OSM control buttons on the front of the monitor function as follows:
™
EXIT
CONTROL
/
CONTROL
+/–
PROCEED
RESET
NOTE:
When OSM controls are activated, icons are displayed at the top of
the menu. If an arrow ( ) is displayed, it indicates further choices
are available.

Brightness/Contrast Controls

Brightness: Adjusts the overall image and background screen
brightness.
Contrast: Adjusts the image brightness in relation to the
background.
Degauss: Eliminates the buildup of stray magnetic fields which alter
the correct scan of the electron beams and affect the purity of the
screen colors, focus and convergence. When activated, your screen
image will jump and waver a bit as the screen is demagnetized.
Caution: Please allow a minimum of 20 minutes to elapse between
uses of the Degauss Control.
78131622

Controls

Main Menu
Exits the OSM controls.
Moves the highlighted
area up/down to select
one of the controls.
Moves highlighted
area left/right to select
one of the controls.
Has no function.
Resets all the controls within
the highlighted menu
to the factory setting.
When RESET is pressed in the main and sub-menu, a warning
window will appear allowing you to cancel the reset function.
4
Sub-Menu
Exits to the OSM controls
main menu.
Moves the highlighted area
up/down to select one of the
controls.
Moves the bar in the + or –
direction to increase or
decrease the adjustment.
Only executes control
or enters sub, sub-menu.
Resets the highlighted control
to the factory setting.
