Bob's Discount Furniture SAVOY CHAIR Assembly Instructions

Read instructions carefully prior to assembly.
Thank you for purchasing this quality product. Check carefully for small parts which may come loose during shipment.
Remove all components from pack and place top down on soft surface such as carpet or cloth to prevent scratching the finish.
Identify and count all parts as specified below.
It is recommended to use two or more people during the assembly process.
HARDWARE LIST:
No. Sketch
Description
1
Long Bolt
2 Short Bolt
Long Bolt
3
Lock Washer
4
Flat Washer
5
Allen Key
6
A
Step 1:
Attach the Seat Cushion (B) to the Chair Back (A) by using Fat
Washer (5), Lock Washer (4), Short Bolt (2) on back rail and insert
Fat Washer (5), Lock Washer (4), Long Bolt (1) onto corner of seat
frame and secure with Allen Key (6). Do not fully tighten.
Cleaning instructions: Clean using soft cloth
ASSEMBLY INSTRUCTIONS
SAVOY
CHAIR, SIDE UPH 2/CTN
Size
ɸ 5/16'' x 75mm
ɸ 5/16'' x 40mm
ɸ 5/16'' x 50mm
ɸ 5/16'' x 13mm
ɸ 5/16'' x 19mm
4mm
6
1
B
4
2
4
5
. Description
No
Q.TY
4 pcs
A
Chair Back
2 pcs
Seat Cushion
B
w /wood Dowel
4 pcs
10 pcs
Front Leg
C
10 pcs
1 pc
5
6
Step 2:
Attach Front Legs (C) to the Seat Cushion (B) by using Flat
Washer (5), Lock Washer (4), Long Bolt (3) and secure with
Allen Key (6).
Step 3:
Place the chair on flat surface and adjust legs so that chair is
level and
. Assembly product is completed .
PARTS LIST:
Sketch
B
C
not wobble . Tighten all Bolts with Allen Key (6)
Made in Vietnam
Page 1 of 1
Qty
1 pc
1 pc
2 pcs
6
3
4
5
