the Controller. All outputs should be 28.5V +/-0.5Vdc. If the voltage measurements are non-compliant with the limits troubleshoot the power system before proceeding. -
Page 31: Network Configuration And Controller Module Connections
OS System Configuration OS-1933-E3-003 Customer Powerwave Laptop Product Ethernet 192.168.255.2 Site Ethernet Local Equipment 192.168.255.1 Typical product network configuration Controller Module PC Local LAN connection (front) Site LAN connection (rear) Figure 3-1 Network Configuration and Controller Module Connections Figure 3-2 Network Connections Dialog Box 044-05243 Rev A... -
Page 32: Local Area Connection Properties Dialog Box
OS-1933-E3-003 OS System Configuration Figure 3-3 Local Area Connection Properties Dialog Box Figure 3-4 Internet Protocol (TCP/IP) Properties. 044-05243 Rev A... -
Page 33: Activate Sectors
OS System Configuration OS-1933-E3-003 Figure 3-5 Setting the IP Address. Figure 3-6 Enable the Connection Activate Sectors Table 3-3 Activate Sectors Step Action Select the System/Configuration Page. See Figure 3-15 Using the pull-down menus in the Installed section choose YES for the Sectors to be utilized.
