RAZER LEVIATHAN V2 PRO
MASTER GUIDE
F O R G A M E R S . B Y G A M E R S .
0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LEVIATHAN V2 PRO and is the answer not in the manual?

Questions and answers

Related Manuals for Razer LEVIATHAN V2 PRO

Summary of Contents for Razer LEVIATHAN V2 PRO

  • Page 1 RAZER LEVIATHAN V2 PRO MASTER GUIDE F O R G A M E R S . B Y G A M E R S .
  • Page 2 Experience the next innovation in 3D spatial audio with the Razer Leviathan V2 Pro the world's first PC soundbar with AI head tracking and adaptive beamforming. Directing sound to your ears through intelligent on-the-fly tracking, enjoy ultra-personalized audio with untold accuracy and immersion.

  • Page 3: Table Of Contents

    5. SETTING UP YOUR RAZER LEVIATHAN V2 PRO.................... 7 6. CONNECTING TO YOUR SOUNDBAR ........................ 9 7. USING YOUR SOUNDBAR ..........................13 8. CONFIGURING YOUR RAZER LEVIATHAN V2 PRO VIA RAZER SYNAPSE ..........20 9. SAFETY AND MAINTENANCE ........................... 32 10. LEGALESE ................................33...

  • Page 4: What's Inside

    1. WHAT'S INSIDE ▪ Razer Leviathan V2 Pro FRONT REAR Equalizer button Integrated IR camera* Audio mode button Soundbar lighting Powered by Razer Chroma Power button / Volume control knob Power port Source button Subwoofer port Chroma button Headset port...
  • Page 5 ▪ Subwoofer Rear-facing bass port Power port Soundbar port Power button ▪ USB Type A to USB Type C cable ▪ Subwoofer regional power cords** ▪ Soundbar power adapter + regional ▪ 2.5 mm Aux cable (for soundbar to power cords** subwoofer connection) ▪...

  • Page 6: What's Needed

    2. WHAT'S NEEDED PRODUCT REQUIREMENTS ▪ USB Type A port or devices with Bluetooth connectivity RAZER AUDIO APP REQUIREMENTS ▪ iOS 14 / Android 10 (or higher) devices with Bluetooth connectivity ▪ Internet connection for software installation RAZER SYNAPSE REQUIREMENTS ▪...

  • Page 7: Technical Specifications

    4. TECHNICAL SPECIFICATIONS TECHNICAL SPECIFICATIONS ▪ Razer Chroma RGB (30 zones) ▪ THX Spatial Audio ▪ Bluetooth 5.0 ▪ USB audio input ▪ 3.5mm socket with mic in ▪ Wired subwoofer ▪ Razer Audio app ▪ Custom 10-band EQ ▪ Frequency Response: 40Hz 20 kHz ▪...

  • Page 8: Setting Up Your Razer Leviathan V2 Pro

    5. SETTING UP YOUR RAZER LEVIATHAN V2 PRO 1. Connect the subwoofer to the subwoofer output port on the soundbar using the 2.5 mm aux cable. 2. Connect the soundbar to any USB Type A ports on your PC using the included USB Type C to USB Type A cable.
  • Page 9 3. With the appropriate power cord connected to the power adapter, connect it to the power port of the Razer Leviathan V2 Pro and plug it into a power outlet. Use the appropriate power cord for your region. 4. Connect the appropriate power cord to the subwoofer and plug it into a power outlet. The subwoofer's Power button will light up, indicating that the subwoofer is powered on.

  • Page 10: Connecting To Your Soundbar

    Source button will turn solid green to indicate that the soundbar is in PC mode. PC MODE (Solid green) 2. Set the Razer Leviathan V2 Pro as the default Output device on your PC. Razer Leviathan V2 Pro When using the soundbar with compatible devices, set the Razer Leviathan V2 Pro as its default output device (if applicable).
  • Page 11 MODE BLUETOOTH MODE (Pairing Blinking blue) Activate Bluetooth on your device and select "Razer Leviathan V2 Pro (BT)" from the available devices. Razer Leviathan V2 Pro (BT) F O R G A M E R S . B Y G A M E R S .
  • Page 12 Bluetooth mode. Learn more about switching between soundbar modes The Razer Leviathan V2 Pro is now ready for use in Bluetooth mode. C. VIA HEADSET PORT (HEADSET OUTPUT) This feature is available in both PC and Bluetooth modes.
  • Page 13 When the soundbar is toggled to headset output, it will continue using the connected headset as the audio output even as you switch between PC and Bluetooth modes. To use the connected headset as an audio input device, ensure the Razer Leviathan V2 Pro is set as your system's input device.

  • Page 14: Using Your Soundbar

    Movie Music Custom You can also change the active EQ preset and personalize the Custom EQ preset using the Razer Audio app (mobile devices) and Razer Synapse app (PC). Learn more about the Audio Equalizer F O R G A M E R S . B Y G A M E R S .
  • Page 15 (in low brightness) if the IR camera cannot track your ears. You can also change the soundbar's audio mode using the Razer Audio app (mobile devices) and Razer Synapse app (PC).
  • Page 16 ADJUSTING THE VOLUME Rotate the volume control knob to adjust the volume of the soundbar. The indicator LEDs will briefly diverge as you increase the volume and converge as you decrease it. Decrease volume Increase volume When decreasing the volume, the two middle indicator LEDs will start blinking to indicate that the soundbar is already at its lowest volume.
  • Page 17 SWITCHING BETWEEN SOUNDBAR MODES Press the Source button to switch between PC and Bluetooth modes. PC MODE BLUETOOTH MODE (Solid green) (Paired Solid blue) Switching to Bluetooth mode will activate pairing mode when the soundbar is not paired to any device.
  • Page 18 BLUETOOTH MODE (Pairing Blinking blue) Bluetooth pairing mode can only be activated from Bluetooth mode. 2. Activate Bluetooth on your device and select "Razer Leviathan V2 Pro (BT)" from the available devices. Razer Leviathan V2 Pro (BT) 3. Wait until both devices are connected. The Source button will briefly show solid blue to indicate that the soundbar is now connected to your device.
  • Page 19 HEADSET OUTPUT OUTPUT You can also use the Razer Audio app (mobile device) or the Razer Synapse app (PC) to toggle between a soundbar and headset outputs. CYCLING THROUGH CHROMA EFFECTS Press the Chroma button to cycle through the following lighting effects on the soundbar: Ambient awareness, Audio meter, Breathing, Fire, Spectrum cycling, Starlight, Static, and Wave.
  • Page 20 Customize the soundbar's audio mode, EQ settings, Chroma lighting effect, and fine-tune other advanced features for an immersive audio experience that's genuinely yours. Install Razer Synapse when prompted, or download the installer from razer com/synapse Razer Audio app (Mobile devices) Customize the soundbar's EQ settings and audio mode, conveniently toggle between connected audio devices, and even experience full RGB lighting customization from your mobile device.

  • Page 21: Configuring Your Razer Leviathan V2 Pro Via Razer Synapse

    Razer ID account is recommended but optional. All listed features are subject to change based on the current software version, the connected device(s), and supported apps and software. SYNAPSE TAB The Synapse tab is your default tab when you first launch Razer Synapse. This tab allows you to navigate the Dashboard subtab. Dashboard The Dashboard subtab is an overview of your Razer Synapse, where you can access all your Razer devices, modules, and online services.
  • Page 22 Modules The Modules subtab displays all installed and available modules for installation. Global Shortcuts Bind operations or Razer Synapse functions to custom key-combinations from any Razer Synapse- enabled device inputs, which apply across all device profiles. Learn more about Profiles Only Razer Synapse-enabled device inputs will be recognized.
  • Page 23 AUDIO TAB The Audio tab is the main tab for your Razer Leviathan V2 Pro, where you can customize your soundbar's settings to unleash its full potential. Changes made under this tab are automatically saved to your system and cloud storage.
  • Page 24 Allows you to switch the soundbar to Bluetooth mode using Razer Synapse. Razer Synapse won't be able to revert to PC mode when the soundbar has been set to Bluetooth mode. To set the soundbar to PC mode, press the Source button.
  • Page 25 Use the EQ subtab to customize the frequency response of the soundbar or normalize the loudness of audio to avoid unpleasant increases in volume. Audio equalizer Select any available equalizer preset created for the best audio experience designed for balance, gaming immersion, movie viewing, or enjoying your favorite music.
  • Page 26 Lighting The Lighting subtab enables you to customize the lighting on the soundbar. Brightness You can turn off the soundbar lighting by toggling the Brightness option or increase/decrease the luminance using the slider. Switch Off Lighting This power-saving tool allows you to disable soundbar lighting when your system's display is turned off.
  • Page 27 Only devices that support the selected lighting effect will synchronize. Advanced Effects The Advanced Effects option allows you to choose a Chroma Effect you want to use on your Razer Chroma-enabled peripheral. To start making your own Chroma Effect, simply press the Chroma Studio button ( F O R G A M E R S .
  • Page 28 Power Use the Power subtab to enable the soundbar to enter standby mode when idle for a certain period. F O R G A M E R S . B Y G A M E R S .
  • Page 29 PROFILES TAB The Profiles tab is a convenient way to manage all your profiles and link them to your games and applications. Devices View which games are linked to each device's profiles or which Chroma Effect is linked to specific games using the Devices subtab.
  • Page 30 Added games will still be listed here, even if they are not linked to a Razer device. To link games to connected Razer devices or Chroma Effects, click on any game from the list, and then click Select a device and its profile to launch automatically during gameplay to select the Razer device or Chroma Effect it will link with.
  • Page 31 Dashboard. Reset tab The Reset tab allows you to perform a factory reset on all connected Razer devices with on-board memory and/or reset Razer Synapse tutorials to acquaint yourself again with Razer Synapse's new features on its next launch.
  • Page 32 All profiles stored on the selected device's on-board memory will be erased when you reset a Razer device. About tab The About tab displays brief software information and copyright statement, and provides relevant links for its terms of use. You may also use this tab to check for software updates, or as quick access to Razer's social communities.

  • Page 33: Safety And Maintenance

    SAFETY GUIDELINES To achieve maximum safety while using your Razer Leviathan V2 Pro, we suggest that you adopt the following guidelines: ▪ Should you have trouble operating the device properly and troubleshooting does not work, unplug the device and contact the Razer hotline or go to support.razer.com...

  • Page 34: Legalese

    Product. In no event shall Razer's liability exceed the retail purchase price of the Product.
  • Page 35 Product was purchased. If any term herein is held to be invalid or unenforceable, then such term (in so far as it is invalid or unenforceable) shall be given no effect and deemed to be excluded without invalidating any of the remaining terms. Razer reserves the right to amend any term at any time without notice.
