TECHNICAL DATA

Turn X
Type of turntable: .............................................................................Direct drive, fully manual
Motor: ..................................................................................................DC Motor, 16-Pole, 3-Phase
Rotation speeds: ...............................................................................33 1/3, 45 & 78 RPM
Breaking System: ..............................................................................Electronic brake
Wow and Flutter: ...............................................................................Less than 0.1% WRMS (JIS WTD)
S/N Ratio: ...........................................................................................More than 60dB (DIN-B)
Analogue Output: ..............................................................................Phono
Connections: ......................................................................................RCA Audio output (gold-plated)
Turntable Platter: .............................................................................305 mm diameter, 23 mm thick, 2.1 kg, Aluminium die-cast
Tone Arm type: ..................................................................................Static balanced S-Shape
Effective Arm Length: ......................................................................230 mm
Applicable Cartridge Weight: ..........................................................17~25g (incl. Headshell)
Overhang: ...........................................................................................15 mm
Anti-Skating adjustment: ................................................................Yes
Anti-Skating Range: .........................................................................0-3 g
Type of cartridge: .............................................................................Ortofon 2M Blue
Power Supply: ....................................................................................AC IN 100~240V, 50/60 HZ
Power consumption: .........................................................................3W
Dimensions: ........................................................................................460 x 172.6 x 367.3 mm
Weight: ................................................................................................10.35 kg
Ortofon 2M Blue
Output voltage at 1000 Hz, 5cm/sec.: ..........................................5.5 mV
Channel balance at 1 kHz: ...............................................................1.5 dB
Channel separation at 1 kHz: ..........................................................25 dB
Channel separation at 15 kHz: ........................................................15 dB
Frequency response at -3dB: ..........................................................20-20.000 Hz + 2 / - 1 dB
Tracking ability at 315Hz at recommended tracking force: ......80 µm
Compliance, dynamic, lateral: ........................................................20 µm/mN
Stylus type: ........................................................................................Nude Elliptical
Stylus tip radius: ...............................................................................r/R 8/18 µm
Tracking force range: .......................................................................1.6-2.0 g (16-20 mN)
Tracking force, recommended: .......................................................1.8 g (18 mN)
Tracking angle: ..................................................................................20°
Internal impedance, DC resistance: ...............................................1.3 kOhm
Internal inductance: .........................................................................700 mH
Recommended load resistance: .....................................................47 kOhm
Recommended load capacitance: ..................................................150-300 pF
Cartridge colour, body/stylus: ........................................................Black/Blue
Cartridge weight: ..............................................................................7.2 g
Note: Subject to alterations. The specified data is of approximate value.
HELP & SUPPORT
If you need additional help or have technical questions,
you can contact our support team:
https://www.reloop-hifi.com/support-ticket-request
Reloop Hifi
www.reloop-hifi.com
Reloop
Global Distribution GmbH & Co. KG
Schuckertstrasse 28
48153 Muenster / Germany
Fax: +49.251.6099368
Subject to alterations.
Illustrations similar to original product.
Misprints excepted.
