Specifications - NEC MultiSync LCD1720M User Manual

6. This LCD monitor is designed for use with a flexible arm.
Please use the attached screws (4pcs) as shown in the picture when
installing.
To meet the safety requirements, the monitor must be mounted to an arm
which guaranties the necessary stability under consideration of the
weight of the monitor.
The LCD monitor shall only be used with an approved arm (e.g. GS
mark).

Specifications

4-SCREWS (M4)
(MAX depth: 10mm)
If using other screws than
ones included, first check
depth of the hole.
–continued
Replace screws
Weight of LCD Assembly : 5.5kg (MAX)
7
Thickness of
bracket (arm)
2.0~3.2mm
Tighten all
screws.
100mm
