Controls

INPUT SELECT
If no OSM menu is displayed, video input and USB upstream can be changed by
pressing the PROCEED button.
: Changes only video
: Changes video and USB
OSM ™ (On-Screen-Manager) Controls
To access OSM press any of control buttons (
The OSM controls on the front of the monitor function as follows:
Control Main Menu
EXIT Exits the OSM controls.
CONTROL / Moves the highlighted
area up/down to select
one of the controls.
Proceeds to the selected
CONTROL /
menu choice (indicated
by the highlighted area)
PROCEED Has no function
RESET Resets the highlighted control Resets the highlighted control to the
menu to the factory setting.
NOTE: When RESET is pressed, a warning window will appear

Brightness and Contrast

BRIGHTNESS: Adjusts the overall image and background screen brightness.
CONTRAST: Adjusts the image brightness in relation to the background.
AUTO ADJUST: (Analog Input Only) Corrects the image displayed for non-
standard video inputs.
Auto Adjust (Analog Input Only):
and Fine settings.
Position (Analog Input Only)
H. POSITION: Controls horizontal image position within the display
area of the LCD.
H. POSITION: Controls vertical image position within the display area
of the LCD.
AUTO ADJUST: Automatically sets the horizontal and vertical image
position within the display area of the LCD.
1525X.wpc
,
Sub-Menu
Exits to the OSM controls main menu.
Moves the highlighted area
up/down to select one of the controls.
Moves the bar in the + or – direction to
increase or decrease the adjustment.
Activates Auto Adjust feature. In Tools and
Information Mode, opens additional window.
factory setting.
allowing you to cancel the reset function.
Adjusts the Position, H. Size
